REFRIGERATOR
Model: SR-61KTC/SR-61NMC
SR-65KTC/SR-65NMC
SR-69NMC
CONTENTS
1. Product Specifications
2. Safety Warning & Caution
3. Electrical part specifications & standard
5. Air Circulation route
6. Function & Vsing method
7. Temperature control & other Functions
9. Failure diagnosis & repairment
10. Dissembie & Assemble drowing and part LIST 53
11. Disassemble & Assemble Method
13. Main componets specification
1
2
4
6
7
8
11
21
36
88
84
86
