EconoStand™
Parts
Instructions for Assembly
Step 1
Assemble bottom holder bracket onto
lower pole section (thicker section of
pole).
Step 2
Screw pole onto baseplate. Tighten
securely.
Step 3
Place stand upright. Using thumbscrew
at top of pole, attach top holder bracket
onto pole top.
Step 4
Snap Gotcha
®
holder onto brackets in
four places.
Step 5
Open holders, place sign in top and snap
closed, repeat for bottom holders.
Step 6
Adjust height of stand as necessary.
®
Gotcha
is a registered trademark and EconoStand
Displays, Ltd. Neither the manufacturer nor any sales agent may be held liable for
injury, loss or damage resulting from the use of these products.
Part #00INSEcono/Gotcha
Incept- 6.29.00
Instruction Sheet
EconoStand
components
Pole
Gotcha
®
12G100
1
3
5
TM
is a tradmark of Rose
Bottom
Holder Bracket
2
4
6
Thumb
Base Plate
Top
Holder Bracket
35 Congress Street, Salem MA 01970
Tel# 1-800-631-9707 Fax# 1-800-560-2890
e-mail:signware@rosedisplays.com
Top
Screw
