Summarization of Contents
Disclaimer and General Information
Disclaimer Details
Provides a disclaimer regarding the accuracy and use of the manual, and limits liability.
Handling and Use Guidelines
Outlines responsibilities and procedures for handling, processing, and using the PV modules.
Limitation of Liability
Defines the limitations of liability and available remedies for issues related to the modules and manual.
General Installation Instructions
Provides essential safety instructions for installation, maintenance, and handling of PV modules.
Safety Precautions
General Warning
Essential safety warnings for PV module installation, including regulations and professional expertise.
Mechanical Safety
Details mechanical safety for rooftop installations, adverse conditions, and module construction integrity.
Electrical Shock Hazard
Highlights risks of lethal electric shock from PV modules, emphasizing insulated tools and avoiding wet conditions.
Fire Safety
Addresses fire rating, installation methods, and precautions to mitigate fire risks associated with PV modules.
Operating and Installation Conditions
Temperature Limits
Specifies the minimum and maximum ambient air temperatures for proper PV module operation.
Installation Orientation
Guides correct module orientation, junction box position, and facing direction for optimal performance.
Handling, Unpacking, and Storage
General Handling and Storage
Provides guidelines for storing modules in dry conditions and safe general handling practices.
Detailed Unpacking Instructions
Step-by-step guide and safety precautions for safely unpacking solar module pallets and individual modules.
Product Specifications
PERC 72 Electrical Ratings
Presents electrical performance data for MSE PERC 72 (6BB) modules, white and black backsheets.
PERC 60 Electrical Ratings
Details electrical specifications for MSE PERC 60 (6BB) modules with white backsheets.
PERC 60 Black Electrical Ratings
Provides electrical ratings for MSE PERC 60 (6BB) modules with black backsheets.
PERC 66 Black Electrical Ratings
Lists electrical specifications for MSE PERC 66 (6BB) modules with black backsheets.
Module Temperature Coefficients
Details temperature coefficients for various MSE PERC module series affecting performance with temperature.
Mechanical Installation
General Mounting Requirements
Covers UL 61730 compliance, mounting options, and series/parallel connection limits for modules.
Ground Mount Installation
Guidelines for ground mounting, ensuring adequate height to avoid snow coverage and debris.
Roof Mount Installation
Instructions for secure roof mounting, ventilation, and maintaining fire class ratings.
Pole Mount Installation
Considerations for pole mounting, ensuring the structure withstands anticipated winds.
Mounting Methods
Details bolt and clamp methods for securing modules, including hardware and torque specifications.
Module Series Dimensions
PERC 72 Series Dimensions
Front, side, and back views with dimensions for MSE PERC 72 (SX6S/SX6W/SX6Z) series modules.
PERC 60 Series Dimensions
Dimensional drawings for MSE PERC 60 (SX5T/SX5K) series modules, including front, side, and back views.
PERC 66 Series Dimensions
Provides front, side, and back views with dimensions for MSE PERC 66 (SX5R) series modules.
Grounding Instructions
WEEB-UIR Grounding Method
Details the use of BURNDY WEEB-UIR washers for bonding modules to mounting structures and torque specifications.
Electrical Installation
Local and National Regulations
Emphasizes adherence to local/national codes (NEC, CSA) and professional wiring practices for safety.
Wiring and Connections
Provides recommendations for wiring, series/parallel connections, cable types, and connector handling.
Module Connectors
Details connector types, proper handling, and mating compatibility for Staubli and RENHE connectors.
Bypass Diodes
Explains the function of bypass diodes in junction boxes for partial shading and potential diode failures.
Maintenance
Visual Inspection
Recommends periodic inspections to ensure system components are functioning properly and securely.
Cleaning Procedures
Guides on cleaning modules to maintain performance, recommending specific methods and materials.
