Samsung SR-688EV Service Manual

S E R V I C E
R E F R I G E R A T O R
"A"
"A": WITH DISPENSER
S R - 6 0 8 E V
S R - 6 4 8 E V
S R - 6 8 8 E V
WITHOUT DISPENSER
SR-606EV
SR-646EV
SR-686EV
R E F R I G E R ATO R
Model : SR-608EV
SR-648EV
Model :
SR-688EV
M a n u a l
C O N T E N T S
1. Safety Precautions And Warnings
2. Product Specifications
3. Electrical Part Specifications & Standard
4. Electric Diagram
5. Outer Package Specification
6. Air Circulation Route
7. Functions And Directions
8. Circuit Operating Theory
9. Failure Diagnosis And Repairment
10. Disassemble & Assemble Drawing And
Part Lists
11. Disassemble & Assemble Method
12. Packing Method
13. PCB Diagram
14. PCB Specifications
15. Main Components Specifacations
