Page 1: Package Contents
All manuals and user guides at all-guides.com Package Contents • One ZFS3308E • One Quick Installation Guide • One Power Adapter • Four Rubber Pads Contact your local authorized reseller or the store purchased from for any items damaged and/or missing. -
Page 2: Front Panel
All manuals and user guides at all-guides.com Front Panel Status Operation Steady Power is ON Steady Network cable connected and connection established Flash Data packets are transmitting Rear Panel Item Name Description Power connector, connects to power adapter RJ-45 ports 1 to 8... - Page 3 All manuals and user guides at all-guides.com Connect the provided power adapter to the Power connector of the ZFS3308E Connect your network devices to the RJ-45 ports of the ZFS3308E with UTP/STP Category 3/4/5 cables...
- Page 4 • Do not recommend to put any items on top of the switch • ZFS3308E is not ideally to work in a high electromagnetic environment, under direct sunlight, dust and vibrating surfaces • Maximum distance between the switch and the end node is 100 meters •...
- Page 5 All manuals and user guides at all-guides.com 1. Check the power adapter and power wall-jet to make sure they are function properly. Check if the switch is turned-ON and power LED is steady. 2. Check all cable connections between computer and the switch to make sure they are connected properly.
