Summarization of Contents
Preliminary Notes and Warnings
Document Symbols
Explains symbols used for instructions, reactions, cross-references, and important notes in the manual.
Warning Levels Explained
Defines the meaning of WARNING, CAUTION, and NOTE for safety and property protection.
Product Functions and Features
IO-Link Communication
Enables direct access to process/diagnostic data and parameter setting via an IO-Link master.
Electrical Connections
IO-Link and Standard Pinouts
Defines pin assignments for M12 connectors in both IO-Link and Standard modes.
Operation Overview
IO-Link Operation
Connects unit to IO-Link master for controlling LED segment colours and states via parameters.
Digital IO Operation
SIO Mode Configuration
Assigns colour, flash rate, and intensity to digital inputs in SIO mode (On/Off and RGB).
Scale Drawings
Model Dimensions
Detailed measurements for DV212x and DV213x signal lamps.
Technical Data
IO-Link Technical Specifications
Details transmission type, revision, device ID, SIO mode, and cycle times for IO-Link.
Maintenance and Disposal
Cleaning Housing Surface
Steps for cleaning the device housing using soft cloths, with recommendations for damp cleaning.
