- Page 1 QUICK INSTALL GUIDE AND USER MANUAL KVXLCH-100, KVXLCHF-100 KVX SERIES 4K HDMI KVM- IP EXTENDER 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM...
-
Page 2: Table Of Contents
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TABLE OF CONTENTS TECHNICAL SUPPORT 1.877.877.2269 QUICK INSTALLATION GUIDE ................................3 1. SPECIFICATIONS ................................... 4 2. OVERVIEW ...................................... 6 2.1 Introduction .......................................6 2.2 Features ........................................6 2.3 What’s Included ......................................6 2.4 Hardware Description ....................................7 2.4.1 Transmitter .......................................... -
Page 3: Quick Installation Guide
SUPPORT 1.877.877.2269 Follow these steps to install the extender: 1. If you have the fiber models, install the SFPs in the transmitter and receiver. Compatible SFPs from Black Box are listed in the table below. COMPATIBLE SFP MODULES PART NUMBER... -
Page 4: Specifications
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 TABLE 1-1. TRANSMITTER SPECIFICATIONS Console Connection Video Output Serial Control Port (1) DB9 female Host Connection Video Input (1) HDMI female Local Out Video Connection Local Out (1) HDMI female Link Port... - Page 5 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 TABLE 1-2. RECEIVER SPECIFICATIONS Console Connection Video Output (1) HDMI female Serial Control Port (1) DB9 male Host Connection Video Input Link Port RJ-45 (KVXLCH-100 receiver) CATx cable –...
-
Page 6: Overview
HDMI video output of the remote source devices via the HDMI output port on 4K HDMI KVM Extender’s TX unit. There are two models of the KVX Series 4K HDMI KVM-IP Extender: one is KVXLCH-100 via a CATx link, and the other is KVXLCHF-100 via a fiberoptic link. -
Page 7: Hardware Description
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4 HARDWARE DESCRIPTION 2.4.1 TRANSMITTER FRONT PANEL Figure 2-1 shows the front panel that is common to both the CATx and the fiber transmitter. Table 2-1 describes its components. LINK FIGURE 2-1. - Page 8 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 BACK PANEL Figures 2-2 and 2-3 show the back panels of the CATx and fiber transmitters. Table 2-2 describes their components. DC 5V HDMI OUT HDMI IN CATx RS232...
-
Page 9: Receiver
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4.2 RECEIVER FRONT PANEL Figure 2-4 shows the front panel that is common to both the CATx and the fiber receiver. Table 2-3 describes its components. LINK FIGURE 2-4. - Page 10 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 BACK PANEL Figures 2-5 and 2-6 show the back panels of the CATx and fiber receivers. Table 2-4 describes their components. DC 5V CATx RS232 HDMI OUT FIGURE 2-5.
-
Page 11: Connection Diagram
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: CONNECTION DIAGRAM TECHNICAL SUPPORT 1.877.877.2269 Figures 3-1 and 3-2 show typical connections. HDMI RS-232 device Audio Audio HDMI HDMI display display RS-232 keyboard/mouse DC 5V DC 5V RS232 HDMI OUT HDMI IN CATx RS232... -
Page 12: Installation
SUPPORT 1.877.877.2269 Follow these steps to install the extender: 1. If you have the fiber models, install the SFPs in the transmitter and receiver. Compatible SFPs from Black Box are listed in the table below. COMPATIBLE SFP MODULES PART NUMBER... -
Page 13: Appendix A. Regulatory Information
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.1 FCC CLASS A STATEMENT This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. -
Page 14: Nom Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL APPENDIX A: REGULATORY INFORMATION SUPPORT 1.877.877.2269 A.2 NOM STATEMENT 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3. -
Page 15: Appendix B. Disclaimer/Trademarks
B.1 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice. - Page 16 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2019. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. K VXLCH-100_QIG-USER_REV1.PDF...
