Related Manuals for Brymen BM072
Summarization of Contents
Safety Information and Categories
Overvoltage Protection Categories
Explains CAT II, CAT III, and CAT IV overvoltage protection levels for equipment.
Safety Terms and Warnings
Defines WARNING and CAUTION terms and provides initial safety alerts.
CENELEC Directives and Product Description
CENELEC Directives
Lists conformity to CENELEC directives for safety and EMC.
Product Description
Clarifies that illustrations are for representative models only.
Operation: Voltage, Hz, and EF Detection
Voltage, Hz, and EF Detection Operation
Details operation for ACV, DCV, DC+ACV, Line-level Hz, and EF (NCV) modes.
Electric Field EF-Detection
Explains the Electric Field EF-Detection feature and its operation.
EF-Detection Methods
Describes Non-Contact and Probe-Contact EF-Detection techniques.
Operation: Current Measurements
Non-Invasive Low-Current Functions
Covers AmpTip™ and regular clamp-on ACA/DCA, Hz functions for low currents.
Non-Invasive Regular Current Functions
Covers AmpTip™ and regular clamp-on ACA/DCA, Hz functions for regular currents.
Operation: Resistance, Continuity, Diode, Capacitance, Temperature
Resistance, Continuity, and Diode Functions
Explains operation for Ω Resistance, Continuity, and Diode tests.
Capacitance and Temperature Measurement
Details operation for Capacitance and Temperature (°C/°F) measurements.
Operation: DCµA Current and 3-Phase Rotation
DCµA Current Function
Explains the DCµA function for HVAC/R flame sensor applications.
3-Phase Rotation Function
Details the 3-Phase Rotation function for Motors and MAINS.
Operation: Special Features and Modes
Hold, Record, and Relative-Zero Modes
Explains Hold, MAX/MIN/AVG Record, and Relative-Zero modes.
Peak-RMS, Backlight, and Auto-Power-Off
Details 80ms PEAK-RMS, LCD Backlight, and Intelligent Auto-Power-Off features.
Maintenance, Troubleshooting, and Calibration
Maintenance Procedures
Covers general maintenance, cleaning, storage, and battery replacement.
Troubleshooting and Calibration
Addresses common issues, calibration recommendations, and warranty service.
Electrical Specifications Overview
Protection, EMC, and Key Specifications
Details transient/overload protection, EMC compliance, and key electrical specs.
Voltage and DC+AC Voltage Accuracy
Lists accuracy for DCV, ACV, and DC+ACV measurements.
Other Function Accuracies
Provides accuracy specs for Capacitance, Diode, DCµA, Temperature, and Hz.
Current Measurement Accuracies
Details accuracy for AmpTip™ and regular clamp-on AC/DC current measurements.
EF-Detection Specifications
Lists typical voltages and bar-graph indications for EF-Detection.
