DiBos/DiBos Micro
3.6.1 Control field for Dome Cameras and Pan/Tilt
Cameras
After selecting this tab
cameras and pan/tilt cameras is displayed.
The control field will not be active until a dome camera and
pan/tilt camera is displayed in the selected image window. The
individual elements are highlighted when you move over them
with the mouse cursor.
If no dome camera or pan/tilt camera has been selected, the
control field is inactive.
Bosch Sicherheitssysteme GmbH
, the control field for dome
Pan the camera to the left/right.
Pan the camera up/down.
Pans the camera in all directions. Move the
mouse cursor to the icon and drag it in the
direction you would like to pan the camera
while holding down the left mouse button.
Enlarges (wide angle)/reduces (tele) the
image angle.
Focus far/focus near (sets the image so it is in
focus).
Close iris/open iris
Operation Manual
Live Mode | en
F.01U.033.372 | V5 | 2009.09
