V50S, V50SH, and VFB50NC Vent-Free Fireboxes
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result caus-
ing property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
This appliance may be installed in an aftermarket*, permanently located, manufactured
(mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance
is not convertible for use with other gases.
*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
Save this manual for future reference.
Save this manual for future reference.
UNVENTED (VENT-FREE)
UNIVERSAL FIREBOX
TM
OWNER'S OPERATION AND
INSTALLATION MANUAL
WARNING: Improper installation, ad-
justment, alteration, service, or main-
tenance can cause injury or property
damage. Refer to this manual for cor-
rect installation and operational pro-
cedures. For assistance or additional
information consult a qualified installer,
service agency, or the gas supplier.
WARNING: FOR USE ONLY WITH A
LISTED DECORATIVE TYPE UNVENTED
ROOM HEATER. DO NOT BUILD A
WOOD FIRE.
This firebox has been tested and ap-
proved by CSA International under
Z21.91-2001 for use with approved
ANSI Z21.11.2 decorative type
unvented room heater.
Advertisement
Table of Contents
Related Manuals for Desa V50S
Summary of Contents for Desa V50S
- Page 1 For more information, visit www.desatech.com For more information, visit www.desatech.com V50S, V50SH, and VFB50NC Vent-Free Fireboxes WARNING: If the information in this manual is not followed exactly, a fire or explosion may result caus- ing property damage, personal injury, or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION TABLE OF CONTENTS SAFETY INFORMATION ... 2 LOCAL CODES ... 3 PRODUCT FEATURES ... 3 LOCATING FIREBOX ... 3 PRODUCT SPECIFICATIONS ... 4 AIR FOR COMBUSTION AND VENTILATION ... 5 INSTALLATION ... 8 SAFETY INFORMATION WARNINGS IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or... -
Page 3: Safety Information
SAFETY INFORMATION Continued Do not use this firebox as a wood-burning fireplace. Use only decorative unvented room heaters (log sets). Do not add extra logs or ornaments such as pine cones, vermicu- lite, or rock wool. Using these added items can cause sooting. Use only the provided hood, or appropriate hood accessory. -
Page 4: Product Specifications
PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS Firebox Top View Side View Front View Figure 1 - Firebox Dimensions For more information, visit www.desatech.com For more information, visit www.desatech.com 110749-01A... -
Page 5: Air For Combustion And Ventilation
AIR FOR COMBUSTION AND VENTILATION WARNING: This firebox shall not be installed in a confined space or unusually tight construction un- less provisions are provided for adequate combus- tion and ventilation air. Read the following instruc- tions to insure proper fresh air for this and other fuel- burning appliances in your home. - Page 6 AIR FOR COMBUSTION AND VENTILATION Determining Fresh-Air Flow For Heater Location AIR FOR COMBUSTION AND VENTILATION Continued DETERMINING FRESH-AIR FLOW FOR FIREBOX LOCATION Determining if You Have a Confined or Unconfined Space Use this work sheet to determine if you have a confined or unconfined space. Space: Includes the room in which you will install heater plus any adjoining rooms with doorless passageways or ventilation grills between the rooms.
- Page 7 AIR FOR COMBUSTION AND VENTILATION Continued VENTILATION AIR Ventilation Air From Inside Building This fresh air would come from an adjoining unconfined space. When ventilating to an adjoining unconfined space, you must provide two permanent openings: one within 12" of the ceiling and one within 12"...
-
Page 8: For More Information, Visit Www.desatech.com For More Information, Visit Www.desatech.com
INSTALLATION Installation Clearances INSTALLATION WARNING: A qualified service person must in- stall firebox. Follow all local codes. WARNING: Never install the firebox • in a bedroom or bathroom* • in a recreational vehicle • where curtains, furniture, clothing, or other flam- mable objects are less than 42 inches from the front, top, or sides of the firebox •... - Page 9 INSTALLATION Continued Mantel Clearances for Built-In Installation If placing custom mantel above built-in firebox, you must meet the minimum allowable clearance between mantel shelf and top of firebox opening shown in Figure 5. These are the minimum allow- able mantel clearances for a safe installation. Use larger clearances wherever possible to minimize the heating of objects and materials placed on the mantel.
- Page 10 INSTALLATION Built-In Firebox Installation (Cont.) Installing Firebox Using Optional Mantels Available from Retailer or Custom Built INSTALLATION Continued IMPORTANT: When finishing your firebox, combustible materials such as wall board, gypsum board, sheet rock, drywall, plywood, etc. may be butted up next to the sides and top of the firebox. Combustible materials should never overlap the firebox front facing.
-
Page 11: Installing Gas Line
INSTALLATION Continued INSTALLING GAS LINE WARNING: A qualified service person must con- nect heater to gas supply. Follow all local codes. IMPORTANT: See Connecting to Gas Supply in your log set owner’s manual for details on gas hookup. You may run the gas line from either side of the firebox (see Figure 11). -
Page 12: Illustrated Parts Breakdown And Parts List
ILLUSTRATED PARTS BREAKDOWN ILLUSTRATED PARTS BREAKDOWN V50H, V50S, AND VFB50NC For more information, visit www.desatech.com For more information, visit www.desatech.com 17/18 110749-01A... -
Page 13: Parts List
PARTS LIST V50H, V50S, AND VFB50NC This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 14 of this manual. KEY PART NUMBER DESCRIPTION 23490 Top Spacer 110285-03 Fireplace Top... -
Page 14: Technical Service
If so, contact DESA International’s Technical Service Department at 1-866-672-6040. When calling, please have your model and serial numbers of your firebox ready. You can also visit DESA International’s technical services web site at www.desatech.com. REPLACEMENT PARTS Note : Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. -
Page 15: Owner's Registration Form
Address: City: Home Phone: E-Mail: Please answer the following questions to register your product with DESA International: Where will the product be used? Living/Family Room Office/Warehouse If you bought this product yourself, did you plan to purchase this type of product before going into the store? - Page 16 Postage Required 2701 Industrial Drive P.O. Box 90004 Bowling Green, KY 42102-9004 For more information, visit www.desatech.com For more information, visit www.desatech.com 110749-01A TAPE...
- Page 17 NOTES NOTES _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ _______________________________________________________________________________________________ For more information, visit www.desatech.com For more information, visit www.desatech.com 110749-01A...
-
Page 18: Warranty Information
DESA International warrants this product to be free from defects in materials and components for four (4) years from the date of first purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions. To make a claim under this warranty the Bill of Sale or cancelled check must be presented.
