- Page 1 VM-3154D Installation, Operation and Maintenance Instructions VIBRATORY FEEDERS mODEl hS36 ERIEZ WORLD HEADQUARTERS: 2200 ASBURY ROAD, ERIE, PA 16506–1402 U.S.A. WORLD AUTHORITY IN SEPARATION TECHNOLOGIES Vibratory Feeder: Model HS36...
- Page 2 Introduction This manual details the proper steps for installing, operating and maintaining the Eriez Vibratory Feeder. Careful attention to these requirements will assure the most efficient and dependable performance of this equipment. If there are any questions or comments about the manual, please call Eriez Manufacturing at 814-835-6000 for Vibratory Feeder assistance.
-
Page 3: Table Of Contents
Table of Contents ERIEZ VIBRATORY FEEDER - MODEL HS36 INSTALLATION ..................... 4 Mounting ......................4 Electrical Connections ..................4 OPERATION AND MAINTENANCE ..............4 Tuning Guide ....................4 How To Measure Displacement ............... 5 Tuning for Non-standard Trays ................ 5 Tuning for Different Conditions of Tray Loading .......... -
Page 4: Installation
ELECTRICAL CONNECTIONS After full steady-state displacement has been attained, NOTE: The Eriez Vibratory Feeder is designed to be use the controller to adjust the unit to the desired operated from an AC source. It cannot be operated feed rate. -
Page 5: How To Measure Displacement
HOw TO MEASURE DISPLACEMENT sum of the relative stiffness numbers. By various Position an Eriez displacement sticker on the outer combinations of different ply springs having different side of the tray, near the rear of the tray and at an relative stiffnesses, practically any desired total angle of 25°... -
Page 6: Tuning For Different Conditions Of Tray Loading
TUNING FOR DIFFERENT CONDITIONS OF TRAY LOADING Units with Eriez-built trays are factory tuned for maximum displacement (approximately .090" to .100" [2.3 mm to 2.5 mm]) with light loading (light head load, light materials, limited depth of flow of heavier materials). -
Page 7: Spring Change Or Replacement
(Figure 8). The purpose of Coil this is to hold the tiebar or tray-tiebar assembly in position while the tuning springs are removed. E-frame Armature Gap spacers adapter Rear spring stack Body housing Diaphragm FIGURE 7 FIGURE 8 Vibratory Feeder: Model HS36... -
Page 8: Armature Replacement
A failed spring will exhibit one or more of the Table 1 following characteristics: Torque Chart HS36 A. Looseness of the spring combined with signs of rubbing or abrasion at the outer surface of ARMATURE REPLACEMENT the cylinder. -
Page 9: The Hi-Vi Magnetic Drive Circuit
Note that both poles of the permanent magnet are being attracted toward the unlike electromagnet poles. They are also being repelled in the same direction by the like electromagnet poles. Vibratory Feeder: Model HS36... -
Page 10: Troubleshooting
REFER TO TABLE 2. SERVICE CHART Coil Failure Misapplication Replace coil or coil and E-frame assembly. Feeder too small. Product difficult or impossible Order from Eriez parts lists. Follow maintenance to handle. Impossible temperatures or instructions carefully. atmospheres. Impossible dimensional Control Failure requirements. - Page 11 Check all connections and correct. 17. Shockmount Deterioration Check and correct. 18. Corrosive or Abrasive Material May require special tray. Consult Eriez. 19. Product Variation If product density, moisture content or other characteristics vary, customer should take own corrective measures.
- Page 12 Eriez and Eriez Magnetics are registered trademarks of Eriez Manufacturing Co, Erie, PA ©2019 Eriez Magnetics All Rights Reserved World Authority in Separation Technologies Headquarters: 2200 Asbury Road, Erie, PA 16506-1402 U.S.A. Telephone: 814-835-6000 • Fax: 814-838-4960 www.eriez.com e-mail: eriez@eriez.com...
