  • Page 1 Security-telematic system User manual Version 1.0.1...

  • Page 2: Table Of Contents

    Safety precautions ................. 3 General description ................7 Technical specification................9 Personal ID card ..................10 StarLine.online service and mobile app ..........11 Lights and sound indication ..............12 Control with wireless tag (transponder) ..........14 Control with 2-way remote key ............16 Operation modes ...................

  • Page 3: Safety Precautions

    . In order to check whether this security system is suitable for your car follow a vehicle instruction manual and manufacturer’s requirements. StarLine security system is a complicated technical appliance implying connection to vehicle wiring and equipment, including those related to engine operation.
  • Page 4 5. Never give the security system remote key, tag or mobile phone with StarLine app over children or other persons unless operation manual carefully studied. 6. Before remote engine start activation make sure of: •...
  • Page 5 user manual • sufficient level of fuel, oil, cooling and other technical fluids available; • necessary parameters of climate control unit, heating and other accessories are preset; • set fan regulator to an air circulation position for more effective cabin cooling or warming up. Safety precautions while vehicle storage battery charging Remember that any battery charging process implies supply of voltage...
  • Page 6 StarLine E9 v2 Owner is fully responsible for possible short circuit or surge voltage and damaging of security system and vehicle electronic components caused while using this method. Follow a safe storage battery charging procedure! Before charging a battery terminals shall be disconnected from vehicle circuits.

  • Page 7: General Description

    General description Security telematics system StarLine S9 V2 (hereinafter the system) is intended for vehicle securing against theft, immobilising and convenient remote control via cellular networks and location monitoring with use of global satellite positioning systems. Depending on delivery set StarLine security system can be controlled with radio remote key, wireless radio tag and a smartphone with StarLine App.
  • Page 8 • data recording and storage a trip data in non-volatile memory (“black box”); • universal programmable input and output channels; • Flexible Logic for customized system operation in various individual scenarios; • universal StarLine Master installer’s software for system configuration and updating.

  • Page 9: Technical Specification

    Rated radio notification distance up to 2000 m • 2x CAN • 4 x LIN • 1 x StarLine coded data bus • 1 x USB • 18 programmable channels which can be set as: • 15 OC negative outputs – 200 mA max Interfaces •...

  • Page 10: Personal Id Card

    • Login and password for StarLine personal account • Emergency disarm code for instant security deactivation when regular disarming methods unavailable. • Service code to enter main unit configuration parameters in StarLine Master software • Main unit serial number Remove the protection layer from plastic card carefully. Do not use metal and other sharp items to avoid occasional erasing a printed information under layer.

  • Page 11: Starline.online Service And Mobile App

    StarLine 2 mobile app with free of charge unlimited subscription. This feature is available when E9v2 security system is paired with the optional StarLine M66 GSM GPS wireless communication (tracking) device via Bluetooth. In this bundle login and password from M66 ID card is used to sign in StarLine account.

  • Page 12: Lights And Sound Indication

    StarLine E9 v2 Do not forget to enter and verify your email in personal StarLine account. Verified email is necessary to restore forgotten password, access sharing and other important functionality. Lights and sound indication Security system indicates its status by means of sounds (siren or buzzer) and lights (hazard or other lights).
  • Page 13 user manual LED service button indication State of security system LED light Disarmed Disarmed with ignition On and one of secured zones 1 flash per 5 sec breach (doors, hood, trunk) Armed 1 flash per 1 sec Armed with Hands free mode active 2 flashes per 1 sec Engine is running continuous On...

  • Page 14: Control With Wireless Tag (Transponder)

    StarLine E9 v2 Control with wireless tag (transponder) (optional accessory) Wireless tags availability depends on delivery set. The included and optional tags are supplied from factory in transport (power saving) mode, i.e. inactive! Pushing a tag button in this mode is indicated by green and red alternating flashes of the built-in LED.
  • Page 15 user manual Command Button push Arm / disarm 1 short Enable / disable Anti-hijack by a tag away long 1 level Enable / disable Service mode long 2 level Replacing a tag battery Wireless tag (transponder) is equipped with CR2032 type Li-ion battery. Tag battery discharging is indicated with 3 sounds of embedded main unit buzzer (or siren) at ignition On.

  • Page 16: Control With 2-Way Remote Key

    StarLine E9 v2 Control with 2-way remote key (optional accessory) LCD remote control and matching external RF868 transceiver are optional accessories and can be ordered from local dealer. Display icons meaning Remote engine start Icons Meaning Engine is running Automatic engine start by timer enabled...
  • Page 17 user manual Operating modes Icons Meaning Armed Hands Free mode Service mode Programming mode Buttons lock Anti-Hijack mode Secured zones Icons Meaning Ignition switched On Parking brake tighten Hood open Door open Trunk open Sensors Icons Meaning Motion or tilt sensors triggered Auxiliary sensor 1 triggered Auxiliary sensor 2 triggered Tilt sensor triggered...
  • Page 18 StarLine E9 v2 Shock sensor warning level triggered Shock sensor main level triggered Shock sensor disabled Additional indicators Icons Meaning Data transfer Replace remote battery Siren sounds enabled Siren sounds disabled Control commands Button 4 Button 3 Button 2 Button 1...
  • Page 19 user manual Definition of buttons push duration: Pushing one or two buttons once less than 1,5 sec. Example: — first button short push; Short push — short push of first and second buttons simultaneously. Pushing and holding a button or two buttons until melody and vibration come up.
  • Page 20 StarLine E9 v2 Stop engine Start parking heater Stop parking heater Find car on parking Switch shock sensor On / Off Switch motion / tilt sensor On / Off Enable Panic Unlock trunk Enable automatic engine start configuration menu or configuration...
  • Page 21 user manual Modes submenu is flipped with buttons short push forward backward accordingly. Submenu options selected with buttons short push: Parameters are tuned with buttons short push up and down accordingly. Long buttons pushing increases parameters tuning speed. Listing menu points, changing settings and menu exit are confirmed with melody.
  • Page 22 StarLine E9 v2 Time and date setup 1. Enter time setup menu with sequential pushing button: 2. Set current time hours with button and minutes with button. • 1 – hours • 2 – minutes 3. Push button to turn to current date setting.
  • Page 23 user manual 4. Set current date with button, current month with button and year with button. 5. Push buttons together to exit from time setup menu. Main settings menu Operation parameters are set in the Setting menu. Settings menu is entered and exited with 4 button long push level 2: 1 –...
  • Page 24 StarLine E9 v2 Current time is automatically retrieved from cellular network and satellites data (if GPS module is available). Setting lights and siren indication at Arming and Disarming Select 2 item of Settings menu and set the mode with buttons: 0 –...
  • Page 25 user manual Setting motion sensor sensitivity Select 6 item of Settings menu and set sensor sensitivity from 0 to 30 level with buttons: 0 – motion sensor is disabled, 30 – max sensitivity Setting tilt sensor sensitivity Select 7 item of Settings menu and set sensor sensitivity from 0 to 30 level with buttons: 0 –...
  • Page 26 StarLine E9 v2 Setting tag (transponder) detection range Select 11 item of Settings menu and set tag detection range value from 1 to 8 level with buttons: 1 – min distance, 8 – max distance Tag detection range must be set less than a tag loss range.
  • Page 27 user manual Setting parking heater starting max duration Select 16 item of Settings menu and set max parking heater starting interval from 1 to 10 min with buttons. Setting parking heater run time duration Select 17 item of Settings menu and set parking heater run time from 5 to 60 min with buttons.
  • Page 28 StarLine E9 v2 Setting temperature for automatic engine start Select 21 item of Settings menu and set automatic engine start temperature from +10 to – 40 ºС with buttons. Setting 2 way remote key detection range Select 22 item of Settings menu and set remote key detection range from...
  • Page 29 user manual Setting commands confirmation signals 1 — selected signal type volume level 2 — selected sound profile number 3 — commands confirmation sound settings icon 4 — vibration: — enabled, — disabled Sounds volume is tuned with buttons short push. Vibration is enabled and disabled with button short push.
  • Page 30 StarLine E9 v2 Setting alarm sounds volume 1 — selected signal type volume level 2 — selected sound profile number 3 — vibration: — enabled, — disabled 4 – alarm sounds volume settings icon Sounds volume is tuned with buttons short push.
  • Page 31 user manual 2 — selected volume 3 — selected sound profile 4 — vibration: — enabled, — disabled Sounds volume is tuned with buttons short push. Vibration is enabled and disabled with button short push. Next sound signal type is flipped with button short push.

  • Page 32: Operation Modes

    StarLine E9 v2 3. Push buttons shortly to select next tone. Sounds tone menu is automatically exited in 10 sec if no any buttons pushed. Buttons auto lock The option lock buttons automatically each time after backlit off. It is enabled and disabled with long push level 2.

  • Page 33: Silent Arming

    • pushing tag button once shortly • pushing remote key button shortly • command from StarLine mobile app • arming with factory security system in «Slave» • tag loss or touching capacitive sensor in Hands Free mode. System shall confirm arming with 1 lights flash and 1 siren sound.

  • Page 34: Automatic Doors Locking And Unlocking On A Trip

    StarLine E9 v2 • command from StarLine mobile app • disarming factory security system (Slave) • tag detection or holding capacitive sensor in Hands Free mode Disarming is confirmed with 2 siren sounds and 2 lights flashed. If alarm was triggered while armed mode then 3 siren sounds and 3 lights flashes come up at disarming.

  • Page 35: Trunk Unlocking In Armed Mode

    The system shall lock factory Keyless-Go system once StarLine tag is away of detection range. And then unlocks it once tag is detected again in range.

  • Page 36: Panic Mode

    StarLine E9 v2 The maximum number of zone triggering is limited to 8 times within 1 security cycle. Panic mode Panic mode ensures owner and vehicle security and informs on intrusion attempt. Mode can be activated with double pushing remote key button.

  • Page 37: Slave Mode

    user manual 30 sec 30 sec < 30 km/h 2. Anti-hijack operation sequence when speed from CAN bus is not supported: • any of secured zones has been breached (doors, hood or trunk) • motions sensor has triggered • in 30 sec system begins seeking for a tag or remote key •...

  • Page 38: Hands Free Mode

    StarLine E9 v2 • tag or remote key detection in range at disarming during adjusted interval from 15 to 60 sec • entering personal PIN code with factory buttons at ignition On during adjusted interval from 15 to 60 sec If authorization failed by any of methods then system shall activate warning siren sounds and then turn to alarm mode.

  • Page 39: Service (Valet) Mode

    user manual Disabling Hands Free mode for 1 security cycle When tag is within detection range at a parking place, then it is recommended to disable arming and disarming in Hands Free mode for 1 security cycle. • Hands Free is enabled / disabled for 1 cycle in one of following ways depending on current state (disarmed / armed) accordingly: •...

  • Page 40: Immobilizer Mode

    StarLine E9 v2 • entry to system configuration settings • entry to registration mode Service mode is enabled by any of following ways: • tag button long push level 1 (if this option is enabled in system configuration) • short push of remote key buttons •...

  • Page 41: Remote Engine Start

    Engine will be stopped. • system turns to Armed • “N” (program neutral) icon is indicated on remote key display and StarLine app main screen • system and vehicle are now ready for remote and automatic engine start. If any door is open or ignition is switched On after setting to...
  • Page 42 Parameters for automatic engine start can be configured in: • remote key operation modes menu • StarLine mobile app Automatic engine start is allowed only in armed mode, in 5 min after last engine stop and 1 hour after previous remote and automatic engine start.

  • Page 43: Parking Heater Control

    • disarm security system • push PTS button 1 or 2 times Learn ignition takeover support and particular procedure from your StarLine installer. Parking heater (preheater) control This feature lets warm up engine and/ or interior before a trip with remote and automatic activating parking heater and auxiliary heater.

  • Page 44: Intelligent Turbotimer

    Temperature and time for parking heater activation can be set in: • remote key operation mode menu • StarLine mobile app Parking heater is stopped when the set engine start temperature (for automatic engine start) or the set parking heater run time is reached and engine will be started then.

  • Page 45: Beach Mode

    System is disarmed by owner authorization with emergency disarm code entered by means of StarLine EC-1 touch sensor installed in a door handle or another convenient place (under plastic parts). System does not execute any commands from remote key in this mode.

  • Page 46: Video Recorder (Dashcam) Control

    StarLine E9 v2 Hands Free mode is switched Off in Beach mode until disarming. Disarming (exit from Beach mode) is done by entering emergency disarm code by means of touch sensor with less than 3 sec intervals. Every valid digit entry is confirmed with sounds and flashes in corresponding number.

  • Page 47: Accessories Registration

    user manual settings made in system configuration. Risky parking activation: 1. Disarm security system 2. Switch ignition Off 3. Push service button or external transceiver button twice 4. Switch ignition On. Double sounds shall follow. Risky parking activation is confirmed with 1 sound and flash, deactivation –...
  • Page 48 StarLine E9 v2 Total up to 8 Bluetooth accessories can be operated simultaneously, where: 1 memory cell is always reserved for registered smartphone or M66 tracking device, 7 cells are reserved for other wireless devices (tags, wireless relays and sensors). Once 8 first detected Bluetooth accessories are in range, then remaining registered Bluetooth accessories will be ignored until any of first devices get out of range.
  • Page 49 user manual Wireless tags (transponders) registration 1) Remove battery from a tag slot. 2) Push and hold tag button and insert battery back in slot observing the right polarity (“+” side top). The tag LED will light up red. 3) Release button and make sure a tag LED serial red flashes come up for 10 seconds..
  • Page 50 StarLine E9 v2 Smartphone registration 1. Enable Bluetooth in smartphone and activate device searching 2. Select “StarLine E96” in available devices list 3. Enter pairing code 000000 (for iOS click “Pair”) Remote key registration 1. Push 1 and 2 remote key buttons shortly...

  • Page 51: Owner Authorization Code (Pin-To-Drive)

    user manual Owner authorization code (PIN-to-Drive) Pin-to-Drive code entered with factory buttons is used for secondary owner authorization at disarming and immobilizer mode. Recording and changing authorization PIN code in registration mode: 1) Disarm system if it is armed. 2) Switch ignition Off if it is On. 3) Push service button or external transceiver button 7 times.
  • Page 52 Authorization PIN code may consist of 2 to 25 push sequence of factory buttons. List of supported factory buttons is published at can.starline.ru for each supported vehicle. If pushing a button is not indicated with a LED flash, then this button is not supported via CAN bus.
  • Page 53 user manual Deleting authorization PIN code 1. Disarm system if it is armed 2. Switch ignition Off if it is On 3. Push service button or external transceiver button 7 times. 4. Switch ignition On. 7 LED flashes and 7 beep sounds shall follow.

  • Page 54: Emergency Disarming

    StarLine E9 v2 Emergency disarming System can be fully disarmed with emergency disarm code, indicated on owner ID card, when: • tag is lost • tag or remote key battery discharged • Anti-hijack mode activated Emergency disarming with service button 1) Make sure ignition is switched On.
  • Page 55 user manual 3) Each digit entry will be confirmed within 3 sec with service button LED flashes in a number equal to a sequence number of corresponding digit entered (1,2, 3 or 4 times). 4) Repeat 1...2 steps for remaining digits. 5) Valid code entry is confirmed with 3 flashes and 3 sounds, system turns disarm.
  • Page 56 StarLine E9 v2 Changing emergency disarm code with service button (or external transceiver button) 1. Switch system in disarmed mode if it is armed. 2. Push service button 4 times. 3. Switch ignition On. 4 LED flashes and 4 sounds shall follow.

  • Page 57: Optional Accessories

    user manual Optional accessories BT-6 wireless tag (transponder) Short range 1-way remote control on a distance 10-15 m approx Radio operation range – 2.4 GHz Bluetooth Low Energy Button for arming / disarming / switching operation mode / engine start / stop LED indicator Buil-in accelerometer Battery CR2032 3V...
  • Page 58 StarLine E9 v2 EC-1 touch sensor Capacitive sensor to perform Hands Free functionality by touching a door handle when tag is in range and emergency disarm code entry in Beach mode. MS-06BT wireless sensor Wireless sensor with reed switch to secure camper, van doors, windows, roof racks etc.
  • Page 59 user manual R6 Eco wireless relay module Wireless service module for engine blocking and custom functionality Radio operation range – 2.4 GHz Bluetooth Low Energy Input power 5...12V, can be powered from engine sensors circuit Built-in accelerometer Built-in relays for engine blocking (0.5A) and other custom functionality Programmable outputs Stand-alone mode...

  • Page 60: Memo

    StarLine E9 v2 Memo Security system parts layout main unit service button start module blocked circuit siren...
  • Page 61 Personal info Service code: Emergency disarm code: Pin-to-Drive buttons code sequence: StarLine account Login / Password:...

  • Page 62: Conformity Statement

    StarLine E9 v2 Approvals StarLine E9 v2 vehicle security system conforms the relevant international regulations Electromagnetic compatibility directive 2014/30 EU UNECE vehicles and parts regulations R116 (VSS) and R10 (EMC) The manufacturer reserves the right to modify and improve the product design and technical features without prior notice.

  • Page 63: Warranty Terms

    Warranty terms Warranty repair and replace is carried out by StarLine authorized dealers and service centers. Warranty period is 3 years beginning from the date of purchase. Service life is 5 years providing device is installed, configured and used according to the present instruction manual and connection diagram recommendations.
  • Page 64 StarLine E9 v2 Purchase certificate Model __________________ _______________________________________ Serial number_____________ ______________________________________ Date of purchase “______” ________________ 20____ Reseller name, address, stamp and signature ______________________________________________________________ ______________________________________________________________ Installation certificate I, the undersigned ________________________________________________ name, position professional installer herein certify that above specified security system is...
