Jma-5100 series color marine radar

Advertisement

Quick Links

Worthy choice of Quality Inovation
Combining the best features from the most popular JRC radars
Special Features We got'em!
Designed for Flexibility
Four unit configuration: Processor, Keyboard, Display and Antenna
Flush-mount or Console-mount installation available
To use jog-dial and trackball makes operation very easy
Target trail time can be displayed and recorded simultaneously in two formats
(equipped with background trail function)
Scale has large off-center function (90% or more, 4x range display compared to normal)
Direct connection to PC plotter
"Radar System Data (RSD)," "Tracked Target Message (TTM*)," and "Own Ship Data (OSD)" output directly to the PC.
TTM with optional MARPA installation.
*
GPS compass direct input, NSK unit connectivity
Full control of antenna from second station
New MARPA, Automatic Tracking Device - "ATD" - Semi ATA function
Greater performance by using the ARPA algorithm applied to large radars
Manual acquisition of 10 targets, target numbers automatically assigned
High-speed rotation (4 ft/6 kW)
Dedicated LCD display unit meets IPX5 waterproofing, vibration specifications
IEC60945 adjustable brightness level for night sailing / fishing
JMA - 5100
series
Small size black box (processor)
< option >
< option >
< option >
Variable vertical or horizontal screen
< option >
