Summarization of Contents
8 INTRODUCTION
8.1 TECHNICAL DATA
Provides specifications and details for LAF 800, 1250, and 1600 models.
9 INSTALLATION
9.1 General
Installation and commissioning must be performed by a qualified specialist.
9.2 Unpacking and erection
Warning about tipping risk and instructions for lifting equipment.
9.3 Connections
Instructions for connecting mains, control, and welding cables correctly.
9.4 PC board
Details DIP switch settings (SW1, SW2) for LAF 800, 1250, 1600 models.
10 OPERATION
10.1 Controls
Describes front panel components: main switch, indicator lamps, and pushbuttons.
10.2 Start-up
Steps for connecting the return cable and powering on the welding unit.
11 MAINTENANCE
11.1 Cleaning
Instructions for cleaning the welding power source using dry compressed air.
