Summarization of Contents
Front Panel Functions
DISPLAY
Shows selected source, volume, and digital input format (PCM, MQA, DSD).
STANDBY
Places amplifier in standby or switches it on. Indicates status with LED and display line.
MUTE/REMOTE CONTROL PAIRING BUTTON
Mutes speaker/pre-outs, or pairs amplifier with Apple remote control.
NAVIGATION/MENU BUTTON
Selects source input or enters menu system for settings adjustment.
VOLUME CONTROL (ROTATING KNOB)
Adjusts volume, source, or other settings via rotation.
Rear Panel Features
SPEAKER TERMINALS
Accepts spade connectors and 4mm banana plugs for speaker cable connection.
PRE OUT
Pre-amplifier output connections for sub-woofers or other amplifiers.
LINE INPUTS
Five single-ended RCA inputs for connecting audio sources.
BNC DIGITAL INPUTS
Two electrical S/P-DIF inputs supporting PCM, MQA, and DSD.
TOSLINK OPTICAL INPUT
Two optical S/P-DIF inputs supporting PCM, MQA, and DSD.
USB INPUT
One fully isolated UAC 2 asynchronous USB input for digital audio.
POWER ON/OFF SWITCH
Toggles between full off and standby mode, affecting power consumption.
POWER INLET
Accepts 100-240VAC 50-60Hz via IEC 60320-C13 connector.
RS-232, FIRMWARE UPDATE
Interface for firmware updates, intended for qualified service personnel.
TRIGGER OUTPUT
DC trigger output to power other equipment along with the amplifier.
REMOTE
REMOTE CONTROL PAIRING
Instructions for pairing the amplifier with a remote control.
FACTORY RESET
Procedure to reset all settings to default factory configurations.
