Enclosure configuration

A. Run the Insight Display wizard
When the enclosure is powered up for the first time, the HP BladeSystem Insight
Display launches an installation wizard to guide the rack technician through the
initial configuration process.
Be sure to have the Installation Checklist available to record important information,
such as the Onboard Administrator IP address, gathered while running the
installation wizard. By default, the Onboard Administrator obtains an IP address
using DHCP. Read the Insight Display and write the IP address for the active and
standby Onboard Administrator on the checklist. This IP address is needed for
remote connection and subsequent setup with a browser. If DHCP is not used, a
static IP address can be configured on the Insight Display Settings screen. For
specific instructions, see the HP BladeSystem Onboard Administrator User Guide
on the HP website (http://www.hp.com/go/bladesystem/documentation).
The Insight Display verifies that no installation or configuration errors exist and
indicates configuration check progress. If configuration errors are indicated, follow
the on-screen instructions to correct the problem. When the screen display stays
green, there are no configuration errors or device failures and hardware
installation is complete.
B. Run the Onboard Administrator First Time Setup
Wizard
After all hardware is installed and the hardware configuration has been verified in
the Insight Display, use one of the following methods to complete the enclosure
configuration setup:
Use the Insight Display to determine the address received by DHCP, and then
use the Onboard Administrator First Time Setup Wizard to complete the
installation and configuration at the assigned address.
If no DHCP server is present on the customer management network, do one
of the following:
o
Use the Insight Display to set the address, and then use the Onboard
Administrator First Time Setup Wizard to complete the installation and
configuration at the assigned address.
o
Use the Onboard Administrator First Time Setup Wizard or the CLI to
configure EBIPA and assign IP addresses for iLO and interconnect
management ports. This method simplifies the required setup for
interconnect management network settings.
Use the Insight Display to set the IP address and complete the Onboard
Administrator First Time Setup Wizard from the Insight Display. This method
enables configuration without the use of an external browser.
For specific instructions, see the HP BladeSystem Onboard Administrator User
Guide on the HP website (http://www.hp.com/go/bladesystem/documentation).
