OWNER'S OPERATION AND INSTALLATION MANUAL
NATURAL GAS MODELS (V)V36N, (V)V42N SERIES,
PROPANE/LP GAS MODELS (V)V36P, (V)V42P SERIES
WARNING: If the information in this manual is
not followed exactly, a fire or explosion may
result causing property damage, personal
injury, or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch
• Do not use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
INSTALLER: Leave this manual with the ap-
pliance
CONSUMER: Retain this manual for future
reference.
DIRECT-VENT FIREPLACE
CHDV36NR AND CTDV36NR
For more information, visit www.desatech.com
WARNING: Improper installation, adjust-
ment, alteration, service, or maintenance
can cause injury or property damage. Refer
to this manual for correct installation and
operational procedures. For assistance or
additional information consult a qualified in-
staller, service agency, or the gas supplier.
Installation and service must be performed
by a qualified installer, service agency, or the
gas supplier.
This appliance is only for use with the type
of gas indicated on the rating plate. This ap-
pliance is not convertible for use with other
gases, unless a certified kit is used.
This appliance may be installed in an after-
market*, permanently located, manufactured
(mobile) home, where not prohibited by state
or local codes.
*Aftermarket: Completion of sale, not for purpose of resale,
from the manufacturer.
