8900GEN-SM GeckoFlex Reference Input Submodule
The 8900GEN-SM submodule attaches to a synchronizer module and provides a reference input for:
• The host synchronizer module
• Other GeckoFlex modules via the frame reference bus (if the module is mounted in slot 1 or slot 3)
A second submodule attached to another GeckoFlex host module can provide a redundant frame reference
or a reference of a completely different signal format.
NOTE: At least one module per frame must have a genlock submodule installed to provide reference bus support.
Specifications
Genlock Reference Supported Formats:
• NTSC 29.97 Hz and PAL 25 Hz color black (black
and burst)
• 1080i 59.94 Hz tri-level sync
• 720p 59.94 Hz tri-level sync
• 1080i 50 Hz tri-level sync
• 720p 50 Hz tri-level sync
• 1080p 24 Hz tri-level sync
• 1080sf 24 Hz tri-level sync
• AES 48 kHz signal and AES 96 kHz signals
• Word Clock 48 kHz and Word Clock 96 kHz
Power Rating
0.7 Watts – single slot
Ordering Information
8900GEN-SM
Reference input submodule. This submodule mounts
to the synchronizer to provide reference input for the
frame reference bus. It is not required for 8985PRC
module operation.
For detailed specifications, installation, and setup
instructions see:
www.grassvalley.com/docs/modular
