3
Intel
Characteristics
Jumper
J1
J2
J8
J9
J10
Intel® RAID Controller SRCSASJV Hardware User's Guide
®
RAID Controller SRCSASJV
Description
Serial UART
4-pin
I2C header
3-pin
Mode selector
2-pin
Cache write
2-pin
pending LED
RAID Smart Battery
20-pin
connector
Type
Debug header. Factory use only
Enclosure management support, usually for non-
expander hot-swap backplane
Default is for no jumper
Provides signal to enclosure to indicate that the
cache needs to write data
Cable connector to the battery backup pack. This
connector is on the back of the card
Figure 4. Card Layout
Comments
10
