WINE CABINET INSTRUCTION MANUAL
Model:
One section models:
DAVS-18.46
DAUF-7.19
Two section models:
DAUF-16.52
DAVG-25.63.TO
DAVS-49.116
DAVS-72.185
DAUF-45.125.TO
DAVG-114.288.TO
NEW! PUSH-AND-OPEN DOOR FUNCTION (.TO)
DOOR OPENING MECHANISM
The push-and-open door function is activated when the unit is powered. To open the door, push the door slightly
inwards on the top left position for the right hinge model (the top right position for the left hinge model) and then release
it again. The unit will beep once to confirm the action. The door will be opened approx. 2~7cm by the push rod. Then
the door can be fully open manually. The push rod will return to its initial position after 3 seconds automatically. And
the unit will beep once again and it is ready for next opening action.
NOTE:
The door will close again automatically after approx. 3 seconds if it has not been fully opened manually for models
with automatic door closing function.
Do not block the door or hold on it while it is opening. If the door is blocked or held during opening, the door opening
mechanism and the door will be damaged. The loud and repeated cracking noises will be heard.
Do not push the push rod in or hold on to it during closing. If the push rod is blocked during closing, it will no longer
be able to reach its initial position. In the initial position, the push rod is flush with the front of control panel. In order to
set the push rod back in its initial position, disconnect the appliance from the mains, wait for approx. 10 seconds and
plug it back in again. The push rod will return to its initial position.
2020.V.1.
DAVG-18.46.TO
DAVS-25.63
DAVG-32.80.TO
DAVG-49.116.TO
DAVG-72.185.TO
DAUF-53.125
1
