MX75 Hardware Installation Guide
This guide provides instruction on how to install and configure your MX75 series device. This guide also provides
mounting instructions and limited troubleshooting procedures. For more MX device installation guides, refer to the
MX installation guides section
on our documentation website.
Product Overview
The Meraki MX75 is an enterprise security appliance designed for distributed deployments that require remote
administration across medium branch environments. It is ideal for network administrators who demand both ease of
deployment and a state-of-the-art feature set. The Meraki Dashboard allows for simple and easy deployment of the
MX75 with minimal pre-configuration in almost any location.
Features
MX75 provides dedicated WAN uplinks, a single 1GbE SFP port, and 2 RJ45 1GbE ports. The LAN ports include 10
RJ45 1GbE ports. The MX75 is ready for deployment in a variety of enterprise environments. MX75 appliance provides
the following features:
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MX85 and is the answer not in the manual?

Questions and answers

Related Manuals for Meraki MX85

Summary of Contents for Meraki MX85

  • Page 1 MX75 with minimal pre-configuration in almost any location. Features MX75 provides dedicated WAN uplinks, a single 1GbE SFP port, and 2 RJ45 1GbE ports. The LAN ports include 10 RJ45 1GbE ports. The MX75 is ready for deployment in a variety of enterprise environments. MX75 appliance provides...
  • Page 2 • Managed via Cisco Meraki Dashboard • Meraki AutoVPN and L2TP/IPSec VPN endpoint • Automatic Firmware upgrades • Active Directory integration • WAN Link Balancing • Content Filtering • Automatic WAN Failover • Malware Protection (AMP) w/ optional Threat Grid integration •...
  • Page 3 MX68 MX75 MX85 location with 200 users retail location with 250 users Physical Specifications MX68 MX75 MX85 # WAN Interfaces 10x Dedicated GbE 10x Dedicated Gigabit LAN Interfaces - Dedicated 3x Dedicated GbE RJ45 RJ45 Ethernet RJ45 2x Dedicated GbE...
  • Page 4 Product View and Physical Features Front Panels MX75 Status Indicator The MX75 series devices uses an LED to inform the user of the device's status. LED patterns and their meanings are described below. LED Status Meaning Power is applied but the appliance is not connected to...
  • Page 5 Fully operational/connected, uplink actively using Solid Purple integrated cellular failover Back Panels MX75 MX75 Back Panel Functions Additional functions on the back panel are described below, from left to right. USB port USB 3.0 port for debugging. WAN / Internet port This port provides connectivity to the WAN.

  • Page 6: Side Panels

    Side Panels MX75 Bottom Panel Please note that the serial number is located on the product label at the bottom panel of MX75 devices Package Contents In addition to the MX device, the following are provided: MX75 Power Adapter (No Power Cable)
  • Page 7 2. Find the network to which you plan to add your MX or create a new network. 3. Add your MX to your network. You will need your Meraki order number (found on your invoice) or the serial number of each MX, which looks like Qxxx-xxxx-xxxx, and is found on the bottom of the unit. You will also need your Enterprise license key, which you should have received via email.
  • Page 8 You can mount the appliance on a drywall surface, either vertically or horizontally. The distance between the holes you drill should be 5-1/8 inches (13 cm). The fan grills for the MX75 are located at the bottom of the chassis.
  • Page 9 VLAN ID for your network. Setting up a Secondary WAN Interface on the MX75 MX75 comes with three dedicated Internet ports, which are both configured under Security & SD-WAN > Monitor > Appliance Status in the Uplink tab. Setting PPPoE PPPoE authentication may be required if you are connecting MX device to a DSL circuit.

  • Page 10: Warranty

    Meraki MX75 devices have been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. A digital device that is marketed for use in a residential environment notwithstanding use in commercial, business and industrial environments.
  • Page 11 Support and Additional Information If issues are encountered with device installation or additional help is required, contact Meraki Support by logging in to dashboard.meraki.com and opening a case by visiting the Get Help section. • The equipment is intended for industrial or other commercial activities.
