jcb 210 Series Quick Start Manual

Tracked excavators
Hide thumbs Also See for 210 Series:
Table of Contents

Advertisement

Quick Links

Quick Start Guide
QUICKSTART.JCB.COM
Tracked Excavators
210X 220X
1

Advertisement

Table of Contents
loading

Related Manuals for jcb 210 Series

Summary of Contents for jcb 210 Series

  • Page 1 Quick Start Guide QUICKSTART.JCB.COM Tracked Excavators 210X 220X...
  • Page 2 Operation of this machine without periodic maintenance could cause it to malfunction. For more information please contact your JCB Dealer. Please see operator manual for full details.

  • Page 3: Table Of Contents

    Index Intended use ............................4 Static dimensions ..........................5 Tie down points ..........................6 Lifting points ............................8 Cab layout & controls .........................9 Start up sequence ..........................17 Shutdown sequence .........................18 Hydraulic quick hitch .........................19 Lifting mode .............................20 Maintenance position ........................21 Service / maintenance schedule ......................22 Fluids &...

  • Page 4: Intended Use

    Intended use General > Machine Type – Heavy Excavator > Self propelled machine with a tracked undercarriage > 360° revolving upper structure with boom, dipper, bucket and slew mechanism Intended Use > The machine is intended to be used in normal conditions for the applications and in the environmental condition as described in the operators manual >...

  • Page 5: Static Dimensions

    Static Dimensions Fig 1 Fig 1 Dimensions in mm Machine Type Undercarriage options Track length on ground 3660 3370 3660 3660 3370 Undercarriage overall length 4460 4170 4460 4460 4170 Track gauge 2390 2170 2390 2170 2170 Width over tracks (500mm trackshoes) 2890 2670 2890...

  • Page 6: Tie Down Points

    Tie down points Fig 2 A Undercarriage tie down points B Dipper tie down points Standard undercarriage Please see operator manual for full details.
  • Page 7 Tie down points Fig 3 Undercarriage dozer option Tie down position decal Undercarriage type Track Running gear Angles in degree width CL width 210SC / 220SC / 220SCXD 800mm 2,170mm 20° 16.5° 41° 35° 210LC / 220LC / 220LCXD / 220LCLR 900mm 2,390mm 20°...

  • Page 8: Lifting Points

    Lifting points Fig 4 A Lifting points B Lifting decal Note: The correct lifting positions are identified on the machine by their decals (B): Please see operator manual for full details.

  • Page 9: Cab Layout & Controls

    Cab layout & controls Fig 5 A Track controls L Fire extinguisher (option) B Display unit M Option switches C Keypad 1 N Winter control panel (option) D Dozer control (option) P Left hand pod E Right joystick Q Operators seat F Dial control panel R Left hand joystick G Display control panel...
  • Page 10 Instrument panel Fig 6 A Upper ribbon icons J Power band B Ambient temperature K Lower ribbon HVAC (Heating Ventilation Air Conditioning) icons C Clock L HVAC/Fan speed D Machine hours M Fuel level gauge E Camera screen (if camera mode selected) N Coolant temperature gauge F Volume or phone/media P DEF fluid level gauge...
  • Page 11 Rotary controller 1 Fig 8 A Rotary media volume control: Rotate clockwise to increase, anti-clockwise to decrease. Push to mute. B Rotary media track/source control: Rotate clockwise to skip forward, anti-clockwise to skip backwards. Push to select source. C Engine start/stop button. D Rotary wiper control: Wiper off, intermediate 1, intermediate 2, continuous.
  • Page 12 Rotary controller 2 Fig 9 A Quick hitch confirm button B Lift mode on/off button C Overload warning on/off button D Quickhitch lock/unlock button E Rotary control F Back button G Home button Keypad 1 Fig 10 A Slew lock on/off button B Beacon on/off button C Camera button D Controls isolate button.
  • Page 13 Keypad 2 Fig 11 A Call accept/reject/end button Immobiliser key number 2 B Boom float button Immobiliser key number 4 C Exhaust filter button, Immobiliser key number 6. Press the button to initiate or defer SCR (Selective Catalytic Reduction) D Aux 1 button. Immobiliser key number 8 E Aux 2 button.
  • Page 14 Pedals and controls LH Joystick (ISO control pattern) Fig 12 A Boom slew priority B Horn C Hot key D Proportional Auxiliary Control high flow (option) Left: Slew to the left Right: Slew to the right Forward: Move the dipper outwards Backward: Move the dipper inwards Please see operator manual for full details.
  • Page 15 Pedals and controls RH Joystick (ISO control pattern) Fig 13 A Proportional auxiliary control low flow (option) B 2 - speed tracking C One touch engine idle D Power boost Backward: Raise the boom Forward (lower the boom) Left: Fill the bucket Right: Empty the bucket 210X 220X...
  • Page 16 Pedals and controls Track levers Fig 14 A Left track lever B Right track lever C Right track pedal D Left travel pedal E Footrests TAB boom controls (option) Fig 15 A Pedal B Ram Heel end of pedal: Extend the ram To end of the pedal: Retract the ram Please see operator manual for full details.

  • Page 17: Start Up Sequence

    Start up sequence Insert Isolator Key Check Isolation Lever Engage Seat Belt Insert isolator key (A) and turn Ensure the hydraulic isolation Engage seat belt (A) into latch in a clockwise direction. lever is in the lower position (B). (B) before starting machine. Engine Pre Heat Disarm Immobiliser Start Machine...

  • Page 18: Shutdown Sequence

    Shutdown and auxiliary venting Shutdown sequence Park machine up Leave and secure Isolate machine Park machine on solid level Switch off all switches. Leave Turn isolator key anti-clockwise ground with the attachment and machine using the handrails and remove key. dozer (if fitted) on the ground.

  • Page 19: Hydraulic Quick Hitch

    Hydraulic quick hitch Standard attachments Start unlock process Confirm process Indicator To start quick hitch unlock Switch (B) will flash and the process ensure hydraulics buzzer will sound constantly for When the sequence is are live then press quick hitch 5 seconds indicating confirmation confirmed the confirmation sequence button (A).

  • Page 20: Lifting Mode

    Lifting mode Mode selection Power band adjustment Overload alarm Activate button (A) on In lift mode the power band Overload warning alarm controller 2. adjusts from A to B. is automatically activated, highlighted on screen by (A). Autoidle de-activate Disable lift mode Autoidle de-activates when in To disable lift mode press lift mode, symbol B will not be...

  • Page 21: Maintenance Position

    Maintenance position Fig 16 A Excavator End Park the machine on solid, level ground, with the upper structure parallel to the undercarriage. If necessary, lower the dozer blade. Lower the excavator end to ground. Stop the engine. Remove the ignition key. Release the hydraulic pressure and the tank pressure.

  • Page 22: Service/Maintenance Schedule

    Service/Maintenance Schedule Daily Checks (10h) Check Check condition of attachments / optional equipment Visual check Grease attachments / optional equipment as required Lubricate Clean bodywork and framework Clean Check condition of bodywork and framework Visual check Check condition of cab/canopy including seat belt Visual check Check engine for leaks and oil level Visual check...
  • Page 23 Service & Maintenance Points Fig 17 A Air filter B Fuse box C Batteries D Battery isolator E Window washer fluid bottle F Radiator(s) Fig 18 A Main fuel filter B Engine oil filter C Lubricity filter (option) D Fuel sedimenter E Hydraulic oil level indicator F Fuel tap G Water separator...
  • Page 24 Service & Maintenance Points Fig 20 A DEF (Diesel Exhaust Fluid) filler cap B Diesel fuel filler cap C Hydraulic oil filler cap D Engine oil dip stick E Engine oil filler cap F Coolant expansion tank G Slew gearbox filler H Slew gearbox dipstick J Blower booster filter (option) K Slew gear grease bath...
  • Page 25 Service & Maintenance Points Upper step – DEF filler access Fig 22 A Latch B Cover C DEF tank filler cap Lower step – Toolbox/refuel pump access (if fitted) Fig 23 A Fuel hose B Close-off valve C Switch 210X 220X...

  • Page 26: Fluids & Lubricants

    All other grease As required JCB Special HP Grease 4003/2006 12.5kg JCB part numbers are liable to change and may also vary by region. For the latest information, always check with your dealer/distributor. Please see operator manual for full details.

  • Page 27: Troubleshooting/Faqs

    Troubleshooting/FAQs Issue / FAQ Resolution / Answer Ensure that the start-up sequence has been followed (Page 17). If the machine is fitted with an immobiliser make sure the My machine will not start correct pin has been entered. If the machine still will not start contact dealer. Make sure that the isolation lever is in the upper position (page 17).
  • Page 28 Troubleshooting/FAQs Issue / FAQ Resolution / Answer Can I open the quickhitch with The quickhitch can be opened with the attachment on the the attachment on the ground? ground using the quickhitch override feature (Page 19). Why is there an audible buzzer The lift overload warning system has detected a load that is near the in the cab when I am lifting a limits of the machine, reduce the load to prevent overturn (Page 20).

  • Page 29: Your Notes

    Your Notes 210X 220X...
  • Page 30 Your Notes Please see operator manual for full details.
  • Page 31 Your Notes 210X 220X...
  • Page 32 They should not therefore be relied upon in relation to suitability for a particular application. Guidance and advice should always be sought from your JCB Dealer’. JCB reserves the right to change specifications without notice. Illustrations and specifications shown may include optional equipment and accessories.
