DiBos/DiBos Micro
4.3

The Display Bar

The display bar contains the following buttons:
4.3.1

Buttons for Live and Playback Mode

4.3.2

Button for Full Image

4.3.3

Buttons for Image Display

The individual buttons show how many image windows are
displayed in the image area.
–
–
Bosch Sicherheitssysteme GmbH
Button for live mode
Button for playback mode
Enlarges the image area to full image size.
To return to the original image display, press the
ESC key or double-click the right mouse button.
Aspect ratio 4:3
When these buttons are selected, the image area is divided
into image windows of equal size.
Aspect ratio 4:3
Click the down arrow to show the individual views.
Note: The most recently used view is copied to the display
bar.
Operation Manual
Playback Mode | en
F.01U.033.372 | V5 | 2009.09
41
