Summary of Contents for Zonet KVM3332
- Page 2 NOTE: All hardware must power-OFF before and during hardware installation. 1. Connect all KVM cables to the KVM switch and computers. 2. Connect monitor, keyboard, mouse, speaker and microphone to the KVM switch’s console port. 3. Power-ON all hardware. 4. Do not switch between computers during boot-up process. 5.
- Page 3 Monitor: To the female VGA (HDDB-15) console port Speaker: To the top audio console port next to the speaker symbol Microphone: To the bottom audio console port next to the microphone symbol USB Mouse: To the right USB female console port with the Mouse symbol USB Keyboard: To the left female USB console port with the keyboard symbol NOTE:...
- Page 4 KVM3332 supports 4 different “Hot Key” modes in order to be compatible with different keyboards. [Ctrl] + [Shift] mode (Left-hand side) – default settings [Ctrl] ++ [Ctrl] Go to next PC [Ctrl] ++ [Shift] + 1 Go to PC 1 [Ctrl] ++ [Shift] + 2 Go to PC 2 [Ctrl] ++ [Shift] +...
- Page 5 ’ ’ [Caps Lock] mode [Caps Lock] ++ [Caps Lock] + 1 Go to PC 1 [Caps Lock] ++ [Caps Lock] + 2 Go to PC 2 [Caps Lock] ++ [Caps Lock] + Go to the next PC (Ex: 1 [Caps Lock] ++ [Caps Lock] + Go to the previous PC (Ex: 2 [Caps Lock] ++ [Caps Lock] + B...
- Page 6 1. Make sure all KVM cables are connected securely, properly and well-seated. 2. Suggested to label all KVM cables accordingly to avoid confusion. 3. Do not move or press any mouse buttons when switch between PC ports. 4. Do not move or press any keys on keyboard when switch between PC ports. It may cause keyboard error.
