- Page 1 MODULE INSTALLATION AND USER MANUAL - PERC AND MONO SERIES w ww. mi ss i o ns o l ar. co m...
- Page 2 CONGRATULATIONS Congratulations on choosing Mission Solar Energy panels for your next solar project. Your Mission Solar Energy panels have been engineered to provide you with many years of power production. Designed, engineered and assembled in our state-of-the-art facility in San Antonio, Texas, you will feel peace of mind knowing you have an American Quality product proven to perform over the long-term.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Disclaimer....................3 Handling and Use..................3 Limitation of Liability and Limited Remedies........3 General Instructions..................3 Safety......................4 General Warning................5 Mechanical..................5 Electrical Shock Hazard..............5 Fire.....................5 Operating Conditions................6 Temperature..................6 6.2 Installation Conditions..............6 Unpacking and Storage................7 General Instructions..............7 7.2 Unpacking..................8-9 Product Electrical Specifications............10-11 Mechanical Installation................12 Mounting Clamps................13 10.0 Grounding Instructions................14 11.0 Electrical Installation................15 11.1 Local/National Code and Local Regulations......15... -
Page 4: Disclaimer
Mission Solar Energy is not responsible for the accuracy of said contents or results of your use of the same. Under no circumstances will Mission Solar Energy be liable to you or any third party for damages arising under any legal theory including contract, tort, negligence or strict liability or for direct, indirect, special, consequential;... - Page 5 FIGURE 1: OVERVIEW OF MSE PERC / MONO 72 Front View Back View FIGURE 2: OVERVIEW OF MSE PERC 60 CELL Front View Back View Module Installation and User Manual - PERC and Mono Series Page 4 of 17 Document #: P-SA2-UM-0003 Revision #: R8...
-
Page 6: Safety
5.4 FIRE photovoltaic system • Mission Solar Energy modules have a Type 1, Class C fire 5.2 MECHANICAL resistance rating in accordance with the IEC 61730 and UL 1703 standard. •... -
Page 7: Operating Conditions
6.0 OPERATING CONDITIONS 6.1 TEMPERATURE All the modules must be mounted in environments that ensure they operate within the following maximum and minimum operating temperatures. • Maximum Operating Temperatures: +90oC (194oF) • Minimum Operating Temperatures: -40oC (-40oF) 6.2 INSTALLATION CONDITIONS Orient the module correctly. -
Page 8: Unpacking And Storage
7.0 UNPACKING AND STORAGE 7.1 GENERAL INSTRUCTIONS Store modules in an environment consistent Do not stand, step, walk and/or jump on the with prudent solar industry practices, including, module. storage in dry conditions such that modules (or any part thereof) are not immersed in water. Do not allow children or unauthorized persons Do not carry the module above the head. -
Page 9: Unpacking
7.2 UNPACKING Prior to unpacking, ensure pallet is set on a Cut the two green strips of banding material Lift the pallet lid and set away from unpacking level surface and proper PPE is equipped with scissors. These strips are under high area. - Page 10 7.2 UNPACKING (Optional) If tape has been used to provide The first module must be separated and When four modules remain, the stack will additional support to module stack, peel pulled out with additional care so as to not inherently become prone to tipping over. At tape back as needed to remove individual scratch the modules.
-
Page 11: Product Electrical Specifications
8.0 PRODUCT ELECTRICAL SPECIFICATIONS TABLE 1: ELECTRICAL RATINGS OF MSE PERC 72 (4BB) MODULE SERIES Open Circuit Short-Circuit Rated Maximum Model-P PERC Rated Voltage at Maximum System Rated Current at PV Modules have been certified for a maximum static load Voltage at STC, Current at STC, Power at STC, Crystalline STC, (V dc) Voltage, (V dc) STC, (A dc) - Page 12 TABLE 4: ELECTRICAL RATINGS OF MSE PERC 72 (5BB) MODULE SERIES Open Circuit Short-Circuit Rated Maximum Model-P Mono Rated Voltage at Maximum System Rated Current at Voltage at STC, Current at STC, Power at STC, PERC STC, (V dc) Voltage, (V dc) STC, (A dc) (V dc) (A dc) (Watts) MSE370SQ9S / 48.08 ±...
-
Page 13: Mechanical Installation
9.0 MECHANICAL INSTALLATION The module is considered to be in compliance with IEC 61730 and UL 1703 only when the module is mounted in the manner specified by the mounting instructions below. We recommend using the following orientation to install the module. The maximum number of modules connected in series /parallel for MSE PERC 72 is 24/1 and maximum number of modules connected in series /parallel for MSE PERC 60 is 19/1. -
Page 14: Mounting Clamps
9.1 MOUNTING CLAMPS Use the mounting holes as a reference - 297 mm (MSE PERC 60) or 370 mm (for MSE PERC 72) for mounting clamp location. Make sure that the module is evenly between the two rails and sits perpendicular on the railing. If the module is not perpendicular, slightly adjust the end-clamp positions to get the proper alignment. -
Page 15: Grounding Instructions
NEC requirements for grounding solar electrical systems. In order to install, Mission Solar Energy modules shall be grounded using grounding hardware that has been certified to meet requirements for grounding systems in UL467, UL1703, or UL1741 on anodized aluminum frames. -
Page 16: Electrical Installation
11.0 ELECTRICAL INSTALLATION 11.1. LOCAL/NATIONAL CODE AND LOCAL • Install the modules so that water from rain or condensation REGULATIONS cannot penetrate inside the cable conduits. • Fix cables to the structure so that the connectors are protected from water ingress. Cables should be held by UV resistant clamps or ties. -
Page 17: Connectors
11.4. DIODES • Keep connectors dry and clean. Ensure that connector caps • The junction boxes used with Mission Solar Energy modules are hand-tight before connecting the modules. contain bypass diodes wired in parallel with the PV cell strings. •... -
Page 18: Maintenance
12.1. VISUAL INSPECTION 12.2. CLEANING • Mission Solar Energy recommends that PV systems be periodically The dust accumulated on the front transparent substrate may inspected by the installer or other qualified personnel. The purpose reduce the power output, and may even cause regional hot-spot of the PV system inspection is to ensure that all system components effect. - Page 19 Mission Solar Energy 8303 S. New Braunfels Ave. San Antonio, Texas 78235 info@missionsolar.com 210-531-8600...
