Brakes
General ...............................................................................................................................................................
Description .........................................................................................................................................................
W/B60-80XT ...................................................................................................................................................
W20-40XTA, W20-40XTC, W20-30XTR, W60-80XT ....................................................................................
C60-80XT, CA60-80XT/XT2, T5XT ...............................................................................................................
Repairs - General ...............................................................................................................................................
Brake Shoe Removal ..........................................................................................................................................
W/B60-80XT, W20-40XTA, W20-40XTC, W20-30XTR.................................................................................
C60-80XT .......................................................................................................................................................
CA/C60-80XT/XT2, T5XT ..............................................................................................................................
Brake Shoe Installation.....................................................................................................................................
W/B60-80XT, W20-40XTA, W20-40XTC, W20-30XTR.................................................................................
C60-80XT2, CA60-80XT, T5XT .....................................................................................................................
Brake Linkage Removal ....................................................................................................................................
W/B60-80XT ...................................................................................................................................................
C60-80XT .......................................................................................................................................................
CA60-80XT/XT2, T5XT..................................................................................................................................
Brake Linkage and Cable Installation .............................................................................................................
W/B60-80XT ...................................................................................................................................................
C60-80XT .......................................................................................................................................................
CA60-80XT/XT2, T5XT..................................................................................................................................
Brake Adjustment..............................................................................................................................................
W/B60-80XT, W20-40XTA, W20-40XTC, W20-30XTR.................................................................................
C60-80XT, CA60-80XT/XT2, T5XT ...............................................................................................................
Brake Linkage Adjustment ...............................................................................................................................
C60-80XT, CA60-80XT/XT2, T5XT ...............................................................................................................
Troubleshooting..................................................................................................................................................
