Summarization of Contents
Operating Instructions
Startup Test
The Ampstik conducts a startup test to verify sensors and circuitry functionality.
RUN & HOLD Mode
Explains how to use RUN mode for continuous readings and HOLD mode to store a single reading.
Clearing Display and Powering Off
Covers clearing measurements, switching modes, and turning the instrument off.
Automatic Backlight
Manually Power Off Backlight
Instructions on how to manually turn off the backlight using the control switch.
Manually Power On Backlight
Instructions on how to manually turn on the backlight using the control switch.
Troubleshooting the Ampstik
Unit Will Not Power On
Checks to perform if the unit fails to power on, such as battery and connector verification.
Backlight Flicker
Explanation that backlight flicker under artificial lighting is normal due to refresh rate.
Fail Codes
Lists common fail codes (1-4) indicating circuit or sensor failures and their causes.
Repair
SensorLink Service Department
Contact information and process for returning the instrument for evaluation, repair, or calibration.
