- Page 1 VM-3166B Installation, Operation and Maintenance Instructions Vibra- tory feeder model Hs36 Vibratory feeder model Hd36 & Hd36C ERIEZ WORLD HEADQUARTERS: 2200 ASBURY ROAD, ERIE, PA 16506–1402 U.S.A. WORLD AUTHORITY IN SEPARATION TECHNOLOGIES...
- Page 2 Careful attention to these requirements will assure the most efficient and dependable performance of this equipment. If there are any questions or comments about the manual, please call Eriez at 814-835-6000 for Vibratory Feeder assistance. CAUTION Safety labels must be affixed to this product.
-
Page 3: Table Of Contents
Table of Contents ERIEZ VIBRATORY FEEDER - MODEL HD36 & HD36C INSTALLATION ..................... 4 Mounting ......................4 Electrical Connections ..................4 OPERATION AND MAINTENANCE ..............4 Tuning Guide ....................4 How To Measure Displacement ............... 5 Tuning for Non-standard Trays ................ 5 Tuning for Different Conditions of Tray Loading .......... -
Page 4: Installation
FIGURE 1 of the vibratory elements. Electrical Connections IMPORTANT NOTE: NOTE: The Eriez Vibratory Feeder is designed to be Special Trays and Attachments operated from an AC source. It cannot be operated Eriez engineering service should always be consulted from a DC source. -
Page 5: How To Measure Displacement
How to Measure Displacement The unit can then be properly tuned to the desired Position an Eriez displacement sticker on the outer displacement. At no time should the displacement side of the tray, near the rear of the tray and at an exceed the value indicated on the name tag. -
Page 6: Tuning For Non-Standard Trays
Tuning For Different Conditions of Tray Loading HD36 with Eriez-built trays are factory tuned for maximum displacement (approximately .120 to .125 inches [3.0 mm to 3.2 mm]) with light loading HD36C will not... -
Page 7: Spring Change Or Replacement
E-frame and the two pole pieces (Figure 4 and 8). The purpose of this is to hold the tiebar or tray- tiebar assembly in position while the tuning springs Body housing are removed. Diaphragm FIGURE 7 Vibratory Feeder: Model HD36 & HD36C... -
Page 8: Armature Replacement
22.0 Elastomer Nut M12-1.75 53.5 Table 1 Torque Chart HD36/HD36C ARMATURE REPLACEMENT FIGURE 8 Refer to the Parts List Drawing and Figs. 4, 5, 6 & 7. If after inspection of the rear tuning spring stack, CAUTION: This unit contains Rare Earth Magnets. -
Page 9: The Hi-Vi Magnetic Drive Circuit
(Torque - see Table 1). opposite direction. • Tighten rear spring stack. (Torque - see Table 1). • Tighten electrical E-frame assembly. (Torque - see Table 1). Vibratory Feeder: Model HD36 & HD36C... - Page 10 Repairs (cont.) POTENTIOMETER POWER ELECTRO-MAGNET SUPPLY ARMATURE CONNECTED PERMANENT TO SPRINGS AND MAGNET MOVING MASS FIGURE 12 CAUTION Operation from portable engine driven power plants. Varying and unstable line frequency has a diverse effect on vibratory feeders because they are tuned mechanical devices, designed for 40 cycle operating frequency.
- Page 11 Diaphragm 434502 Hex Head Bolt 430232 NOTE: All fasteners listed above are metric high strength plated steel class 8.8. When ordering parts be sure to specify Feeder Model and Style, Part No. and Quantity. Vibratory Feeder: Model HD36 & HD36C...
- Page 12 Parts List (cont.) Model HD36C Part Part Item Item Number Name Number Quantity Number Name Number Quantity Body Casting 131854 Front Clamp Bar 125389 Armature 133343 Diaphragm 434502 Armature Adapter 131856 Diaphragm Spacer 400742 Electrical Assembly Specify Voltage Diaphragm Clamp 434503 Tie Bar 132331...
-
Page 13: Troubleshooting
Refer To Table 2. Service Chart Coil Failure Misapplication Replace coil or coil and E-frame assembly. Feeder too small. Product difficult or impossible Order from Eriez parts lists. Follow maintenance to handle. Impossible temperatures or instructions carefully. atmospheres. Impossible dimensional Control Failure requirements. -
Page 14: Storage
To increase and Eriez. Equipment should remain in its original displacement, use more or thicker tuning springs. shipping crate or packaging and be placed in a clean, dry area. - Page 15 Vibratory Feeder: Model HD36 & HD36C...
- Page 16 Eriez and Eriez Magnetics are registered trademarks of Eriez Manufacturing Co, Erie, PA ©2019 Eriez All Rights Reserved World Authority in Separation Technologies Headquarters: 2200 Asbury Road, Erie, PA 16506-1402 U.S.A. Telephone: 814-835-6000 • Fax: 814-838-4960 www.eriez.com e-mail: eriez@eriez.com...
