Once the machine boots into the Bart PE and you configure the network connection, select Go ->
System -> Storage -> Acronis Backup & Recovery 10 to start.

6.10.2 Connecting to a machine booted from media

Once a machine boots from bootable media, the machine terminal displays a startup window with
the IP address(es) obtained from DHCP or set according to the pre-configured values.
Remote connection
To connect to the machine remotely, select Connect -> Manage a remote machine in the console
menu and specify one of the machine's IP addresses. Provide the user name and password if
these have been configured when creating the bootable media.
Local connection
Acronis Backup & Recovery 10 Management Console is always present on the bootable media.
Anyone who has physical access to the machine terminal can run the console and connect. Just
click Run management console in the bootable agent startup window.

6.10.3 Working under bootable media

Operations on a machine booted with bootable media are very similar to backup and recovery under
the operating system. The difference is as follows:
1. Disk letters seen under Windows-style bootable media might differ from the way Windows
identifies drives. For example, the D: drive under the rescue utility might correspond to the E:
drive in Windows.
Be careful! To be on the safe side, it is advisable to assign unique names to the volumes.
2. The Linux-style bootable media shows local disks and volumes as unmounted (sda1, sda2...).
3. The Linux-style bootable media cannot write a backup to an NTFS-formatted volume. Switch to
the Windows style if you need to do so.
4. You can switch the bootable media between the Windows style and the Linux style by selecting
Tools > Change volume representation.
5. There is no Navigation tree in the media GUI. Use the Navigation menu item to navigate
between views.
6. Tasks cannot be scheduled; in fact, tasks are not created at all. If you need to repeat the
operation, configure it from scratch.
7. The log lifetime is limited to the current session. You can save the entire log or the filtered log
entries to a file.
8. Centralized vaults are not displayed in the folder tree of the Archive window.
To access a managed vault, type the following string in the Path field:
bsp://node_address/vault_name/
To access an unmanaged centralized vault, type the full path to the vault's folder.
After entering access credentials, you will see a list of archives located in the vault.
6.10.3.1

Setting up a display mode

For a machine booted from media, a display video mode is detected automatically based on the
hardware configuration (monitor and graphics card specifications). If, for some reason, the video
mode is detected incorrectly, do the following:
