Intel® Integrated RAID Controller SRCS14L
Table 1. Common Acronyms (Sheet 2 of 2)
Acronym
StorCon
StorCon+
XROM
1.2

Documentation Conventions

The terms "RAID controller" and "the controller" are used interchangeably throughout this
document. Each term represents the physical PCB that integrates all the components of the RAID
PCI add-in card.
1.3

Product Overview

The SRCS14L is a PCI-based, low-profile, four-port SATA RAID controller. It utilizes the Intel
80303 Intelligent I/O processor, two Silicon Image* Sil3112A SATA controllers, and Intel
Integrated RAID software.
1.4

Operating System Support

The following operating systems are fully validated and supported:
•
Microsoft* Windows* XP Professional
•
Microsoft Windows 2000 Advanced Server
•
Red Hat* Linux* 7.3 (2.4 kernel)
•
SuSe* Linux 8.0 Professional
The following operating systems are supported with limited compatibility validation:
•
Windows 2000 Server
•
Red Hat Linux 7.2
•
TurboLinux* 7.0 Server
1.5

List of Features

•
Supports RAID levels 0, 1, 4, 5 and 10
•
Supports up to four hard drives connected to the four SATA ports on the controller
•
Online RAID level migration and capacity expansion without reboot
•
RAID array roaming
6
Storage Console: A character-based, menu-driven tool used for setting up, monitoring and
maintaining mass storage device subsystems based on IIR Controllers.
Storage Console Plus: A GUI-based, menu-driven tool used for setting up, monitoring and
maintaining mass storage device subsystems based on IIR Controllers. Runs only on
Microsoft* Windows*-based systems.
PCI Expansion ROM - BIOS utility accessed at system POST.
Description
Technical Product Specification
®
