- Page 1 Instruction Manual GRILL STATION – HIGH SPEED CONTACT GRILL MECHANICALLY CONTROLLED ELECTRONICALLY CONTROLLED DEVICES DEVICES GSA610 Version 4 GSA610SE Version 1 GSA810, GSA815 Version 3 GSA810SE, GSA815SE Version 1...
-
Page 2: Table Of Contents
CONTENTS SPECIFICATIONS Model Power Size (mm) Product Features (230V) Specifications Parts Included GSA610 2200W 435 490 228 17.3 Safety Instructions GSA810 2300W 560 490 228 Compliance GSA815 2990W 560 490 228 Cleaning & Maintenance Installation GSA610SE 2200W 435 490 248 17.3... -
Page 3: Safety Instructions
This appliance contains non user-serviceable CAUTION: Disconnect from power and allow to parts. Roband Australia, one of our agents, or a cool before cleaning. similarly qualified person(s) should carry out Season unit prior to use, refer to page 6. -
Page 4: Installation
GSA610, GSA810, GSA610E, GSA810E models cleaning will prevent the build-up of food should be plugged into a single phase, 10 or 15 residue which leads to carbonisation and can Amp power point. -
Page 5: Operation Of Grill Stations
South African (Type M) power point. OPERATION OF GRILL STATIONS Mechanically Timed Grill Stations All Models Models: GSA610, GSA810, GSA815 Selector Switch The timer is purely a mechanical device to provide an audible ring after the set time (each Displays the 2 different cooking functions of the unit;... -
Page 6: Additional Information
Press and hold at any time – Reset timer If the unit is left on pause mode for 6 minutes, to pre-programmed time. the unit will automatically exit pause mode and revert to the default time. The user must then At the end of a time sequence, the timer manually press start again to begin countdown. -
Page 7: Caution
CAUTION CIRCUIT PROTECTION Kitchen appliances must be backed up by the During Hotplate Mode the heat from the necessary level of circuit protection to comply bottom plate will flow upwards and warm the with AS/NZ3000. A GSA must be cabled into a handle. -
Page 8: Parts List
GSA810S / GSA810R PARTS LIST HC0189 Bottom Element & Plate 1410W Common HC0190 Smooth Top Element & Plate DC0116 Left Handle Arm 890W (GSA810S Only) DC0117 Right Handle Arm HC0191 Ribbed Top Element & Plate EC0031 Terminal Block 10mm² 890W (GSA810R Only) Porcelain/Steatite, L &... -
Page 9: Circuit Diagram
CIRCUIT DIAGRAM FOR CIRCUIT DIAGRAM FOR ELECTRONICALLY TIMED UNITS MECHANICALLY TIMED UNITS Special Note: These circuit diagrams have been provided for reference and to assist qualified service and repair agents only. Under no circumstances should persons not suitably qualified attempt repairs to any electrical equipment. - Page 10 (Record any preferred times or settings etc. here to act as a quick reference for other users)
-
Page 11: Warranty
Roband reserves the right to reject a warranty claim if it is not satisfied with the circumstances under which the fault occurred or where a product has been altered from its original specification. - Page 12 © Copyright 2021 – Roband Australia Pty Ltd ® All rights reserved. No part of this work may be reproduced or copied in any form or by any means, electronic or mechanical, including photocopying or posting to a website, without the written permission of the publisher.
