Electrical Characteristics

PCI +12 V
PCI +3.3 Aux
1.0-1.81A
30mA

Safety Characteristics

The Intel
flammability rating 94 V0. Each bare board is marked with the supplier name or
trademark, type, and UL flammability rating. For the boards installed in a PCI bus slot, all
voltages are lower than the SELV 42.4 V limit.
14
PCI +3.3 V
330mA
®
RAID Controller SRCSASLS4I meets or exceeds the requirements of UL
Temperatures
0C to 40C with battery, 0
to 50C without battery
Non-operating, no
battery -30C to +80C
Intel® RAID Controller SRCSASLS4I Hardware User's Guide
Other
Airflow > 200 LFPM relative
humidity non-condensing:
5%-90%. With battery 20-80%
10-90% condensing
