Summary of Contents for Starline E6

  • Page 1 , E96, E9, , E66, E6 security systems User manual instruction...

  • Page 2: Table Of Contents

    StarLine E96, E66 Contents General description ................8 Specification ..................12 Light and sound indication ..............13 System control with the remote key ........... 14 Meaning of remote key pictograms ................15 Main control commands of the remote key .............17 Cursor menu ........................19 Operation modes ...................
  • Page 3 short user manual Attention! Prior to operation of the security system carefully read this manual paying special attention to the sections marked and determine whether this security system is suitable for your car, for which following the car manufacturer’s requirements and the car operation manual.
  • Page 4 StarLine E96, E66 If your security system has a remote key or a wireless tag: • Do not carry the remote key or tag on the same bundle with the car keys • Always switch over the system to the service mode when handing the car over for maintenance or washing.
  • Page 5 short user manual Mandatory safety measures during use of the engine starting function It should be borne in mind that the car is a source of extra hazard. Before security system operation, carefully study the measures for safe use of the function of remote or automatic engine starting outlined below: 1.
  • Page 6 StarLine E96, E66 Safety precautions during charging of your car’s storage battery Remember that any battery charging process implies supply of voltage exceeding the rated 12 V to the storage battery and accordingly to the car circuit, which may damage the car electronic equipment and additional installed equipment in your car.
  • Page 7 short user manual If the aforesaid devices and modes are used, the car owner shall be responsible for damage of the electronic equipment. Observe the technology for safe storage battery charging! Before charging, the storage battery terminals shall be disconnected from the car circuit.

  • Page 8: General Description

    • driver identification by means of the wireless tag or smartphone via the Bluetooth Smart protocol; • connection of wireless underhood unit StarLine R6 for control of the hood locks, horn and engine blocking; • additional owner authorization by means of a wireless tag, smartphone or entry of the secret code by means of the factory buttons;...
  • Page 9 • the service button combined with the LED indicator of system status; • universal reconfigurable outputs/inputs; • the special StarLine Master program, used for individual setting of the system depending on owner’s wishes and car’s peculiarities. * available in connection with StarLine M66 tracking device...
  • Page 10 It is used for emergency security deactivation. • Service code — the code is given on the owner’s plastic card. It is used for entry in the StarLine Master application. ATTENTION! Do not tell the code of emergency security deactivation to anybody! Remember that a malefactor, knowing the code, may deactivate the protective functions.
  • Page 11 short user manual • long — hold the button until the LED flashes. The duration of depression can be of two levels: • 1 level — hold the button until a long flash of the LED corresponding to the current mode of operation appears; •...

  • Page 12: Specification

    Range of notification to the remote key up to 2000 meters Interfaces • 2 CAN • 2 LIN • 1 universal code bus StarLine Bus • 1 USB • 18 reconfigurable channels: • 17 outputs of OC (open collector) ОК –0,2А...

  • Page 13: Light And Sound Indication

    short user manual Light and sound indication The security system informs about its status by means of sound (horn) and light signals (turn signals) — short signal — long signal Event Light signals Horn Security activation Security activation with security zone breach Security activation with deactivation of «Hands free»...

  • Page 14: System Control With The Remote Key

    StarLine E96, E66 System control using the remote key The system (depending on the set) includes Remote key with LCD display (liquid-crystal display): The service life of the battery of the additional remote key is up to 1 year depending on operation conditions.

  • Page 15: Meaning Of Remote Key Pictograms

    short user manual Value of remote key pictograms Engine Starting Operation modes...
  • Page 16 StarLine E96, E66 Security zones Sensors...

  • Page 17: Main Control Commands Of The Remote Key

    short user manual Additional information Main control commands from the remote key This manual users the following terms of duration of pressing on the remote key buttons: One pressing of the button (or two buttons at the same time) with duration less than 1.5 second. Short pressing Example: —...
  • Page 18 StarLine E96, E66 Two pressings of one or different buttons. The first pressing shall be long (of the first or second level), the second pressing shall be short. The first button should be released Successive pressing before the second pressing.

  • Page 19: Cursor Menu

    Automatic starting Set the value of storage 0,1 V by voltage battery voltage in Volts Activate/deactivate Service mode — the service mode The information on the additional remote key settings is available in the electronic manual on the website help.starline.ru.

  • Page 20: Operation Modes

    StarLine E96, E66 Operation modes Security on Security off Security modes Alarm Panic Slave Hands free Additional modes Service mode Device registration mode Telematic setting mode The security modes protect the car against theft. The additional modes are intended for setting of the system...

  • Page 21: Security Off» Mode

    short user manual If a security activation command is sent with the ignition on, only closing of the central lock will be performed. Security activation is performed by one of the following methods: • short pressing on remote key button •...

  • Page 22: Alarm» Mode

    This mode is activated by owner’s command by a double pressing on remote key button or SMS-command (available in connection with StarLine M66 tracking device). Upon command reception the system activates sound alerting by the horn and emergency light alarm for 10 seconds to attract the attention of nearby persons.

  • Page 23: Hands Free» Mode

    short user manual «Hands free» mode Use the wireless tag (depends on the set of the system) or smartphone for the «Hands free» mode The «Hands free» mode is intended for automatic control of security activation/deactivation according to tag presence. When the tag is present near the car, security deactivation is performed automatically.

  • Page 24: Drive Prohibition» Function

    If the owner authorization code is not entered, then if an attempt at driving is made, the engine will be blocked for 1 minute or until entry of the owner authorization code «Engine starting» function (only for StarLine E96) The starting function allows for remote and automatic car engine starting/stopping.
  • Page 25 short user manual If the door is opened or ignition is switched on after fulfillment of the «program neutral», remote and automatic engine starting will be canceled until the next execution of the «program neutral» algorithm. Preparation of a car with automatic transmission for remote and automatic engine starting Make sure the automatic transmission selector is in the «Parking»...
  • Page 26 It can be changed in the personal account on the website starline.online or in the StarLine mobile application. ATTENTION! Automatic engine starting will not take place if less than 1 hour has passed after the last start or the previous automatic start has failed.

  • Page 27: Function «Engine Starting Preheater

    short user manual connection method: • first variant (*): • deactivate system security; • hold the brake pedal for 3 seconds; • the LED on the service button will go out, after which movement can be started (the START/STOP button need not be pressed);...

  • Page 28: Function «Turbotimer

    Operation time and switch-off temperature threshold of the starting preheater can be changed in the personal account on the website starline.online or in the StarLine mobile application. Function «Turbotimer» Use the function «Turbotimer» for turbocharged cars for engine turbine cooling.

  • Page 29: Change Settings

    • the engine will be stopped when the turbine cools down. Turbine cooldown time is calculated automatically and depends on engine speed before the drive end. The maximum turbine cooldown time is 5 minutes. Change settings Change of user settings is available in the personal account on the website starline.online...

  • Page 30: Registration Of Remote Keys, Tags And Smartphones

    StarLine E96, E66 Registration of remote keys, tags and smartphones Use the «Device registration» mode for registration of new remote keys, tags and smartphones. To prevent unauthorized adding of new components, entry in the device registration mode is possible only from the «Security off»...
  • Page 31 short user manual 4) Switch on the ignition. 7 light signals on the service button will follow. 5) Entry in the registration mode will be confirmed by 2 short LED signals. Remote key registration 1) Press the remote key buttons 1 and 2 shortly. 2) In 3 seconds, successful registration will be confirmed by a short sound signal of the remote key and 2 LED signals.
  • Page 32 StarLine E96, E66 Tag registration 1) Remove the battery from the tag. 2) Press and hold the tag button and install the battery. The tag LED will light up red. 3) Release the button and check presence of a series of red flashes for 10 seconds.
  • Page 33 Smartphone registration Register the smartphone using the StarLine mobile application (see the application menu «Smartphone as a tag»). Exit from the device registration mode Exit from the device registration mode is performed automatically in 5 minutes or at ignition switch-off.

  • Page 34: Emergency Security Deactivation

    StarLine E96, E66 Emergency security deactivation If the tag was lost, the tag or remote key battery has discharged, there is no access to the mobile application or the «Anti hijack» mode is on, use the code of emergency security deactivation given on the plastic card.
  • Page 35 short user manual 3) Switch on ignition or wait for 5 seconds. The LED on the service button will light up, the number of flashes will correspond to the ordinal number of the digit of the code of emergency security deactivation (1,2, 3 or 4 times). 4) Switch on the ignition.
  • Page 36 StarLine E96, E66 Example of entry of code 5342...

  • Page 37: Change Of Owner Authorisation Code

    short user manual Change of owner authorization code The owner code is used for user authorization by means of the standard car buttons. Do as follows to change the owner authorization code: 1) Deactivate the system security. 2) Switch off ignition (if it is on). 3) Press the service button 7 times.
  • Page 38 StarLine E96, E66 The owner authorization code consists of a code sequence, containing from 5 to 30 pressings of the standard buttons. The list of standard buttons supported by the car is given on the website can.starline.ru If a light signal does not follow after pressing of a standard button, the button is not supported in the given car.

  • Page 39: Owner Authorisation Code

    short user manual Owner authorization code...
  • Page 40 StarLine E96, E66 The manufacturer reserves the right to modify and improve the product design and technical features without prior notice. Manufacturer: ScPA “StarLine” LLC, Komissara Smirnova str., 9, 194044, Saint-Petersburg, Russian Federation Tel. +7 812 3263333 www.alarmstarline.com...
