VDO SENSOR KITAS 2171-0 Datasheet page 2

Sensor
KITAS 2171-0x
Technical Information
Operating voltage
Power consumption
Impulse/revolution
Operating temperature
Storage temperature
Impulse ratio
Connection
Signal shape (Pin 3)
Frequency range
Output signal (Pin 3)
Continental Trading GmbH | Heinrich-Hertz-Strasse 45 | 78052 Villingen-Schwenningen | Germany
E-mail: tachograph@vdo.com | www.vdo.com
6,5 ... 9 V
max. 15 mA
8 (s- und v- impulse)
- 30 °C ... + 120 °C ADR
(T4/Part 4)
A - 40 °C ... + 140 °C
30 - 70 % ... 70 - 30 %
unearthed
rectangular
1 Hz - 1000 Hz
Real-time signal
U L max = 800 mV
(@I = 250 μA)
U H min = UE - 1,5 V
(@I = - 150 μA)
Output short-circuit
Output signal Pin 4
Protection against voltage
interference
Interference protection
Protection
Resistance to vibration
Connection of sensor to
sensor lead
Connection of sensor
to vehicle gearbox
Torque
(wrench size)
Dimensions (L in mm)
Weight approx.
28 V, 1 min
Bidirectional interface
DIN 40 839
DIN 40 839
EN 60529 / IP 69K
10 g
Standard plug accordingto to
ISO 15170
via thread M 22 x 1,5 or
7/8" 18 UNS 2B
max. 50 Nm ± 10 Nm
(WS 27)
approx. 46,5 x 79
135 to 150 g
