ViewSonic ViewPad 10pro User Manual page 10

3G SIM Card & Memory Card
SIM card contains your network service details. MicroSD memory card provides
additional data storage space.
To install SIM/microSD card
1. MicroSD only: Open card door.
2. Insert SIM/MicroSD card as shown. Make sure the gold contacts are facing
upward.
3. MicroSD only: Close the card door.
To remove the SIM card
1. Push to reject the SIM card from the slot.
To remove the memory card
1. For safe removal, go to Windows task bar and right mouse click on
Select eject MicroSD card option.
2. After Windows prompts, "The device is now safe to remove" open the card
cover.
3. Push to eject the MicroSD card from the slot.
Note: Do not remove the memory card while it's being accessed. Sudden removal of the memory
card may cause data loss or unpredictable system behavior.
Fig. 2-2 SIM & Micro SD Cards
5
icon.
