Summarization of Contents
Intended Use and Limitations
General Excavator Configuration
Describes the excavator's basic configuration and movement capabilities.
Machine Applications and Restrictions
Details the intended applications, operational conditions, and prohibited uses of the machine.
Machine Static Dimensions and Specifications
Dimensional Diagrams
Illustrates the excavator with dimensional labels for various parts.
Machine Specification Dimensions
Provides detailed physical dimensions for different models and undercarriage options.
Boom and Dipper Length Dimensions
Lists transport dimensions for different boom and dipper length configurations.
Tie Down Points for Transport
Standard Undercarriage Tie Down
Shows standard tie-down configurations and points for the undercarriage.
Dozer Option Tie Down Specifications
Specifies tie-down point details and angles for various undercarriage types.
Safe Lifting Points and Procedures
Lifting Point Identification
Emphasizes identification of lifting points via decals for safe operation.
Operator Cab Layout and Control Functions
Cab Control Diagram
Provides a visual layout of the operator's cab controls.
Operator Controls Description
Details the function and location of all controls within the operator's cab.
Instrument Panel Indicators and Gauges
Main Instrument Panel Diagram
Illustrates the main instrument panel displays and indicators.
Fuel Gauge Details
Shows the detailed layout of the fuel gauge and its components.
Indicator and Gauge Explanations
Explains the meaning of various icons and gauges on the instrument panel.
Rotary Controller I Operation
Rotary Controller I Diagram
Shows the layout of the rotary controller.
Rotary Controller I Functions
Describes the functions of the rotary controller's various inputs and selectors.
Rotary Controller 2 and Keypad I Functions
Rotary Controller 2 Diagram
Displays the layout of the second rotary controller.
Rotary Controller 2 Functions
Details the functions of the second rotary controller buttons.
Keypad I Diagram
Illustrates the layout of the first keypad.
Keypad I Functions
Explains the functions of the buttons on the first keypad.
Keypad 2 Functions and Immobiliser
Keypad 2 Diagram
Displays the layout of the second keypad.
Keypad 2 Functions
Details the functions of the buttons and immobiliser keys on the second keypad.
Left Hand Joystick Controls
LH Joystick Diagram
Illustrates the left-hand joystick and its operational directions.
LH Joystick Functions
Explains the functions of the left-hand joystick and its controls.
Right Hand Joystick Controls
RH Joystick Diagram
Shows the right-hand joystick and its operational directions.
RH Joystick Functions
Details the functions of the right-hand joystick and its controls.
Track Levers and TAB Boom Controls
Track Levers and Pedals Diagram
Illustrates the track levers and travel pedals.
Track Levers and Pedals Functions
Explains the function of the track control levers and pedals.
TAB Boom Controls Diagram
Shows the TAB boom controls and their functions.
TAB Boom Controls Functions
Describes the operation of the TAB boom controls.
Machine Start Up Sequence Steps
Insert Isolator Key
Details the first step of inserting and turning the isolator key.
Check Isolation Lever
Instructs to ensure the hydraulic isolation lever is in the correct position.
Engage Seat Belt
Emphasizes engaging the seat belt before starting the machine.
Engine Pre Heat
Explains how to turn the ignition for engine pre-heating.
Disarm Immobiliser
Describes the process of disarming the immobiliser if fitted.
Start Machine
Guides on holding the start/stop button to begin engine operation.
Raise LH Isolator Lever
Instructs to raise the left-hand isolator lever to activate hydraulics.
Press 2 GO Button
Details pressing the 2 GO button to activate hydraulics.
Operate Machine
Confirms all controls are active and the machine is ready for use.
Shutdown and Auxiliary Venting Procedures
Shutdown Sequence Steps
Outlines the steps for safely shutting down and securing the machine.
Auxiliary Venting Procedure
Details the procedure for venting auxiliary hydraulic systems after shutdown.
Hydraulic Quick Hitch Operation
Standard Attachment Procedure
Describes the process for unlocking and confirming standard attachments.
Attachment Removal
Explains how to remove an attachment after disengaging the quick hitch.
Attachment Change Process
Guides on aligning and attaching new equipment using the quick hitch.
Locking the Quick Hitch
Details how to engage and visually confirm the quick hitch lock.
Specialised Attachment Handling
Covers procedures for specialised attachments, including crowd override.
Lifting Mode Operations and Safety
Mode Selection and Power Bands
Describes how to activate lifting mode and adjust power bands.
Overload Alarm and Autoidle
Explains the automatic overload alarm and autoidle deactivation in lift mode.
Disabling Lift Mode
Explains how to deactivate lift mode using rotary controller 2.
Lift Overload Warning System Behavior
Covers how the machine remembers settings and the warning light behavior.
Safe Machine Maintenance Positioning
Maintenance Position Diagram
Illustrates the machine configuration for maintenance.
Steps for Safe Maintenance Positioning
Provides a step-by-step guide for placing the machine in a safe maintenance position.
Service and Maintenance Schedule
Daily Checks (10h)
Lists daily checks and their required actions (visual check, lubricate, clean, operate).
Weekly Checks (50h)
Lists weekly checks and their required actions (lubricate, clean, visual check, operate).
Maintenance Points: Filters and Fluid Access
Maintenance Points: Filter and Fluid Access
Shows the locations of key service points like filters and DEF filler.
Maintenance Points: Fuel, Oil, Water Separator Locations
Illustrates the locations of fuel and oil system maintenance points.
Maintenance Points: Cab Air Filter Location
Shows the location of the fresh air cab filter for maintenance.
Maintenance Points: Engine and Gearbox Access
Maintenance Points: Engine and Gearbox Access
Displays the locations for various fluid filler caps and gearbox access points.
Maintenance Points: Access Cover Components
Shows components related to access covers for maintenance.
Maintenance Points: Step Access Locations
DEF Filler Access Procedure
Details how to access the DEF filler cap located on the upper step.
Toolbox and Refuel Pump Access
Explains access to the toolbox and refuel pump on the lower step.
Fluids and Lubricants Specifications
Fuel, DEF, and Cooling System Fluids
Covers capacity, fluid types, and specifications for fuel, DEF, and cooling systems.
Engine Oil and Hydraulic Fluid Specifications
Details oil types, capacities, temperatures, and part numbers for engine and hydraulics.
Gearbox, Roller, Cylinder, and Slew Ring Lubrication
Lists lubricant types, capacities, and part numbers for gearboxes, rollers, cylinders, and slew rings.
General Grease and Notes
Provides information on general grease types and notes on JCB part numbers.
Troubleshooting: Starting and Hydraulic Issues
Machine Not Starting Solutions
Provides solutions for issues preventing the machine from starting.
Hydraulic Activation Problems
Offers steps to troubleshoot and resolve hydraulic activation problems.
Identifying 2Go System Status
Explains how to identify the status of the hydraulic 2Go system.
Troubleshooting: Advanced Operational Queries
Quickhitch and Load Warning System
Addresses queries on quickhitch operation and audible load warning system.
250 Hour Greasing Procedures
Clarifies greasing frequency and bush replacement for 250-hour intervals.
Control Pattern and Bluetooth Connectivity
Explains switching joystick patterns and pairing a phone via Bluetooth.
Travel Alarm and Cool Box Issues
Covers deactivating the travel alarm and resolving cool box airflow problems.
