MSI10-xxxHN5W SERIES MSI10-xxxHN4W SERIES MSI10-xxxHN5B SERIES MSI10-xxxHN4B SERIES Company: Mission Solar Energy LLC Address: 8303 South New Braunfels Avenue, San Antonio, TX, 78235, USA Factory: PT IDN SOLAR TECH Address: Komplek Kabil Indonusa Estate, Blok A Nomor 19B, Batu Besar, Batam,Indonesia TEL.
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 2 O F 1 6 T A B L E O F C O N T E N T S 1.0 GENERAL INFORMATION ............3 2.0 DISCLAIMER OF LIABILITY ............3 3.0 SAFETY PRECAUTION ...............
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 3 O F 1 6 1.0 GENERAL INFORMATION This manual contains information regarding the installation and safe handling of the MSI photovoltaic module (hereafter is referred to as “module”). Installers must read and understand the manual before installation.
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 4 O F 1 6 Modules should be stored in a dry and ventilated environment. In the storage and handing process, in case of inclement weather (rain, snow, wind, etc.), cover the packing boxes with materials such as plastic film and waterproof cloth.
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 5 O F 1 6 The triangle hole punched on the backside frame of the module is the drain hole which cannot be blocked. When interconnecting the modules, properly secure the connecting cables onto to the mounting system.
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 6 O F 1 6 Never place the module in locations where flammable gases may be easily generated or collected. MSI suggests installing the module in dry areas where the climate is moderate. In case of special installation environments such as the seaside, farm, high humidity environment and sandstorm environment, contact the local dealer for professional support and confirmation.
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 7 O F 1 6 When installing a module on a pole, choose a pole and module mounting structure that will withstand the anticipated wind power in the local area. The support rod must be constructed on a solid foundation.
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 8 O F 1 6 6.4 INSTALLATION METHOD Framed modules shall be installed using mounting holes, clamps* or an insertion system with recommended torque of 20Nm-25Nm. Modules must be installed according to the following examples.
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 9 O F 1 6 Figure 6: Screw Fitting Method * NOTES: MSI limited warranty will be void in cases where improper clamps or installation methods deviating from this manual are used.
Page 10
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 1 0 O F 1 6 Figure 7: PV module installed in portrait orientation with Clamp fitting method Figure 8: Mechanical dimensions when modules are installed in portrait orientation with Clamp fitting method Fringe Module Installation Middle Module Installation Notes:...
Page 11
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 1 1 O F 1 6 Mechanical Mounting Installation location Module type method load MSI10-xxxHT4G 4-clamp MSI10-xxxHN4G installation Design load MSI10-xxxHN5G MSI10-xxxHT4T MSI10-xxxHN5W Positive: 3600Pa MSI10-xxxHN4W MSI10-xxxHN5B Negative: 1600Pa MSI10-xxxHN4B Safety factor: 1.5...
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 1 2 O F 1 6 7.0 ELECTRICAL INSTALLATION 7.1 GENERAL ELECTRICAL I NSTALLATION Try to use the modules with the same configuration in the same photovoltaic system. If the modules are connected in series, the total voltage is the sum of voltages of all the modules, and the maximum number of the series modules (N)=V (System) / [1.25*V...
Page 13
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 1 3 O F 1 6 Figure 9: a) Grounding hole Figure 9: b) Grounding method With negative grounding Figure 10: Schematic diagram for grounding potential of the inverter 7.3 WIRE ...
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 1 4 O F 1 6 CON N EC TO R M OD E L N A M E M AN U FA CT UR E R RA T E D V O LT AG E PV-KST4/6II-UR(male), STAUBLI ELECTRICAL...
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 1 5 O F 1 6 8.0 MAINTENANCE AND CARE Clean the glass surface on a regular basis. Avoid hotspots due to bird droppings, leaves and dead insects covering the glass surface.
Page 16
VERSION: 1 DOCUMENT #: P-UM-0013 VERSION DATE: 05/24/2024 P A G E : 1 6 O F 1 6 Type MSI10-xxxHN4G MSI10-xxxHN5G Size(mm) 2278*1134*30 2465*1134*30 Power(W) Effi. (%) 21.68 21.87 22.07 22.28 22.47 22.67 21.66 21.84 22.02 22.20 22.38 22.56 Vmp(V) 41.81 41.92...
