PPA55xx series
START UP GUIDE
Firmware v2_105

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPA5530 and is the answer not in the manual?

Questions and answers

Related Manuals for Newtons4th PPA5530

Summary of Contents for Newtons4th PPA5530

  • Page 1 PPA55xx series START UP GUIDE Firmware v2_105...
  • Page 3 Model: PPA55xx Family Conforms to the requirements of Council Directives: 89/336/EEC relating to electromagnetic compatibility: EN 61326:1997 Class A 73/23/EEC relating to safety of laboratory equipment: EN 61010-1 April 2006 Eur Ing Allan Winsor BSc CEng MIEE (Director Newtons4th Ltd.)

  • Page 4: Table Of Contents

    PPA55xx Quick User Guide CONTENTS Contents ..............Page.1 Getting Started..........Page.2 Unpacking and Contents........Page.2 Handle Fitment..........Pages.3-4 Safety............. Page.5 Safety Instructions........... Page.5 Cautions............Page.6 Warranty............Page.7 Front Panel Layout Diagram....... Page.8 Front Panel Display Key Functions...... Pages.9-28 Rear Panel Layout Diagram........ Page.29 Basic Key Operation..........

  • Page 5: Getting Started

    PPA55xx Quick User Guide Getting Started Unpacking When you receive your product, check that the following items are included for the appropriate PPA. Refer to the contents list below for each model. If any item is missing or damaged during transportation, immediately contact your local sales distributor or N4L office CONTENTS Start...
  • Page 6 PPA55xx Quick User Guide 1.2 Fitment of the PPA series Carry/Tilt handle PPA5/15/45/55 series power analyzers are supplied with a Carry/Tilt Handle that is located within the accessory pack.............. The handle allows a user to position the instrument upwards at one of two angles for easier viewing when the instrument is positioned below the line of sight.
  • Page 7 Correct 3 Correct 4 A correctly fitted handle will have the ‘N4L Newtons4th’ wording in the correct reading plane when the handle is to the front of the instrument (Pic. 3) Also, a correctly fitted handle will allow storage under the unit (Pic. 4)

  • Page 8: Safety

    There are no user serviceable parts inside the instrument – do not attempt to • open the instrument, refer service to the manufacturer or his appointed agent Note: Newtons4th Ltd shall not be liable for any consequential damages, losses, costs or expenses arising from the use or misuse of this product however caused...

  • Page 9: Cautions

    PPA55xx Quick User Guide 2.2 CAUTIONS Do not use a damaged power cord or cables • Doing so may cause an electric shock or a fire Do not place any object on this instrument • Do not use this instrument if faulty •...

  • Page 10: Warranty

    36 months from the date of purchase In the unlikely event of a problem within this guarantee period, first contact Newtons4th Ltd or your local representative to give a description of the problem. Please have as much relative information to hand as possible – particularly the serial number and release number these can be found by pressing the SYSTEM button then the “Left Arrow”...

  • Page 11: Front Panel Layout Diagram

    PPA55xx Quick User Guide Front Panel Layout 1. Display Screen 2. Screen Display Function Buttons 3. Power Analyzer Mode Buttons 4. Handle 5. Measurement Control Function Keys 6. Rubber Feet 7. Menu Selection and Cursor Controls 8. Measurement Settings Buttons 9.
  • Page 12 PPA55xx Quick User Guide 3.1 PPA55xx Display Key Functions Key & Sub Categories Description Acquisition Control: Used configuring inputs ACQU appropriate to source and nature of signals being Wiring: analyzed In single phase 1 configuration, (phase 2 & phase 3) Single Phase 1 inputs are disabled and the selected phase acts as a completely independent single phase power analyzer...
  • Page 13 PPA55xx Quick User Guide In normal acquisition mode the window over which the measurements are computed is adjusted to give an integral number of cycles of the input waveform. The results from each window are passed through a Speed smoothing filter. There are 5 pre set speed options that adjust the nominal size of the window, and therefore the update rate and time constant of the filter.
  • Page 14 PPA55xx Quick User Guide Smoothing Response The smoothing response is by default set to “auto reset” where the filtering described in “smoothing” is reset in response to a significant change in data such Auto Reset as frequency, voltage and current levels. This speeds up the response of the instrument to changing conditions Auto reset can be disabled so that the filtering has a...
  • Page 15 PPA55xx Quick User Guide A parallel digital frequency filter of low-pass may be selected to filter out the HF carrier component of a PWM waveform ensuring measurements are carried Frequency Filter out on the fundamental frequency, further filter settings for PWM waveforms can be found within the APP/PWM section (page 15) No frequency filter selected Switches On frequency filter (4kHz)
  • Page 16 PPA55xx Quick User Guide In a very noisy application, where the frequency of the signal is known but the instrument is unable to Frequency Lock measure the frequency even with PWM filters or low frequency mode filters applied, it is possible to manually enter the frequency to be used for analysis Utilises N4L unique signal processing techniques for Normal...
  • Page 17 PPA55xx Quick User Guide The bandwidth setting dictates the frequency range of Bandwidth the instrument. This selection sets an inline analogue filter as per the selection Wide bandwidth will offer the full range of frequency Wide (dc - 2MHz) components available for analysis Low bandwidth may be useful in noisy applications for example where...
  • Page 18 PPA55xx Quick User Guide In signal processing, a “FILTER” is a device or process that removes from signal some unwanted Noise Filter component or feature. The noise filter is a digitally selectable in line filter which will alter the bandwidth of the processed signal Select to switch this mode off Select to switch this mode on...
  • Page 19 PPA55xx Quick User Guide RANGE Input channel options Voltage Input The internal voltage attenuator selects the 4mm Internal connections on the rear of the instrument and has a max input of 3000Vpk An External Sensor / Shunt can be connected to the instrument which will...
  • Page 20 PPA55xx Quick User Guide Current Input internal current shunt selects connections on the rear of the instrument. Max Apk is Internal dependent upon model type; LC (10A rms), Standard (30A rms) or HC (50Arms) An External Shunt can be connected to the instrument which will give the operator more versatility in selecting the Input range required.
  • Page 21 PPA55xx Quick User Guide DATALOG Interrogation and extraction of information resulting Datalog from a test log in a specified time scale and at a set speed Disabled No memory selected Instruments internal memory selected data storage, this offers the fastest performance Internal Flash Utilises 200MB (PPA45xx) or 1GB (PPA55xx) internal memory...
  • Page 22 PPA55xx Quick User Guide Electronic lighting ballast waveforms consist of a high frequency carrier signal modulated line frequency. instrument measures line frequency independently of input waveform frequency and synchronises the measurement period line frequency. carrier frequency Lighting Ballast measurement ignores any "dead band" around the zero crossing of the ac line to compute the actual switching frequency of the ballast.
  • Page 23 PPA55xx Quick User Guide Large power transformers operate at very low power factor (<0.01) and the phase accuracy is critical to measure the losses. Power transformer application mode sets the configuration options to the optimum Transformer Mode for phase accuracy e.g. AC+DC coupling range lock across phases.
  • Page 24 PPA55xx Quick User Guide This mode is used for IEC61000 testing. Results can Harmonics / Flicker be obtained directly from the instrument or preferably via IECSoft software Select between IEC61000-3-2 Harmonics or Harmonics / Flicker IEC61000-3-3 Flicker test to be carried out All default parameters will be selected when “ENTER”...
  • Page 25 PPA55xx Quick User Guide Alarm 2 Data Alarm on selected parameter and thresholds Zoom 1 Zoom 1 parameter selected for alarm threshold Zoom 2 Zoom 2 parameter selected for alarm threshold Zoom 3 Zoom 3 parameter selected for alarm threshold Zoom 4 Zoom 4 parameter selected for alarm threshold Alarm Type (Alarm 2)
  • Page 26 PPA55xx Quick User Guide Screen Print Disabled No Screen print option selected RS232 Print screen via RS232 Cable i.e. to printer USB Memory Stick Print screen directly onto USB memory stick Master / Slave Select if 2 x PPA55xx units are to be used as a PPA5540/50/60 Disabled Master / Slave configuration disabled...
  • Page 27 PPA55xx Quick User Guide Measurements of Phase can be expressed in one of Phase Convention three formats: -180⁰ to +180⁰ Commonly used in circuit analysis 0⁰ to -360⁰ Commonly used in power applications 0⁰ to +360⁰ Select as required Keyboard Beep Audible sound when keys are pressed Disabled Audible sound disabled...
  • Page 28 PPA55xx Quick User Guide ← System The information given in this section cannot be changed by the user Information Serial Number Instruments unique serial number Manufacturing Code Code attributed to build date of instrument Main Release Current firmware release installed in instrument DSP Release Digital Signal Processing release version FPGA Release...
  • Page 29 PPA55xx Quick User Guide The HARM mode of the PPA computes multiple DFTs on the input waveforms in real time. There are two modes of operation: difference THD, and series harmonics. Series harmonic mode includes options for THD, TIF, THF, TRD, TDD and phase. There is also an Harmonic Analyzer option of a series harmonic bargraph display which shows both the voltage and current harmonics...
  • Page 30 PPA55xx Quick User Guide Increase font size on selected parameters on display ZOOM + screen Decrease font size on selected parameters on display ZOOM - screen Press Real Time to return to the display screen and REAL TIME see all data in real time. Pressing the real time button will also put the display screen into hold mode Press Table to view results either during or at the TABLE...
  • Page 31 PPA55xx Quick User Guide STOP Stop button will stop any Datalog ZERO Zero button will reset the inputs to zero Trigger returns display screen back to real time from a hold command. Also triggers a single shot in SCOPE TRIGGER mode, all trigger settings can be found by pressing the “scope”...

  • Page 32: Rear Panel Layout Diagram

    PPA55xx Quick User Guide Rear Panel Layout 1. Voltage & Current External Analogue Inputs 2. Voltage & Current Internal Inputs 3. Mains Supply Inlet 4. Communication Ports 5. Auxiliary Ports 6. Master / Slave Connection Port Page 29...

  • Page 33: Basic Key Operation

    PPA55xx Quick User Guide Basic Key Operations This chapter is designed to help the user familiarise themselves with the instrument by setting up some basic functions 5.1 SET UP FOR POWER ON Install Equipment Installation of Equipment Plug in and turn on power Power Supply Connection 5.2 SETTING THE TIME Power Analyzer Default Screen Appears...

  • Page 34: Adjusting The Screen Brightness

    PPA55xx Quick User Guide 5.3 SET THE DATE Press Flashing Red Cursor moves to Date Use Numerical keys Set Date within Flashing Box Press Enter Key Numerical Day of Month is set Press Flashing Red Cursor moves to Month Press Month Calendar Opens Press Select Month to be entered...
  • Page 35 PPA55xx Quick User Guide Now that you have familiarised yourself with the instruments keypad we can complete this section by filling in the User Data Information 5.6 USER DATA Press “SYS” Key System option screen opens Press User settings screen appears Press Red cursor moves to supervisor access Press...

  • Page 36: Wiring

    PPA55xx Quick User Guide PPA55xx Quick User Guide N4L Power Analyzers cover 1 to 3 phase applications in one instrument depending upon the model and up to 12 phases via N4L’s PPALoG software application in both low and high current models. Each phase input has wide ranging voltage and current channels which are fully isolated from each other and from ground.
  • Page 37 PPA55xx Quick User Guide Two Phase Two Wattmeter Configuration Three Phase Two Wattmeter Configuration Three Three Phase Phase Source Load Three Phase Three Wattmeter - simulated neutral configuration Three Three Phase Phase Source Load Page 34...
  • Page 38 PPA55xx Quick User Guide Three Phase Three Wattmeter – Star Connections Three Three Phase Phase Source Load To configure PPA55xx to calculate the correct phase power when the Load topology is in a Star Configuration; Access “Power Analyzer” mode either through the “Mode” or the “POWER” button as per the screenshot below Press 7 times until red box surrounds “conversion”...
  • Page 39 PPA55xx Quick User Guide Three Phase Three Wattmeter– Delta Connections Three Three Phase Phase Source Load To configure PPA55xx to calculate the correct phase power when the Load topology is in a Delta Configuration; Access “Power Analyzer” mode either through the “Mode” or the “POWER” button as per the screenshot below Press 7 times until red box surrounds “conversion”...

  • Page 40: Start Up

    PPA55xx Quick User Guide 6.2 START UP Once connected, power on instrument analyzers factory default settings from memory location 0 will be displayed as per Fig 1, Note these can be altered to your own desired settings (see the User Data section under System...

  • Page 41: Zoom Functions

    PPA55xx Quick User Guide 6.3 ZOOM FUNCTION Within the Power screen you are able to select up to 4 measurements that can be made more prominent from the rest, these can be selected and changed by the user as required To select or change any zoom measurement Action Result...
  • Page 42 PPA55xx Quick User Guide Zoom + Press Zoom+ to display the 4 selected zoomed measurements as shown Note: These will be displayed in the order they were selected Fig 3 Pressing Zoom+ again will display only first selected zoomed measurements as shown in (Fig 4) Fig 4 Press ZOOM- button to revert real time display back to all measurement parameters...

  • Page 43: Speed & Smoothing

    PPA55xx Quick User Guide 6.4 SPEED AND SMOOTHING Within this section we will look at how the speed and smoothing parameters set within the Acquisition menu affect the measurement results NOTE: All measurement windows must have an integral number of cycles within it to calculate correct RMS and Harmonics Input = 50Hz Sine Wave Amplitude = 1Vpk &...
  • Page 44 PPA55xx Quick User Guide Fig 7 displays the table of results from the graph in (Fig 6); we can see that voltage step immediately recorded after 0:01:17 Fig 7 The next sets of screenshots are for the same set up but with smoothing activated Selecting smoothing will take the data and apply the equivalent of a...
  • Page 45 PPA55xx Quick User Guide The resulting graph and results table with smoothing applied are displayed within (Fig’s 9 and 10) Fig 9 Fig 10 The displays above show how with smoothing applied, the data is smoothed out over the resultant timescale and displaying an intermediate value for every update window during the step between the two peak voltage values Note: each speed parameter has its own time constant for smoothing and data updates as shown in the table below...

  • Page 46: Efficiency

    PPA55xx Quick User Guide 6.4.1 EFFICIENCY The “Efficiency” mode will compute and compare the data results from any of the configurations shown within (Fig 11) To select the “Efficiency” parameter from any application mode. Access the Power Analyzer home screen and press “POWER” this will take you into a sub menu (Fig 11).

  • Page 47: Application Modes

    PPA55xx Quick User Guide 6.5 APPLICATION MODES Within this section we will look at all the different application modes selectable from within the PPA55xx APP MENU, with the aid of screenshots and instructions. To select your measurement application you will need to activate the “APP” button.

  • Page 48: Pwm Motor Drive Mode

    PPA55xx Quick User Guide 6.5.1 PWM MOTOR DRIVE MODE The nature of the waveforms produced in a PWM motor drive application makes measurement of the fundamental frequency difficult. In this section we will look at the switching and fundamental frequencies and how frequency lock and filters will allow the correct measurements to be displayed on such a complex waveform Test device: 1 x Inverter/Motor test unit (set at 65Hz)
  • Page 49 PPA55xx Quick User Guide To access PWM motor drive mode: (Fig 15) Press “APP” button Press Red Box will surround “Mode” Press Key. This will open the drop down menu selections Press Key until red box surrounds PWM motor drive Fig 15 Press “ENTER”...
  • Page 50 PPA55xx Quick User Guide Note: Do not select a filter too close to the fundamental frequency this may result in the frequency measurement reading 0Hz Setting the frequency filter: Press 2 times Frequency filter parameter will be selected Press Drop down box will open with all available frequency ranges Press arrows to select...
  • Page 51 PPA55xx Quick User Guide By viewing the waveforms in the Oscilloscope mode (Fig 19) we can see the switching frequency of the Voltage and a smoother sine wave Current waveform The Current waveform shows the time for 1 cycle approximately 15.40ms −3 Therefore 1s ÷...
  • Page 52 PPA55xx Quick User Guide Torque & Speed: Set the Torque and Speed parameters to measure the Mechanical Power (Nm) and Speed (RPM) via the Torque and Speed BNC connectors on the rear of the instrument Open up the torque and speed drop down box to select which type of test is to be configured Fig 20...

  • Page 53: Lighting Ballast Mode

    PPA55xx Quick User Guide 6.5.2 LIGHTING BALLAST MODE Select Lighting Ballast mode from the Application Menu previous applications (Fig 22) Fig 22 Press to default settings. Press “ENTER” to load Once selected you now have the option select frequency tracking speed and the efficiency calculation Fig 23 Page 50...

  • Page 54: Inrush Current Mode

    PPA55xx Quick User Guide 6.5.3 Inrush Current Mode Test Device: 230v, 50Hz Ventilation Fan (Imax 0.8A) Accessories: 1 x PCIS Inrush Switch 1 x Break Out Box Inrush Current Mode (Surge) will allow the user to capture the highest peak value of Current as soon as any load is switched on.
  • Page 55 PPA55xx Quick User Guide Minimum Range: Press Minimum Range parameter will be selected (Instrument will not range below this value irrespective of input signal) Press Drop down box will open with all available Current ranges Press arrows to select minimum range parameter required Press “ENTER”...
  • Page 56 PPA55xx Quick User Guide Once all settings are configured return to the “MODE” app where the +ve peak and –ve peak parameters can be set to appear within the real time display screen Press “MODE” Key Press Key until red box surrounds peak Press Drop down box will open...
  • Page 57 PPA55xx Quick User Guide Zoomed parameters as in (Fig 32) can now be used to capture the Inrush Current (Surge) data within a Datalog Fig 32 Configure Datalog application settings to allow all data to be captured on enabled parameters (Remember these will be displayed in the order they were selected)

  • Page 58: Transformer Mode

    PPA55xx Quick User Guide 6.5.4 Transformer Mode (Single Phase) The Transformer mode in the PPA is ideal for both single phase and three phase transformer analysis, we will first describe general operation with a single phase device and then move on to describe three phase measurements. Test device: 1 x Single Phase Transformer, ratio (1:1) Accessories: 1 x Break out Box Transformer Mode will allow the user...
  • Page 59 PPA55xx Quick User Guide You are now required to set the wiring configuration for the transformer. Press “ACQU” button which will bring up the “ACQUISITION CONTROL” screen. Press the down arrow once so the red box flashes around the wiring selection; press the right arrow to open up the drop down menu as seen in (Fig 37) Use the up and down arrows to select...
  • Page 60 PPA55xx Quick User Guide The Voltage and Current measurements displayed within the Blue Box in (Fig 38) reflect the auto ranging configured by selecting the default settings within the instruments application home set up screen (Fig 36) Viewing the data (Fig 38) the phase angle of the fundamental is shown as 77.62⁰.
  • Page 61 PPA55xx Quick User Guide Press “ENTER” to confirm selection Press “ENTER” to return to home screen and view measurements From the “auto” screen (Fig 39) you can now see that we have a Resistive component affecting the purity of the transformer From the Inductance and Resistance readings the instrument will calculate...
  • Page 62 PPA55xx Quick User Guide Transformer Mode (Three Phase) When performing analysis of a 3 Phase load, transformer mode is extremely useful. The PPA will display phase balance information in an intuitive manner without the requirement for a vector display, this has the advantage of maintaining 5 digit resolution which is not possible whilst attempting to visually interpret phase balance on a conventional vector display.

  • Page 63: Standby Power Mode

    PPA55xx Quick User Guide 6.5.5 STANDBY POWER MODE Power Standby mode will show all power measurements from a device which is in standby mode To access standby mode: (Fig 43) Press “APP” button Press button Press button. This will open the drop down menu selections Press 5 times until red box...
  • Page 64 PPA55xx Quick User Guide Test device: 1 x Stand alone Heater Accessories: 1 x Break Out Box (Fig 45) shows a screenshot from Power Analyzer home screen with the test device in standby mode Fig 45 (Fig 46) screenshot is taken from the “RMS”...
  • Page 65 PPA55xx Quick User Guide (Fig 47) is taken from the power integrator screen, displaying minute integration of the power being consumed Fig 47 Press “SCOPE” button to view the Voltage and Current waveforms being produced device under test. (Fig 48) Fig 48 Page 62...

  • Page 66: Calibration Mode

    Calibration Mode is to be used in combination with N4LCal (N4L Calibration software) which facilitates performing manual calibration with an external source. This software is supplied with a detailed manual describing the calibration process, for more information contact N4L on the following email; support@newtons4th.com Page 63...

  • Page 67: Oscilloscope Mode

    PPA55xx Quick User Guide 6.5.7 OSCILLOSCOPE MODE The PPA55xx provides a digital storage oscilloscope function in order to view the waveforms being measured. The settings for the oscilloscope are configured by pressing the “SCOPE” button twice Upon entering the “SCOPE” menu, the following screenshot will be displayed Timebase: The display for the oscilloscope is divided into 10 divisions along the time axis with the selected timebase displayed in the bottom left hand corner of...
  • Page 68 PPA55xx Quick User Guide Trigger Mode: The trigger mode may be set to be; Auto (trigger if possible but do not wait) Normal (wait indefinitely for trigger) Single shot (wait for trigger then hold) The single shot option is reset using the “TRIGGER” key Trigger Polarity: The trigger polarity may be set to rising edge or falling edge Trigger HF Reject:...
  • Page 69 PPA55xx Quick User Guide Screenshot from Scope display with “Dual” cursors configured From the screenshot above the display shows all fundamental measurements from the position of cursor 1. Also displayed is the time difference between the 2 cursors, “delta t” = 26.00ms with the timebase set to 10ms/div Trace: Set which waveform the user wishes to be displayed at any one time from the 4 options within the drop down menu...
  • Page 70 PPA55xx Quick User Guide Trace set to Voltage: Trace set to Current: Trace set to Dual: Trace set to Together: Page 67...

  • Page 71: Harmonics / Flicker Mode

    IEC61000-3-3 Flicker test – For use with IECSoft software IECSoft software is intuitive software that guides the user through the Harmonics and Flicker test applications. More information can be found by downloading the IECSoft guide from the N4L website www.newtons4th.com Page 68...

  • Page 72: Aircraft Tvf105 Mode

    PPA55xx Quick User Guide 6.5.9 AIRCRAFT TVF105 MODE The Aircraft TVF 105 application must be configured and run in conjunction with N4L software PPALog Connect the PPA with the software according to the following steps Step 1. Connect the PPA5500 to PPALog 3.1b or above Enter the Harmonics mode and select;...
  • Page 73 PPA55xx Quick User Guide Step 2. Select; Mode: Extended Frequency Range Step 3. Select; Harmonic Series up to: 7500 Page 70...
  • Page 74 PPA55xx Quick User Guide Step 4. Select; Set up PPA button Step 5. Select; APP Button Page 71...
  • Page 75 PPA55xx Quick User Guide Step 6. Select: Mode: Aircraft TVF105 Step 7. Select: Start Button Page 72...
  • Page 76 PPA55xx Quick User Guide Step 8. Wait for test to complete (approx 30 mins) Select Export button and Export to Excel Page 73...

  • Page 77: Hf Current Shunts

    PPA55xx Quick User Guide 6.5.10 HF Current Shunts External current shunts can be used as an alternative to the instruments internal shunt as a fixed value Impedance circuit. Note do not use both shunts together Test equipment for demonstration: 1 x Inverter/Motor test unit (single phase) 1 x HF 003 Current Shunt (shunt resistance = 470mΩ) Wiring Configuration: Connect BNC safety lead between the “A EXT”...
  • Page 78 PPA55xx Quick User Guide Press “RANGE” button Press arrow until black box surrounds the current input parameter Press arrow and select “external shunt” Press “ENTER”, external shunt will now be selected Press arrow until black box surrounds the shunt parameter Manually input the shunt resistance value Press “ENTER”, external shunt value will now be selected Fig 49...
  • Page 79 PPA55xx Quick User Guide Rogowski Coil Set the range value of the PPA55xx to the selected channel the Rogowski Coil is connected to, input the correct shunt value corresponding switch value Rogowski Transducer, within (Fig 51) the shunt value is set to 2mΩ to reflect the switch position being set to 1KA (2mV per A) and a scale factor of 1:1 Fig 51...
  • Page 80 PPA55xx Quick User Guide 15 Way Connector WR5000 Wideband Rogowski Transducer Fault 5KA (0.4mv/a) 1KA (2.0mv/a) DC Input BNC – BNC safety lead WARNING: Remember to connect either the Internal or External shunt only to the PPA55xx Page 77...
  • Page 81 PPA55xx Quick User Guide Connect up the Rogowski Coil as shown, wrap the clear plastic tube around the conductor and slot into the “T”piece connector, tighten the connector nut to secure the lead into position A single coil wrapped around the conductor will result in voltage measurement equal to the 2mV/A detail on the WR5000 as set on previous page If the coil is double wrapped around the conductor then the voltage value will double accordingly...

  • Page 82: Remote Settings

    PPA55xx Quick User Guide Remote Settings The Remote Settings menu provides an interface for the user to set the method of connection and the ability to configure the ports as required Resolution The default resolution setting for the PPA55xx is “Normal” this will set the Data Resolution to 5 decimal points plus any exponent eg: +1.2345+E00 Selecting “High”...
  • Page 83 PPA55xx Quick User Guide Selecting RS232 will then open up the “Baud Rate” option. Select applicable data speed rate from the 4 options given in the drop down menu (Default Setting is 19200) To use a USB lead to connect, set the interface parameter to read “USB”...
  • Page 84 PPA55xx Quick User Guide Configuring the instruments interface to GPIB will automatically set the IEEE address to 23 this can be changed within address parameter in the range 0 to 30 total possible addresses available) Recall with Program The recall with program parameter will allow Comms...

  • Page 85: Transferring Internal Datalogs To Usb Memory Stick

    PPA55xx Quick User Guide Transferring Internal Datalogs to USB memory stick The following section explains the procedure for storing a datalog to internal memory and exporting the data to a USB memory Stick 1. Setup Datalog (DATALOG MENU) 2. Press START to commence Datalog Page 82...
  • Page 86 PPA55xx Quick User Guide 3. Store Datalog to Internal memory Fig 52 4. Store Datalog to External USB Memory Stick 5. Locate file on memory stick, the file format will have a .txt extension D001 represents “location 1” as specified in (Fig 52) above. 6.

  • Page 87: Program Store / Recall / Delete

    PPA55xx Quick User Guide Program Store / Recall / Delete The following section explains the procedure for storing / recalling or deleting a program to or from the instruments internal memory or USB memory Stick 1. Press “PROG” button to open up program store / recall mode 2.
  • Page 88 PPA55xx Quick User Guide 3. Select which data type you require to be actioned from the list shown 4. Select the action to be taken in association with the data selected Page 85...
  • Page 89 PPA55xx Quick User Guide 5. Select the location that the associated action is to be recalled from, stored to or deleted from, there are 999 locations available NOTE: Location 0 = FACTORY DEFAULT and cannot be changed Location 1 = Upon start up should any program be stored within program 1 then the PPA will automatically recall this program 6.
  • Page 90 PPA55xx Quick User Guide 7. Upon implementing any of the above actions then remember to scroll down to “EXECUTE” and press “ENTER” to validate your selection / action Page 87...

  • Page 91: Repair / Recalibration

    In the event of any problem with the instrument, during or outside of the guarantee period, contact your local representative Newtons4th Ltd offer a full repair and re-calibration service It is recommended that the instrument be re-calibrated annually Contact details: 1.
  • Page 92 PPA55xx Quick User Guide PPA45xx / PPA55xx GUIDE FOR TESTING THE BASIC FUNCTIONALITY OF THE INSTRUMENT. This document provides instructions on how to test the basic functionality of your Precision Power Analyzer in order to ensure it has a basic level of functionality; this should be used as a pre cursor to any further fault investigations.
  • Page 93 PPA55xx Quick User Guide RESETTING THE PPA TO FACTORY DEFAULT MODE. This will clear any user defined programs that might be stored in the PPA and recalled when the instrument is switched on. Program 1 is recalled when the PPA is restarted..
  • Page 94 PPA55xx Quick User Guide Coupling. Press “COUPLING” button Press Key until Red Box surrounds the “Coupling” options Use the buttons to select “ac+dc” from the drop down list. Press Key until Red Box surrounds the “Bandwidth” options Use the buttons to select “wide (dc-2MHz)”...
  • Page 95 PPA55xx Quick User Guide Press Key until Red Box surrounds the “attenuator” options Type in an attenuator setting of 1.0000:1 Press Key until Red Box surrounds the “Current input” options Use the buttons to select “external shunt” from the list. Press Key until Red Box surrounds the “shunt”...
  • Page 96 PPA55xx Quick User Guide Connecting up the PPA to a signal Generator A signal generator is required to provide a 1.41V PK (1.00Vrms) 50Hz sine wave, if the signal generator expects a 50Ohm load impedance then an output voltage of 0.707V (0.5Vrms) should be used.
  • Page 97 PPA55xx Quick User Guide Connection diagram for the functionality checks of the External BNC inputs. Page 94...
  • Page 98 PPA55xx Quick User Guide Screenshots of PPA Display when making “external” measurements. Oscilloscope Mode The above screenshots of the scope mode display current and voltage for all 3 phase inputs. Use the ENTER/NEXT button to scroll through the various oscilloscope displays.
  • Page 99 PPA55xx Quick User Guide True RMS Voltmeter Mode These screenshots are of the instrument in True RMS Voltmeter mode. The one on the left is displaying the voltage results for all 3 phases whilst the one on the right is displaying current for all 3 phase inputs. These allow comparisons of current and voltage readings between the 3 phases.
  • Page 100 PPA55xx Quick User Guide Power Analyzer Mode The above screenshots are of the instrument in Power Analyzer mode. The screenshot on the left is displaying the results for all 3 phase inputs. The screenshot on the right is the results for phase 1 only. Comparison of current, power and voltage can be made on all 3 phases and it is also possible to check that the instrument has detected the correct frequency.
  • Page 101 PPA55xx Quick User Guide These screenshots show the instrument in Harmonic Analyzer mode with a square wave input. Comparisons can be made of Current, Power, Voltage and Total Harmonic Distortion on all 3 phases. When looking at a single channel it is also possible to check the frequency of the signal.
  • Page 102 PPA55xx Quick User Guide Setting up PPA for “internal” measurements. The set up procedure for internal measurements is very similar to that above for external measurements. The only difference is in the configuration of the Ranging settings. Ranging should be set up as follows: Press “RANGE”...
  • Page 103 PPA55xx Quick User Guide Connecting up the PPA for “internal” measurements. The breakout box is connected to a mains supply. A load is connected to the breakout box to produce a current for the PPA to monitor. The PPA is used to monitor the voltage and current on the connections of the breakout box.
  • Page 104 PPA55xx Quick User Guide Connection diagram for the functionality checks of the Internal 4mm sockets inputs. Page 101...
  • Page 105 PPA55xx Quick User Guide Screenshots of PPA Display when making “internal” measurements. The following screenshot examples were taken with the PPA set up for internal measurements. For full descriptions for each of the PPA modes please refer to the “external” measurements section. Oscilloscope Mode Page 102...
  • Page 106 PPA55xx Quick User Guide True RMS Voltmeter Mode Power Analyzer Mode Page 103...
  • Page 107 PPA55xx Quick User Guide Harmonic Analyzer Mode Harmonic verification Verify that Vthd is nominally the same across all phases inputs, as a reference signal (such as a squared wave) is not being used we cannot verify individual harmonic magnitudes. This is not a problem as we have already verified this with the external inputs Page 104...
  • Page 108 Incorrect frequency detection Incorrect Harmonic magnitude Possible damage to analogue input internal input circuitry Incorrect frequency detection If you find any of the faults described above, please contact Newtons4th Ltd or alternatively your local distribution office. Email: support@newtons4th.com Page 105...

  • Page 109: Specifications

    PPA55xx Quick User Guide Specifications Frequency Range LC & Standard Version DC and 10mHz to 2MHz HC Version DC and 10mHz to 1MHz Voltage Input Internal Input: 300mVpk to 3000Vpk (1000Vrms) in 9 ranges Ranges 20% over-range ability maintains 300Vpk range with 240Vrms 0.01% Rdg + 0.038% Rng + (0.004% x kHz) + Accuracy...
  • Page 110 PPA55xx Quick User Guide Phase Accuracy: LC & Standard Version 0.005deg + (0.01deg x kHz) HC Version 0.01deg + (0.02deg x kHz) Power Accuracy: [0.03% + 0.03%/pf +(0.01% x kHz)/pf] Rdg + 0.03%VA Rng [0.02% + 0.03%/pf +(0.01% x kHz)/pf] Rdg + 40-850Hz 0.02%VA Rng DC Accuracy...
  • Page 111 PPA55xx Quick User Guide Common Mode Rejection Total Common Mode and Noise effect on current channels Applied 250V @ 50Hz – Typical 1mA (150dB) Applied 100V @ 100kHz – Typical 3mA (130dB) Torque and Speed Analogue Accuracy Range: +/- 10V Analogue Bipolar Accuracy: 0.05% Rdg + 0.05% Rng Torque and...
  • Page 112 PPA55xx Quick User Guide Ports RS232 Baud rate to 38400 – RTS/CTS flow control 10/100 base-T Ethernet auto sensing RJ45 GPIB IEEE488.2 compatible USB device – 2.0 and 1.1 compatible Analogue Bipolar +/- 10V Speed BNC bipolar +/- 10V or pulse count Torque BNC bipolar +/- 10V or pulse count Sync...
  • Page 113 PPA55xx Quick User Guide Comparisons Model PPA15xx PPA45xx PPA55xx Item USB Port on front Colour Display Speed and Torque Standard GPIB, LAN Standard IEC61000 Standard Current Options 20, 30 10,30,50 10,30,50 Bandwidth 1MHz 2MHz 2MHz V&I Accuracy 0.05 + 0.1 0.03 + 0.04 0.01 + 0.038 W Accuracy...
