STORM 3G
3 G - s d I e d I t I n G w I t h h d M I
M o n I t o r I n G o u t p u t
3G hd/sd sdI-based, multi-format
editing with hdMI monitoring.
STORM 3G
is designed for video
professionals who want one solution
for both SDI-based editing and tapeless
workflows, with the capability to preview
their projects on affordable HDMI
monitors.
Based on the PCI Express form factor,
the STORM 3G solution includes EDIUS
nonlinear editing software, 3G HD-SDI
inputs and outputs, and an HDMI output
for full-resolution, real-time preview
monitoring. Embedded HDMI audio
provides high-quality audio monitoring.
It's a premium, high-powered solution for
multi-format editing.
KEY FEATURES
3G-SDI input and output with
embedded audio and timecode
HDMI output for full-resolution, real-
time monitoring from the included
EDIUS NLE software
Embedded HDMI audio output for
high-quality audio monitoring
Video and audio output stays
perfectly in sync, with editing
windows for accurate editing and
trimming
www.grassvalley.com
Timecode input and output is supported
via the RS-422 port for accurate editing
from field logs. The reference input
supports both analog blackburst and
tri-level sync. External VTR ingest can be
controlled via the RS-422 port and the
optional VTR emulation software may
be used to control the EDIUS software
®
like a VTR for direct playout from the
workstation.
The STORM 3G board can handle any
mix of high- and standard-definition (HD
and SD) video content; unlimited video,
audio, title, and graphics layers; and any
combination of real-time effects. It also
Reference input supports bi-level or
tri-level sync
RS-422 master or slave machine-
control support*
Edit any mix of SD and HD resolution
video content together in real time
Works with many different native
video formats, including AVCHD,
AVC-Intra, MPEG-2, uncompressed,
and more
product data sheet
offers real-time, full-resolution, full-quality
HD and SD video outputs.
An optional timecode in/reference out
board takes a linear timecode source via
the BNC connector and provides two
reference outputs-blackburst or tri-level
sync-providing a means to synchronize
both the STORM 3G and an external
device, such as a source deck, from a
single timecode source.
Supports newer file-based formats,
including Infinity
JPEG 2000,
XDCAM HD and XDCAM EX, P2
(DVCPRO and AVC-Intra), and GFCam
Compatible with Windows 7 (32/64-
bit) and Windows Vista (32/64-bit)
and Windows XP (32-bit) operating
systems
* Slave functions require the EDIUS VTR Emulation
option, available separately

Advertisement

loading
Need help?

Need help?

Do you have a question about the STORM 3G and is the answer not in the manual?

Questions and answers

Summary of Contents for GRASS VALLEY STORM 3G

  • Page 1 product data sheet STORM 3G 3 G - s d I e d I t I n G w I t h h d M I M o n I t o r I n G o u t p u t 3G hd/sd sdI-based, multi-format editing with hdMI monitoring.
