Summarization of Contents
Installation
Suspension Mounting
Suspend front and rear of Feeder from cables attached to suspension bracket eyebolts.
Floor Mounting
Mount front and rear of Feeder on the floor mounting accessories provided.
Combined Suspension and Floor Mounting
Any combination of suspension and floor mounting means may be utilized.
Special Trays and Attachments Note
Consult Eriez before designing special trays or modifying standard ones.
Electrical Connections
Caution: Engine-Driven Power Plants
Operation from portable engine-driven power plants can adversely affect feeders due to frequency shifts.
Operation
Adjustment (Tuning)
Adjustments are made by changing the stiffness of the springing system at the back of the unit.
Adjustment (Tuning) Guide
General rules for increasing or decreasing tray displacement by adjusting spring stiffness.
Operation Caution
Only Eriez-approved trays are acceptable; modifications void warranty. Never operate in a striking condition.
Displacement Measurement and Tuning
How To Measure Displacement
Observe the displacement sticker and read the amount opposite where fine gray lines meet.
Tuning with New Tray
Steps to follow for adjusting the unit when a new tray is installed.
Material Density Tuning
Adjusting or Tuning For Various Densities of Materials
Adjusting displacement for optimum performance with specific material densities.
Repairs
Coil Replacement
Procedure for replacing the electrical assembly, including checking the air gap.
Spring Replacement
Spring Change or Replacement
Symptoms of spring failure and general replacement guidance.
58B Feeder Spring Replacement
Steps for replacing front and rear springs on the 58B model.
Feeder Model Spring Replacement
62B and 65B Feeders Spring Replacement
Steps for replacing front and rear springs on 62B and 65B models.
70B and 75B Feeders Spring Replacement
Steps for replacing front and rear springs on 70B and 75B models.
