Battery and Charger
USER MANUAL
Battery and Charger User Manual
Podręcznik użytkownika akumulatora i
ładowarki
배터리 및 충전기 사용 설명서
Brugervejledning til batteri og oplader
Uživatelská příručka k akumulátoru a
nabíječce
Manual de utilizare baterie și încărcător
Εγχειρίδιο χρήσης μπαταρίας και
φορτιστή
95-3018-005-100 Rev D © 2023 SRAM, LLC
Advertisement
Related Manuals for SRAM eTap axs 25402
Summarization of Contents
Single Battery Charger Base
LED Indicator Status
Displays the status of the LED indicators on the single battery charger base.
Troubleshooting
Provides solutions for common problems encountered with the single battery charger.
Four Battery Charger Base
LED Indicator Status
Displays the status of the LED indicators on the four battery charger base.
Troubleshooting
Provides solutions for common problems encountered with the four battery charger.
Single Battery Charger Base - USB Connection
Micro USB Connection
Connects the USB cable to the Micro USB port on the charger base.
Fire Hazard Warning
Warns against using non-SRAM cables/chargers, which can cause overheating or fire.
Connecting to USB Charging Port
USB 3.0 Charging Port Recommendation
Recommends using USB 3.0 or later ports for best charging performance.
USB AC Adapter Requirements
Specifies that a USB AC adapter is not included and requires minimum 1A at 5V.
Battery Cover Removal and Handling
Battery Cover Notice
Advices to store the battery cover and avoid metal contact with terminals.
Adjusting Battery Charge Indicator
Instructions on adjusting the dial on the battery cover to show charge status.
Battery Insertion and Charging
Battery Insertion Procedure
Instructions on inserting the battery into the charger base, ensuring the tab is seated first.
Battery Charging Time
Details charging time for a full charge using the recommended adapter and variability by power source.
Battery Release and Storage
Battery Release Mechanism
How to press the button on the charger base to release the battery.
Battery Storage and Handling Precautions
Emphasizes covering terminals when not in use and consulting authorities for travel restrictions.
LED Indicator Status
Solid Blue LED
Indicates the charger is receiving adequate power.
Flashing Blue LED
Indicates less than optimal power, resulting in slower charging.
Amber LED
Indicates the battery is currently charging.
Green LED
Indicates that charging is complete.
Troubleshooting
Red LED Error Indicator
A red LED indicates an error; troubleshooting steps include reinstalling the battery and checking connections.
No LEDs Illuminate
If no LEDs light up after 5 seconds, check plug insertion and power supply (1A at 5V).
Four Battery Charger Base - USB Type C Connection
USB Type C Cable Connection
Connects the USB Type C cable into the port on the charger base.
Fire Hazard Warning
Warns against using non-SRAM cables/chargers, which can cause overheating or fire.
Connecting USB Type C to Charging Port
USB Type C Port Recommendation
Recommends using a USB Type C charging port for best performance.
USB Type C Adapter Requirements
States adapter is not included and requires minimum 3A at 5V.
Battery Cover Removal and Handling
Battery Cover Notice
Advices to store the battery cover and avoid metal contact with terminals.
Adjusting Battery Charge Indicator
Instructions on adjusting the dial on the battery cover to show charge status.
Four Battery Charger - Battery Insertion
Multiple Battery Insertion
Instructions for inserting up to 4 batteries into the charger base, ensuring tabs are seated.
LED Illumination Delay
The charger LED may take up to 5 seconds to illuminate after battery installation.
Battery Charging Times and Modes
Fast Charge (1-2 Batteries)
Details fast charging for 1 or 2 batteries to >75% within 20 or 30 minutes respectively.
Standard Charge (3-4 Batteries)
Details standard charging for 3 or 4 batteries to 100% in about 1 hour.
Recommended USB Type C Adapter
Emphasizes using the recommended USB Type C adapter for sufficient power supply.
Battery Release and Storage Precautions
Battery Release Mechanism
How to press the button on the charger base to release the battery.
Battery Storage and Handling Precautions
Emphasizes covering terminals when not in use and consulting authorities for travel restrictions.
LED Indicator Status
Solid Blue LED Indicator
Indicates the charger is receiving adequate power.
Flashing Blue LED Indicator
Indicates less than optimal power, resulting in slower charging.
Amber LED Indicator
Indicates the battery is currently charging.
LED Indicator Status - Completion and 75% Charge
Solid Green LED
Indicates that the battery charging is complete.
Flashing Green LED
Indicates that the battery is 75% charged.
Troubleshooting
Red LED Error Indicator
A red LED indicates an error; troubleshooting steps include reinstalling the battery and checking connections.
No LEDs Illuminate
If no LEDs light up after 5 seconds, check plug insertion and power supply (3A at 5V).
Maintenance and Safety Precautions
Battery Cleaning and Storage
Guidelines for keeping the battery clean, dry, and storing it at room temperature.
Battery Handling Warnings
Warns against using damaged, dropped, or modified batteries or chargers.
Recycling and Environmental Compliance
Recycling Information
Provides website for recycling and environmental compliance information.
Battery Replacement Guideline
States to only use authentic SRAM replacement batteries.
Fire Warning for Batteries
Warns never to dispose of batteries in a fire.
Rechargable Lithium-Ion Polymer Battery Specifications
Battery Model Numbers
Lists battery model numbers: 25401, 25402, and 25403.
Cell Type and Pack Configuration
Details the cell type and pack configuration of the battery.
Electrical Specifications
Includes EOD Voltage, Nominal Voltage, Nominal Capacity, Minimum Capacity, and Average Working Voltage.
Battery Specifications - Continued
Constant Voltage and Battery Weight
Specifies constant voltage and the weight of the battery.
Cell Dimensions
Details the maximum length, width, and thickness of the battery cells.
Operating and Storage Temperature Ranges
Lists temperature ranges for standard charging, discharge, and storage.
Operating and Storage Humidity
Specifies relative humidity for operating and non-operating conditions.
Four Battery Charger Specifications (Model 25310)
Input and Output Voltage
Specifies the rated input and maximum rated output voltage for the charger.
Temperature and Humidity Ranges
Details operating/storage temperature ranges and relative humidity requirements.
Single Battery Charger Specifications (Models 25301, 25302)
Input and Output Voltage
Specifies the rated input and maximum rated output voltage for the single charger.
Temperature and Humidity Ranges
Details operating/storage temperature ranges and relative humidity requirements.
