Rolls RA102 Specifications

RA102
ROLLS ROLLS
JOINABLE JOINABLE
10 CHANNEL 10 CHANNEL
HEADPHONE HEADPHONE
AMPLIFIER AMPLIFIER
LINKABLE WITH THE JOIN IN/OUT
OUTPUTS ON FRONT AND BACK
ROLLS
5968 SOUTH 350 WEST S.L.C.,UT 84107
PHONE: 801-263-9053
FAX: 801-236-9068
DATA SHEET FOR RA102
The Rolls RA102 is a ten channel professional
headphone amplifier. Designed with volume
controls and 1/8" headphone outputs on the
front of the unit, along with 1/4" headphone
outputs on the back of the RA102 for each
channel. The RA102 has the connections for
any professional application. The join function
allows many RA102's to be linked together
with out any signal loss or impedance issues.
XLR balance inputs and RCA stereo inputs on
the back of the RA102.
SPECIFICATIONS
Input Impedance:
Max Input Level:
Input Connectors:
Outputs:
Max Gain:
Max Output Power:
Frequency Response:
S/N Ratio:
THD:
IMD:
Phase Shift (In to Out):
Slew Rate:
Crosstalk:
Power:
Weight:
Size:
Headphone impedance:
MADE IN USA
www.rolls.com
TEN CHANNEL HEADPHONE AMP
10K Ohms unbalanced
+18 dBV
RCA, R & L balanced XLR
10: 1/4" TRS Stereo jacks
10: 1/8" (3.5 mm) TRS Stereo jacks
20 dB/Channel
up to 250 mW/side, 500 mW/Channel
20 Hz - 30 kHz
90 dB
<.008%
<.008%
0 deg.
2 V per microsecond
- 65 dB
12 VAC (Rolls Model PS12)
7 lbs (3KG)
19" x 1.75" x 3.125" (48cm x 4.5cm x 17cm)
8 Ohms to 1000 Ohms
