SAFETY AND OPERATING
MANUAL
THIS PRODUCT IS NOT FOR PROFESSIONAL USE
WARNING! Read the instructions before using the product.

Advertisement

loading
Need help?

Need help?

Do you have a question about the TORNADO 700SX and is the answer not in the manual?

Questions and answers

Related Manuals for Baumr-AG TORNADO 700SX

Summary of Contents for Baumr-AG TORNADO 700SX

  • Page 1 SAFETY AND OPERATING MANUAL THIS PRODUCT IS NOT FOR PROFESSIONAL USE WARNING! Read the instructions before using the product.
  • Page 2 Read the safety warnings before use EASY STARTING GUIDE CONNECT HANDLE BARS Tighten using the knobs and ensure the wires are on the upper side of the handle bars. FOLD BLADES OUTWARDS IMPORTANT! Pull the blades to the right as the blade is very sharp on one side. 140cm PETROL LAWNMOWER WR65170A ADD ENGINE OIL...
  • Page 3 CHOKE If equipped –move choke to “cold” position. PRIMER Use the primer (if equipped) when starting the product with a cold engine. BRAKE BAR Push the brake bar (2) (if equipped) down towards the handle and hold it in position when starting.
  • Page 4 DRIVE BAR Pull the drive bar (3) (if equipped) up towards the handle to engage self-propel feature (if equipped).

  • Page 5: Table Of Contents

    INTRODUCTION Congratulations on your purchase of this product. This product should give you reliable service but for your peace of mind this product does carry a 1 year guarantee, the terms of which are detailed below. If this product develops a fault within the guarantee period contact your retailer. Please retain this handbook in case you need to refer to safety, care or guarantee information in the future.

  • Page 6: Safety Warnings

    SAFETY WARNINGS 1. This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the product by a person responsible for their safety. 2.
  • Page 7 If petrol is spilled, do not attempt to start the engine but move the product away from the area of spillage and avoid creating any source of ignition until petrol vapours have dissipated. Replace all fuel tank and container caps securely. 4.
  • Page 8 15. Do not tilt the product when starting the engine or switching on the engine, except if the product has to be tilted for starting. In this case, do not tilt it more than absolutely necessary and lift only the part which is away from the operator.
  • Page 9 4. Maintenance and storage 1. Follow the maintenance and repair instructions for this product. Never carry out any modifications of the product. Never change the preset rotary speed or the engine and product settings. Information about maintenance and repair is provided in this user manual.
  • Page 10 Do not eat or drink, while you are refuelling the product. If you have swallowed petrol or oil, or if petrol or oil has got into your eyes, then seek medical advice immediately. Close the tank lid immediately after filling the tank. Make sure that it is properly closed.
  • Page 11 Take fire-extinguishing measures immediately if the product switch is no longer accessible. WARNING! Never use water to extinguish a product on fire. Burning fuel must be extinguished with special extinguishing agents! We recommend that you keep a suitable fire extinguisher within reach in your work area! 8.
  • Page 12 dB(A) Decibel (A-rated) m/s² Metres per second squared Litre Lock / to tighten or secure Unlock / to loosen Caution / Warning. Read the instruction manual. Wear hearing protection. Wear eye protection. Wear respiratory protection. Wear protective gloves. Wear safety footwear. Wear tight-fitted protective clothes.
  • Page 13 Do not smoke in the work area, around the product and in the vicinity of flammable materials! Risk of fire / flammable materials Hot surface, do not touch. High temperatures on the product’s surfaces and structural parts that could cause burns, if they are touched.
  • Page 14 Keep hands and feet away from sharp rotating parts – danger of injury! When cleaning, repairing, or inspecting, make certain the cutting device and all mowing parts have stopped. Disconnect the spark plug cap, and keep the cap away from the plug to prevent accidental starting.

  • Page 15: Product Description

    PRODUCT DESCRIPTION (Appearance may di er slightly)
  • Page 16 Handle Brake bar Drive bar Throttle lever Upper handle bar Brake wire Drive wire Throttle wire Lower handle bar Mounting set (x 2) Knob Washer Bolt Wire clip (x 2), pre-assembled triplex clip Mounting set (x 2) Knob Bolt Oil tank cap Air vents Muffler Spark plug connector...
  • Page 17 Handle support Lever for cutting height adjustment Recoil starter handle Deflector guard Grass catcher Handle Rope guide Cutting device (blade) Locking flange Hex bolt Rear discharge chute...

  • Page 18: Intended Use

    INTENDED USE The product is intended for mowing grass in domestic gardens only. It must not be used to mow unusually high, dry or wet grass, e.g. pasture grass; for shredding leaves or mulching. For safety reasons it is essential to read the entire instruction manual before first operation and to observe all the instructions therein.
  • Page 19 NOTE: Take care of small parts that are removed during assembly or when making adjustments. Keep them secure to avoid loss. 2. Handle bars 1. Remove the mounting sets (12) from the handle support (21) and keep them handy. 2. Ensure that the locking knobs (10a) are loose and unfold the upper (5) and lower handle bar (9).
  • Page 20 height preference (Fig. 2). Fig. 2 7. Fix the wires (6, 7, 8) with the wire clips (11a, 11b) to the lower handle bar (9) (Fig. 3). Fig. 3 8. Grass catcher Open the deflector guard (24) hold it in position and align the hooks on the grass catcher (25) with the support to hang it onto it (Fig.
  • Page 21 9. Fuel and engine oil This product is equipped with a 4-stroke engine. Before operation you have to add proper fuel and engine oil. WARNING! This product contains an instruction manual of the engine. It is important to read and understand these instructions of the engine and the equipment.
  • Page 22 1. Always use clean, fresh unleaded petrol. Purchase fuel in quantities that can be used within 30 days. 2. Never mix oil with petrol. Avoid getting dirt, dust or water in the fuel tank. 3. Unscrew and remove the fuel tank cap (20a). 4.

  • Page 23: Product Functions

    the “ADD” and “FULL” marking. Add more oil if necessary. Do not overfill (Fig. Fig. 7 4. Wipe spilled oil with a soft cloth and reattach the oil tank cap (13). PRODUCT FUNCTIONS 1. Grass catcher Always attach the grass catcher when using this product. Emptying Empty the grass catcher (25) frequently during use.
  • Page 24 Adjust the cutting height according to the needs of your lawn. The cutting height depends on the kind of lawn and its actual height. When mowing high grass, start with the maximum cutting height and make a second cut with lower cutting height. 1.
  • Page 25 Slowly pull on the recoil starter handle (23) and fit it into the rope guide (26) on the right hand side of the upper handle (5) during operation (Fig. 10). Do not remove the recoil starter from the rope guide. Fig.
  • Page 26 Fig. 12 6. Drive bar (self-propelled function IF EQUIPPED) Use the self-propelled function as assistance during operation; the rear wheels are automatically driven by the engine; you do not need to push the product manually. 1. Pull the drive bar (3) towards the handle (1) to engage the wheels. 2.

  • Page 27: Operation Instructions

    OPERATION INSTRUCTIONS 1. General 1. Check the product as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. 2. Double check that accessories or application tools are properly fixed. 3.
  • Page 28 1. Stand behind the handle (1). 2. Press the primer (19) three times. 3. Pull the brake bar (2) against the handle (1), hold it in position during operation (Fig. 15, 1.). 4. Move the throttle lever (4) downward to the start position (Fig. 15, 2.). 5.
  • Page 29 3. Mowing 1. Make sure that the lawn is clear of stones, sticks, wire or other objects that could damage the product or its engine. 2. Do not cut wet grass because it tends to stick to the underbody of the product, preventing the proper discharge of grass clippings, and it could also cause you to slip and fall.

  • Page 30: Maintenance And Care

    Switch the product off, disconnect the spark plug connector and let it cool down. Check, clean and store the product as described below. MAINTENANCE AND CARE WARNING! Always switch the product off, disconnect the spark plug connector and let the product cool down before performing inspection, maintenance and cleaning work! 1.
  • Page 31 WARNING! Wear safety gloves when working on the cutting device and close to it! Use proper tools to remove debris, e. g. a wooden stick! Never use your bare hands! Always use original spare parts for replacement. The cutting device must be replaced by an identification no.
  • Page 32 Grass catcher 1. Inspect the grass catcher (25) before each use. Do not use it if you find any damage. 2. Clean the grass catcher (25) after operation using water and mild soap. 3. Let the grass catcher dry thoroughly before storing to avoid mildew. Wires Check the performance of the wires (6, 7, 8) before each use.
  • Page 33 WARNING! Do not use the product with defective or loose wires! Repair This product does not contain any parts that can be repaired by the consumer. Contact an authorised service centre or a similarly qualified person to have it checked and repaired. Storage 1.

  • Page 34: Trouble Shooting

    2. Attach transportation guards, if applicable. 3. Always transport the product by its handle. 4. Protect the product from any heavy impact or strong vibrations which may occur during transportation in vehicles. Secure the product to prevent it from slipping or falling over, loss of fuel, damage and injury.
  • Page 35 1.3. Primer has been 1.3. Dry spark plug pressed at warm start 1.4. Spark plug is wet 1.4. Dry spark plug 1.5. Spark plug is 1.5. Replace spark plug damaged 1.6. Spark plug 1.6. Attach properly connector lose 2. Engine stops 2.1.
  • Page 36 Some experts believe the incorrect or prolonged use of almost any product could cause serious injury or death. For information that may reduce your risk of serious injury or death consult thepoints below and additionall y , the information available at www.datastreamserver.com/safety - Consult all documentation, packaging and - The product has been supplied by a general merchandise...
