LAE 800
Svetslikriktare
Svejseensretter
Likeretter for sveising
Hitsaustasasuuntaaja
Welding rectifier
Schweißgleichrichter
Redresseur de soudage
Lasgelijkrichter
Rectificador de soldadura
Raddrizzatore per saldatura
Rectificador de soldagem
ÁíïñèùôÞò óõãêüëëçóçò
Bruksanvisning
Brugsanvisning
Bruksanvisning
Käyttöohjeet
Instruction manual
Betriebsanweisung
455 420- -001
98.09.25
Manual d'instructions
Gebruiksaanwijzing
Instrucciones de uso
Istruzioni per l'uso
Manual de instruções
Ïäçãßåò ÷ñÞóåùò
Valid from Machine no 508- - XXX- -XXX

Advertisement

Table of Contents
loading

Related Manuals for ESAB LAE 800

Summary of Contents for ESAB LAE 800

  • Page 1 LAE 800 Svetslikriktare Svejseensretter Likeretter for sveising Hitsaustasasuuntaaja Welding rectifier Schweißgleichrichter Redresseur de soudage Lasgelijkrichter Rectificador de soldadura Raddrizzatore per saldatura Rectificador de soldagem ÁíïñèùôÞò óõãêüëëçóçò Bruksanvisning Manual d’instructions Brugsanvisning Gebruiksaanwijzing Bruksanvisning Instrucciones de uso Käyttöohjeet Istruzioni per l’uso Instruction manual Manual de instruções...

  • Page 2: Svenska

    FRANÇAIS Esab Welding Equipment AB, 695 81 Laxå Suède, certifie sous sa propre responsa- bilité que la source de courant de soudage LAE 800 portant le numéro 508 répond aux normes de qualité EN 60974--1 conformément aux directives 73/23/EEC avec annexe 93/68/EEC.

  • Page 3: Español

    Esab Welding Equipment AB, 695 81 Laxå Swezia, dichiara sotto la propria respon- sabilità che il generatore per saldatura LAE 800 numero di 508 è conforme alla nor- ma EN 60974--1 ai sensi dei requisiti previsti dalla direttiva 73/23/CEE e successive integrazioni nella direttiva 93/68/CEE.

  • Page 4: Table Of Contents

    SVENSKA ..........DANSK .
  • Page 5 ENGLISH 1 INTRODUCTION ........... 1.1 TECHNICAL DESCRIPTION .

  • Page 6: Introduction

    INTRODUCTION LAE 800 is a constant voltage welding rectifier. It is designed SOLELY for submerged arc and gas metal welding (MIG/MAG). LAE 800 is designed for use with PEG--1 control equipment. The welding current range can be extended by connecting two welding rectifiers in parallel.

  • Page 7: Technical Description

    TECHNICAL DESCRIPTION LAE 800 is a fan--cooled welding rectifier. It is fitted with a thermal cut--out to provide protection against overloading or failure of the fan. If this cut--out is activated a yellow lamp on the front panel lights up automatically.

  • Page 8: Installation

    INSTALLATION 1. Installation must be carried out by a qualified electrician. 2. Make sure the welding rectifier is set up for the available mains supply before connecting to the mains. 3. If the control voltage is switched between 42 V and 110 V, make sure the revers- ible rating plate shows the correct voltage.

  • Page 9: Operation

    OPERATION Turn the switch (1) to setting ”I”. The whi- te lamp (2) should light up and the fan will start. Adjust the welding voltage using the knob (3) on the front panel. If you are using a remote connect it to the socket (4) on the front panel and set the toggle switch (5) to the remote setting.
