- Page 1 ViewPad 10pro User Guide Model No. VS14140...
-
Page 2: Compliance Information
Compliance Information CE Conformity for European Countries The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC. R&TTE Compliance Statement 2200 This wireless module device complies with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/EC). This equipment meets the following conformance standards: EN 301 489 EN 301 489... -
Page 3: Important Safety Instructions
Important Safety Instructions DO NOT place objects on top of the ViewPad, as objects may scratch the screen. DO NOT expose the ViewPad to dirty or dusty environments. DO NOT place the ViewPad on an uneven or unstable surface. DO NOT insert any foreign objects into the ViewPad. DO NOT expose the ViewPad to strong magnetic or electrical field. -
Page 4: Declaration Of Rohs Compliance
Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/ 95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Substance... -
Page 5: Copyright Information
Purchase Date: Product disposal at end of product life ViewSonic respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more. USA & Canada: http://www.viewsonic.com/company/green/recycle-program/ Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/... -
Page 6: Table Of Contents
Table of Contents Chapter 1: Product Overview Package Contents Control Buttons and Connectivity Chapter 2: Setup Power and Battery Memory Card Installation SIM Card Installation and Service Activation Network Setup Chapter 3: Basic Operation Power Up, Standby and Off Appendixes BIOS Menu Indicator Table Troubleshooting... -
Page 7: Package Contents
Copyright © 2011, ViewSonic Corporation. All rights reserved. All trademarks, Support for these products pro- registered or otherwise, are the property of their respective companies. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial reeors or vided by ViewSonic ®... - Page 8 Control Buttons and Connectivity Front Left Right Bottom Ambient Light Sensor Micro SD Card Slot Webcam Reset Search Speakers Return Power Indicator Home Menu Charger Indicator Settings Menu Power Button Charger Jack Hold and Ctrl+Alt+Del Button Earphone Jack Volume DOWN Mini HDMI Output Volume UP USB Port...
-
Page 9: Battery Replacement
Chapter 2: Setup Battery Replacement Battery is permanently fixed to the device. Battery replacement should be performed by an authorized ViewSonic service center. Please contact local ViewSonic customer service for more information. Charging Battery The new battery is only partially charged out of box. To fully charge the battery, please follow the below instruction. - Page 10 3G SIM Card & Memory Card SIM card contains your network service details. MicroSD memory card provides additional data storage space. To install SIM/microSD card MicroSD only: Open card door. Insert SIM/MicroSD card as shown. Make sure the gold contacts are facing upward.
- Page 11 Cellular Data Network (3G Data) Setup Warning: ZTE 3G does not support hot-plug detect. Please make sure the device is powered down when inserting the SIM. Inserting SIM while the device’s power is ON will cause system shutdown. Power down the device. Insert SIM (gold contacts facing up).
- Page 12 Adding a New APN If data connection is unable to establish, manual configuration needs to be performed. Fig. 2-6 Carrier APN is not found Note: This device includes over 700+ worldwide APN settings. If your carrier APN is not in the list, please obtain the following information from your network service provider.
- Page 13 Touch Panel Setup The touch panel of this device has been factory calibrated. In most cases, recalibration is not necessary. However, due to the nature of capacitive touch panel, change of geographical location may require recalibration for the new environment conditions.
-
Page 14: Wifi Setup
WiFi Setup In Windows task bar, left click on to bring up available access point menu. Select the WiFi access point from the available WiFi network list. Enter the password for the network if required. Click on “Connect” to complete the connection. Bluetooth Bluetooth can be configured in the Control Panel. -
Page 15: Control Center
Control Center The control center provides a quick system overall status and communication protocol (3G, WiFi and Bluetooth) setup. Main Menu Fig. 2-10 Control Center, Main Menu Tap on an icon to enter the sub-menu. System Info Battery Thermal Condition Display Power Management Device Controller... - Page 16 System Info Contains OS, BIOS, CPU and HD information. Battery Provide battery status and settings. Fig. 2-11 Battery, Sub-Menu Low Battery Warning Level Setting: Set the slide-bar for low battery level. Select warning notification type OSD (Visual) Warning: Silent Sound Warning: Audible. Save changes.
- Page 17 Display Provide display information and adjustments. Fig. 2-12 Display, Sub-Menu Tap to manually enable external video output (If plug & play is not detected). Adjust brightness level. Power Management Power management options.
- Page 18 Device Controller Fig. 2-13 Device Controller, Sub-Menu Wireless Card: Tap to enable/disable WiFi. Bluetooth: Tap to enable/disable Bluetooth. No function. G-Sensor: Tap to enable/disable G-Sensor. Light Sensor: Tap to enable/disable Light Sensor. Adjust display brightness automatically based on room ambient light condition.
-
Page 19: Chapter 3: Basic Operation
Chapter 3: Basic Operation Power up and off Press on button located at top of device to power up. Warning: Do not turn off the device before it is fully booted or it may cause an error on the next power up. In Windows 7, click Start>Shutdown>... -
Page 20: Virtual Keyboard
Virtual Keyboard Virtual keyboard is located at upper left corner of Windows desktop. Drag the virtual keyboard to center of Windows desktop for keyboard input. Fig. 3-1 Virtual Keyboard in Desktop Virtual keyboard icon will also pop up when enter text input section. Tap on keyboard icon to bring forward the virtual keyboard. - Page 21 Navigation, Front and Side Control Buttons The external buttons have different function in different OS. Button Location BIOS & DOS Windows Bluestacks (Android) Front Up Arrow Open Web Browser Open Web Browser TBD Front Down Arrow Return to Previous Return to Previous Front Go to Desktop Go to Home Desktop...
-
Page 22: Bios Menu
Chapter 4 Appendix Appendix A: BIOS Menu Main Menu Set time and date. Provide following system configuration information. BIOS Version EC Version PCB Version Processor Type Processor Speed System Memory Speed L2 Cache RAM Total Memory Advanced Menu Quick Boot Enable quick boot. - Page 23 Security Menu Supervisor Password Set= Enabled; Clear= No Password. User Password Set= Enabled; Clear= No Password. Set Supervisor Password Highest level password. Set password restriction for Setup utility. Set User Password Set password restriction for Setup utility. Authenticate User on boot Enable startup password control.
-
Page 24: Indicator Table
Appendix B: Indicator Table Power Indicator LED ( , located on the top of device) LED Color Power Status Solid Blue Flashing Blue Sleep Battery Indicator LED ( , located on the top of device) LED Color Battery Status Solid Amber Charging Solid Blue Battery Full... -
Page 25: Troubleshooting
Appendix C: Troubleshooting Symptom Possible Causes Remedy Touch 1. Environmental conditions are Perform touch screen panel is not significantly different from factory recalibration. functioning default. properly 2. Touching surface does not provide - Ensure finger is dry and sufficient electrical charge. clean. - Page 26 External 1. Damaged or low quality HDMI Change HDMI cable. display not cable working 2. Output resolution and frame rate Use a display that supports is not support by the connected the selected output display resolution and frame rate. System locks Multiple possible causes: Windows Push reset button to code, Intel device failure, device...
-
Page 27: Customer Support
Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America (Peru) www.viewsonic.com/la/ T= 0800-54565 soporte@viewsonic.com... -
Page 28: Limited Warranty
How long the warranty is effective: ViewSonic ViewPad are warranted for at least 1 year for labor from the date of the first customer purchase. User is responsible for the back up of any data before returning the unit for service. - Page 29 Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages...
