Baumr-AG 890SXe User Manual

Baumr-AG 890SXe User Manual

21" self-propelled petrol key start lawn mower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
21" Self-Propelled Petrol
Key Start Lawn Mower
890SXe
User Manual
[Revision 3.0 February 2020]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND
MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in
appearance, assembly, inclusions, specifications, description and packaging.
The product is NOT supplied with engine oil, although traces of oil from the manufacturing process may be present. It is essential to
Failure to add engine oil will void the product
warranty.
add adequate engine oil of the correct type to the engine before use.
E&OE
© 2020 Baumr-AG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 890SXe and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Baumr-AG 890SXe

Summary of Contents for Baumr-AG 890SXe

  • Page 1 The product is NOT supplied with engine oil, although traces of oil from the manufacturing process may be present. It is essential to Failure to add engine oil will void the product warranty. add adequate engine oil of the correct type to the engine before use. E&OE © 2020 Baumr-AG...

  • Page 2: Safety

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Safety Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or equipment or property damage if not understood or followed. Safety messages have the following symbols:...
  • Page 3 21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe General Electrical Safety General Electrical Safety General Service Information • Inspect electrical equipment, extension • Electrically grounded equipment must have • The equipment must be serviced or cords, power bars, and electrical fittings for...
  • Page 4 21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe • Do not change the engine governor settings or over speed the engine; • Disengage all blade and drive clutches before starting the engine; • Start the engine or switch on the motor carefully according to instructions and with feet well away from the blade(s);...
  • Page 5 21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe • Do not throw the battery on a fire, and do not expose the battery to water. • Do not place the battery core under direct sunlight, which may cause the core to produce heat, smoke, fire, and can also cause bad performance and shorten the service life.

  • Page 6: Safety Symbols

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Safety Symbols The product may have safety warning labels attached to it, explained below. Understand the symbols on your product and their meanings. If any stickers become unreadable, unattached etc., replace them.
  • Page 7 21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Carbon-Monoxide Hazard Pull Hazard Slope / Fall Injury Hazard "Slam Dunk" Warning Do not use the product in Be aware that the product Be aware that using the product Do NOT attempt "slam dunk"...

  • Page 8: Table Of Contents

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Table of Contents Safety ................................2 Safety Symbols ................................6 Parts Identification ............................. 10 Assembly ..............................11 Assembling the Handle ............................. 11 Fixing the Connection Cord ............................12 Assembling the Grass Catcher ..........................12 Assembling the Grass Catcher to the Mower ......................
  • Page 9 21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Maintenance Schedule ............................. 28 Transport .................................. 28 Troubleshooting ............................29 Specifications ............................. 30 E&OE © 2020 Baumr-AG...

  • Page 10: Parts Identification

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Parts Identification Name Name Drive lever (clutch lever) Rear wheel Soft grip Engine oil cap Upper handle Side discharge cover Side discharge chute Fixing knob with square neck blot Deck Lower handle...

  • Page 11: Assembly

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Assembly Assembling the Handle 1. Fasten the lower handle to the device by using two bolts and two small knobs on each side. 2. Unfold the upper handle and fix it to lower handle by using the big knobs and the bolts on each side.

  • Page 12: Fixing The Connection Cord

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Fixing the Connection Cord Fix the connection cord to the handle with the cord clips (supplied). Assembling the Grass Catcher Clip the plastic clips over the metal frame. Make sure that these clips are fully secured to the metal frame.

  • Page 13: Assembling The Grass Catcher To The Mower

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Assembling the Grass Catcher to the Mower 1. Lift the rear discharge cover with one hand and hook in the grass catcher. 2. Release the rear discharge cover to secure the grass catcher in position.

  • Page 14: Assembling The Side Discharge Chute

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Assembling the Side Discharge Chute NOTE: When you’re going to use the side discharge function, you first need to remove the grass catcher and plug-in the mulching plug. 1. As shown in the images above, lift the side discharge cover with one hand and hook in the side discharge duct with the other hand.

  • Page 15: Checking The Engine Oil Level And Filling With Engine Oil

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Checking the Engine Oil Level and Filling with Engine Oil CAUTION! The following procedures and adjustments must be performed before the engine is started. • Do not attempt to make any of these adjustments while the engine is running. • To prevent engine damage, the engine is shipped without oil or petrol.

  • Page 16: Filling With Engine Fuel

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Filling with Engine Fuel CAUTION! • Always use clean, fresh unleaded petrol. Purchase fuel in quantities that can be used within 30 days. Never mix oil with petrol. • Do not fill into the base of neck to allow for fuel expansion.

  • Page 17: Adjustments

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Adjustments Setting the Cutting Height CAUTION! Adjust the cutting height only when the engine is switch OFF and the spark plug boot has been pulled out. The cutting height is centrally adjusted with the cutting height adjusting handle. Different cutting heights can be selected.

  • Page 18: Setting The Required Functions

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Setting the Required Functions NOTE: This lawn mower has three functions. These functions can be converted by changing the accessory settings. Please see the following table for details. Mulching Grass Side discharge...

  • Page 19: Operation

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Operation WARNING! • The blade begins to rotate as soon as the engine has been started. • Do not operate the machine in enclosed or poorly ventilated areas as the exhaust gas contains toxic substances.

  • Page 20: Battery Charging

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Battery Charging 1. Plug the charger input wire into the power socket and the power indicator light will turn on (green light). 2. Plug the battery into the charger slot and put it on a stable surface. When the battery is charging, the charging indicator light will have a red light, and the green indicator light will turn off.

  • Page 21: Start-Up Operation

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Start-Up Operation 1. First, check the lawn mower and add fuel and lubricating oil, if needed. 2. When starting with a cold engine, you need to turn the throttle control towards the START position.

  • Page 22: Cleaning A Flooded Engine

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe • To safely operate the mower, ensure all four wheels are on the ground and be careful not to lose your footing or control of the mower. Be very careful when mowing uneven or rough ground. Keep a firm grip on the handlebar at all times.

  • Page 23: Emptying The Grass Catcher

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe 3. Keep a firm grip on the upper handle with engine stop/start lever and drive lever (clutch lever) closed and walk along with its self-propelling to start mowing. When Mowing •...

  • Page 24: Lithium Battery Care And Maintenance

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Lithium Battery Care and Maintenance Top 3 Battery Care Requirements 1. Charge battery before first use. The battery may arrive with some charge, regardless of this the battery must be charged for 2 hours on the initial charge and 2 hours for each subsequent charge.

  • Page 25: Maintenance, Storage And Transportation

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Maintenance, Storage and Transportation WARNING! Before performing any maintenance or cleaning work, switch OFF the engine and wait until the blade has come to a stop. General Cleaning • The lawn mower should be cleaned thoroughly every time after it has been used.

  • Page 26: Engine Oil Replacement

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Engine Oil Replacement 1. Tilt the lawnmower towards the oil filler, have a container ready to catch the oil and remove the dipstick. Once the oil has been emptied, replace the dipstick and wipe clean any spillages.

  • Page 27: Storing The Lawnmower For Short Periods

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe 5. Clean the dirt and grass from around the blade mounting area. 6. Replace all 4 blades to ensure a smooth even cut and re-fit them on the mower in the reverse direction they were removed.

  • Page 28: Maintenance Schedule

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Maintenance Schedule Performing routine maintenance correctly on your lawnmower will ensure you get years of trouble free use. Please keep this manual safe for future reference. It is recommended that the following maintenance schedule is adhered to. This will ensure the lawn mower operates correctly and is safe to use.

  • Page 29: Troubleshooting

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Troubleshooting WARNING! Before performing any maintenance or cleaning work, switch off the engine and wait until the blade has come to a stop. CAUTION! • Improper repairs can result in the product functioning unsafely. This endangers yourself and your environment.

  • Page 30: Specifications

    21" Self-Propelled Petrol Key Start Lawn Mower – 890SXe Specifications Engine Type 4 Stroke Displacement 248cc Starting System Push Button (Electric) Battery (for starting) 12V Lithium Charger (for starting) 240V Self-Propelled Deck Steel Blade Type CrossCut Cutting Width 530mm; 21 inches...
  • Page 31 ©2020 Baumr-AG. All rights reserved. No part of this document, including descriptive content, concepts, ideas, diagrams or images may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, scanning or recording, or any information storage and retrieval system,...
