OWNER'S

INSTRUCTIONS

SR-608EV/648EV/688EV

(dispenser Applied)

606EV/646EV/686EV

REFRIGERATOR

Before operating the unit, please read this manual throughly,

and retain for future reference.

If you took out of the

power supply outlet, you

should plug in again after

five minutes.

DA68-60306A (0.2)

Table of Contents

Need help?

Do you have a question about the SR-606EVSS and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung SR-606EVSS

Page 1 606EV/646EV/686EV REFRIGERATOR Before operating the unit, please read this manual throughly, and retain for future reference. If you took out of the power supply outlet, you should plug in again after five minutes. Register your product at www.samsung.com/global/register DA68-60306A (0.2)
Page 2: Table Of Contents
FEATURE What is H.M.CYCLE(High-efficiency Multi- evaporator CYCLE)? • A high efficiency cooling method adopting an independent cooler and an independent cool- ing fan in freezing room and refrigerating room, respectively. • A new cooling method providing an economic energy, power cooling function and supply of high humidity cool air by independent cooler and cooling fan.
Page 3 WARNING Do not put a tank filled with water Do not install the refrigera-tor in Do not insert the power plug with on the product. the wet place or the place which the wet hand. • If water poured, it cause bad insu- water splashes.
Page 4 CAUTION Do not touch the tank and the food stuffs of the Do not enter the hand into the bottom surface of frezzing room with the wet hand. the product. • It may cause frostbite. • Sharp edge may inflict a wound. Please wipe out foreign materials of the metal If you want to insert the power plug again, please option of the power plug cleanly.
Page 5 SEPARATE AND INDEPENDENT COOLING OF REFRIGERATING AND FREEZING ROOMS! Refrigerator of energy-saving type • It adopts the high-efficiency Multi-evaporator CYCLE that makes it possible to cool the refrigerating room and freezing room separately and to reduce the power consumption and energy. Super-power cooling technique for quick refrigeration.
Page 6 THE CORRECT WAY OF PRESERVING FOODS. Please keep them after washing. Please store foods after dividing into small pieces. Please do not store foods which are apt to go bad Please place watery foods(particularly bean in low temperature. curds) on the front area of shelf in refrigerating (Examples : Bananas, Pineapples, Tomatoes etc.) room.
Page 7: Display Panel
DISPLAY PANEL High moisture refrigerating Door-alarm function function (Door opening) A high moisture refrigerating display lamp is A warning sound(Dingdong-Dingdong) indi- always on when the refrigerator is in opera- cates that door is open. tion. • In case the door is open wider than 15°, after 2 •...
Page 8 POWER FREEZING/TEMPERATURE CONTROL OF FREEZING ROOM The artificial intelligent function keeps the adjusted temperature of freezing room in the optimum state conforming with conditions of use. Power freezing(Quick freezing) When you want to freeze foods at a fast speed or to get ice quickly, The red lamp is on when selecting Power freezing by pressing “QUICK FRE”...
Page 9 POWER REFRIGERATION/TEMPERATURE CONTROL OF REFRIGERATING ROOM The artificial intelligent function keeps the adjusted temperature of refrigerating room in an optimum state conform- ing with conditions of use. Power refrigeration When you want to cool the foods quickly. The red lamp is on when selecting POWER REFRIGERATING by pressing “QUICK ref” button Please press the button one more time for cancelling power refrigeration.
Page 10: How To Preserve The Refrigerated Foods
HOW TO PRESERVE THE REFRIGERATED FOODS High humidity special fresh room Re-enforced glass shelf (chilled Room ) • Please use this room for foods to be stored in • Please keep the side dish foods in storage bowl colder environments than refrigerating room. or other refrigerated foods with a proper distance Please keep meat or fish in freezing room for its apart.
Page 11 FUCTIONS OF WATER DISPENSER Models applied : SR-608EV/648EV/688EV What is the water dispenser? If a water tank full of water and equipped with water supply device is inserted into the location where the water supply lever in the refrigerating room is connected to, the cold water can be available at the outside of door even without opening the door by pressing the water supply lever.
Page 12: How To Clean
HOW TO CLEAN (MODELS APPLIED : SR-608EV/648EV/688EV) Hand-grip Large lid Please separate the large lid from water tank after pulling it out. • It can be separated from water tank when pulling up both hand-grips of large lid. Water tank Please separate the water tank from water supply device.
Page 13: How To Disassemble And Assemble The Water Supply Device
HOW TO DISASSEMBLE AND ASSEMBLE THE WATER SUPPLY DEVICE When you want to further clean every corners of the water supply device, disassemble and assemble it after clean- ing as follows. HOW TO DISASSEMBLE (MODELS APPLIED : SR-608EV/648EV/688EV) Part (small rubber packing) Part (2-1) Part (Medium rubber packing) Part (Large rubber packing)
Page 14 HOW TO ASSEMBLE Fit the part, while pressing it, Fit the locking part of part into into part. the hole of part. part part part part Insert part and part into Insert the long portion of part into part. the hole of part. •...
Page 15: How To Install
HOW TO INSTALL HOW TO ADJUST LEVELING Adjust the leveling of refrigerator. • If the refrigerator is so installed to make its front a little high, the door can be easily opened and closed. Refrigerator leaning to the left. Refrigerator leaning to the right Make leveling by filling driver into Make leveling by fitting...
Page 16 HOW TO GROUND The refrigerator should be grounded. The purpose of grounding is to prevent any power leakage or electric shock caused by the current leakage from the refrigerator. Never ground to gas pipes, telephone line and lightning rod as it is very dangerous at the time of lightning strikes. In case of outlets without ground terminals.
Page 17: Before Asking For Service
BEFORE ASKING FOR SERVICE SYMPTIOMS CHECK Non-operation or bad refrigeration • Check the connection of power plug. • Isn’t the temperature control lamp of front operating panel in “LOW” mode? • Isn’t there sunshine or heat directly applied to refrigerator. •...
Page 18: Questions
QUESTIONS WHAT IS THE LOW TEMPERATURE CATALYZING DEODORIZER? Low temperature catalyzing deodorizer Low temperature catalyzing deodoriz- It is so designed as to suck and er is installed at cool air suction hole completely remove smells. Also it where the air of refrigerating room is has an excellent capability of deodor- sucked, therefore, even without any izing the bad smell of the favorate...
Page 19 Correct Disposal of This Product (Waste Electrical & Electronic Equipment) English (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
