  • Page 1 SC-ICG (In-Ceiling Grille) SubContractor Series I N S T A L L A T I O N M A N U A L...

  • Page 2: Important Safety Instructions

    C a u t i o n I M P O R T A N T S A F E T Y I N S T R U C T I O N S Caution To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel.
  • Page 3 C o n g r a t u l a t i o n s Congratulations on your purchase of a Velodyne in-ceiling grille. The Velodyne in-ceiling grille is for use with the SC-IF/IC (In-Floor/In-Ceiling) or SC-600 IF/IC subwoofers. Read and follow this instruction manual to ensure safe and proper installation.
  • Page 4 I n s ta l l a t i o n I n s t r u c t i o n s R e t r o f i t 1. Determine the center position for the subwoofer installation location. 2.
  • Page 5 4. Cut the ceiling material along the solid line noted on the template, following the outer diameter of the circular template. Figure 2. Cut ceiling material along specified solid cut-line. w w w . v e l o d y n e . c o m SC-ICG (In-Ceiling Grille) User’s Manual...
  • Page 6 5. Insert the paint template into the in-ceiling grille basket. Paint the grille basket flange to match decor. 6. After the paint has dried, remove the paint template and insert the in-ceiling grille basket into the hole in the ceiling material. Figure 3.
  • Page 7 N e w C o n s t r u c t i o n 1. Designate a suitable location for for the installation of the Velodyne in-ceiling subwoofer, during the framing construction. Mark the driver location by stapling the mud ring template across the ceiling beams centered at the designated location.
  • Page 8 S p e c i f i c a t i o n s SPECIFICATIONS SC-600 In-Ceiling Grille Frame High strength ABS plastic Grille Paintable aluminum alloy Grille Dimensions 12” Cut-out Dimensions 11” Warranty (parts/labor) Five years (for normal usage) Shipping Weight (approx.) 5 lbs.

  • Page 9: To Obtain Service

    VELODYNE ACOUSTICS, Inc. (“VELODYNE”) warrants all electronics for a period of three years, drivers for a period of five years, and full range speakers for a period of five years. All VELODYNE products have a warranty from the date of purchase against defects in materials and workmanship subject to the following conditions:...
  • Page 10 V e l o d y n e P r o d u c t s 120V 230V ® ® DD Series MicroVee™ DD Series SPLi Series DD-10 DD-10 SPL-800i ® DD-12 MiniVee DD-12 SPL-1000i ® DD-15 MiniVee DD-15 ® DD-18 DD-18 SPL-R Series...
  • Page 11 Velodyne Acoustics, Inc. 345 Digital Drive Morgan Hill, CA 95037 408.465.2800 voice 408.779.9227 fax 408.779.9208 service fax www.velodyne.com Service E-mail: service@velodyne.com Product E-mail: help@velodyne.com Technical E-mail: techhelp@velodyne.com 63-IC12G Rev A JUL08 w w w . v e l o d y n e . c o m...
