Page 3
When reading this instruction booklet, keep the watch diagram on the left unfolded and in full view. The symbols (A, B, etc.) on the diagram are those referred to in the section describing the operating instructions. Pendant la lecture de ce mode d'emploi, gardez le schéma d'illustration de la montre ci-contre ouvert et bien en vue.
Page 4
Thank you very much for purchasing a BREIL WATCH. To ensure its correct use, please read these instructions carefully. In order to be able to make full use of the guarantee service (subject to the guarantee terms), please ensure that the Breil international guarantee card is supplied with the watch at the time of purchase.
Page 5
CONTENTS MAIN COMPONENTS ........2 SETTING THE TIME AND DATE ......3 PRECAUTIONS AND USEFUL INFORMATION .
SETTING THE TIME AND DATE To set the time: 1. Pull out the crown to the second click position. 2. Turn the crown to set the hour and minute hands. 3. After the date has been set, push the crown back to the normal position. To set the date (fst digit): 1.
PRECAUTIONS AND USEFUL INFORMATION Indication Spray, sweat, light Swimming, Dial Case rain, washing, etc. etc. WATER RESISTANT WATER RESISTANT 30M (3ATM) WATER RESISTANT WATER RESISTANT 50M (5ATM) WATER RESISTANT WATER RESISTANT 100M (10ATM) WATER RESISTANT WATER RESISTANT 200M (20ATM) or more “WATER RESISTANT”...
Page 9
in water Skin-diving Scuba diving Water-resistance characteristics Not water resistant. Must be kept away from water and moisture Average water resistance. Can withstand spray, sweat, light rain, washing, etc. during daily use Can be worn while swimming but not diving Suitable for skin-diving.
Page 10
Temperature Do not leave the watch exposed to direct sunlight or temperature extremes for long periods of time. Long exposure, in fact, may adversely affect the operation of the watch and actually shorten battery life, causing it to gain or lose time and affect its other functions. Impact This watch can withstand normal everyday impacts and shocks and those normally imparted by non-contact sports.
Page 11
The watch case and strap may discolour if they come into contact with mercury from a broken thermometer or other equipment. Keeping the watch clean Use an absorbent soft cloth to clean off any dirt or damp from the watch glass. Wearing the watch when the strap or back of the case is dirty can cause skin irritation.
TECHNICAL DATA Movement: 1M52 Type: quartz analogue watch with time movement Frequency: 32.768 Hz Accuracy: +/-20 seconds per month at normal temperatures. Time function Hour: hour, minute and second hands Additional characteristics Calendar Battery: SR621SW or equivalent Battery life: 3 years * In order to improve the product, the technical specifications may be modified without prior notice.
Page 13
INDEX PIECES PRINCIPALES ....... .10 REGLAGE DE L’HEURE ET DE LA DATE ....11 PRECAUTIONS D’UTILISATION ET INFORMATIONS UTILES .
Page 14
PIECES PRINCIPALES Aiguille des heures Couronne Aiguille des minutes Aiguille des secondes Calendrier Caractéristiques: Montre analogique à quartz avec mouvement temps : heures et minutes Calendrier.
Page 15
REGLAGE DE L’HEURE ET DE LA DATE Pour régler l’heure: 1. Extraire la couronne jusqu’au deuxième déclic. 2. Faire pivoter la couronne pour régler les aiguilles des heures et des minutes. 3. Après avoir réglé l’heure, remettre la couronne en position normale. Pour régler la date: 1.
Page 16
PRECAUTIONS D’UTILISATION ET INFORMATIONS UTILES Indicacion Utilisation Eclaboussure, Natation Cadran Boîtier sueur, pluie légère, etc. ablutions, etc. WATER RESISTANT WATER RESISTANT 30M (3ATM) WATER RESISTANT WATER RESISTANT 50M (5ATM) WATER RESISTANT WATER RESISTANT 100M (10ATM) WATER RESISTANT WATER RESISTANT 200M (20ATM) ou plus L’indication “WATER RESISTANT”...
Page 17
sous l’eau Plongée Caractéristiques Plongée en d’étanchéité profondeur Non étanche. Doit être protégée de l’eau et de l’humidité. Etanchéité normale. Résiste aux éclaboussures, à la sueur, à la pluie légère, aux ablutions, etc. pendant l’utilisation quotidienne. Utilisation possible pendant la natation. Adaptée à...
Page 18
Température Ne pas laisser la montre exposée aux rayons directs du soleil ou dans des endroits extrêmement chauds ou extrêmement froids pendant une longue période. Cela pourrait en effet provoquer un mauvais fonctionnement de la montre ou réduire la durée de la pile, ou encore entraîner un ralentissement ou une accélération de la montre et des conséquences sur les autres fonctions.
Page 19
Substances chimiques et gaz Ne pas porter la montre en présence de substances chimiques fortes ou de gaz. Si la montre entre en contact avec des solvants, comme le benzène, ou bien avec des produits. contenant des substances telles que essence, cires, détersifs, adhésifs, ses pièces peuvent se décolorer, se dissoudre ou se rompre.
Page 20
DONNÉES TECHNIQUES Caractéristiques du mouvement Calibre: 1M52 Type: Montre analogique à quartz avec mouvement temps Fréquence: 32.768 Hz Retard ou avance: +/-20 s/mois en conditions normales d’utilisation. Fonction mouvement temps Heure: aiguilles des heures, minutes et secondes. Fonctions supplémentaires Calendrier...
Page 21
INHALTSVERZEICHNIS HAUPTBESTANDTEILE .......18 EINSTELLUNG DER UHRZEIT UND DES DATUMS ..19 HINWEISE ZUM TRAGEN DER UHR .
HAUPTBESTANDTEILE Stundenzeiger Stellkrone Minutenzeiger Sekundenzeiger Kalender Eigenschaften: Analoge Quarzhur mit Uhrwerk nur für Zeitanzeige: Stunden und Minuten Kalender...
EINSTELLUNG DER URHZEIT UND DES DATUMS Einstellung der Urhzeit: 1. Die Stellkrone bis zur zweiten Position herausziehen. 2. Drehen Sie die Krone , um Stunden- und Minutenzeiger einzustellen. 3. Wenn Sie die Uhrzeit eingestellt haben, bringen Sie die Krone in die Normalposition zurück.
HINWEISE ZUM TRAGEN DER UHR Angabe Gebrauch Spritzwasser, Schwimmen Ziffernblatt Gehäuse Schweifl, leichter usw. regen, Waschen, usw. NEIN NEIN WATER RESISTANT NEIN WATER RESISTANT 30M (3ATM) WATER RESISTANT WATER RESISTANT 50M (5ATM) WATER RESISTANT WATER RESISTANT 100M (10ATM) WATER RESISTANT WATER RESISTANT 200M (20ATM) oder mehr Die Angabe “WATER RESISTANT”...
Page 25
in Wasser Tauchen Tieftauchen Dichtheit NEIN NEIN Nicht wasserdicht. Vor Wasser und Feuchte schützen. NEIN NEIN Normal wasserdicht. Widersteht Spritzwasser, Schweib, leichtem Regen, Waschen usw. im täglichen Gebrauch. NEIN NEIN Kann zum Schwimmen eingesetzt werden, zum Tauchen nicht empfohlen. NEIN Zum Tauchen ohne Flaschen geeignet.
Page 26
Temperatur Setzen Sie die Uhr nie längerer Zeit direkter Sonneneinstrahlung aus und legen Sie nicht an besonders heißen oder kalten Orten ab. Dies kann die Funktionsweise der Uhr beeinträchtigen und die Lebensdauer der Batterie verkürzen, was einen schnelleren oder langsameren Lauf der Uhr bewirkt und auch Auswirkungen auf ihre sonstige Funktionen hat.
Page 27
Chemikalien und Gase Tragen Sie die Uhr nicht in Räumen, in denen aggressive chemische Substanzen oder Gase vorhanden sind. Kommt die Uhr mit Lösungsmittel wie Benzol oder chemischen Substanzen wie Benzin, Poliermittel, Waschflüssigkeiten oder Klebstoffen in Berührung, können ihre Komponenten entfärben, sich auflösen oder zerbrechen. Achten Sie besonders darauf, daß...
TECHNISCHE DATEN Kaliber: 1M52 Typ: Analoge Quarzuhr mit Uhrwerk nur für Zeitanzeige Frequenz: 32.768 Hz Genauigkeit: +/- 20 S/Monat unter normalen Betriebsbedingungen Uhrwerkfunktionen nur Zeitanzeige Stunden-, Minuten- und Sekundenzeiger. Zusatzfunktionen Zusatzfunkionen Batterie: SR621SW oder gleichwertig Lebensdauer der Batterie: Etwa 3 Jahre...
Page 29
INDICE COMPONENTI PRINCIPALI ......26 IMPOSTAZIONE DELL’ORA E DELLA DATA ....27 PRECAUZIONI PER L’USO E NOTIZIE UTILI .
COMPONENTI PRINCIPALI Lancetta delle ore Corona Lancetta dei minuti Lancetta dei secondi Calendario Caratteristiche: Orologio analogico al quarzo con movimento solo tempo: ore e minuti Calendario.
IMPOSTAZIONE DELL’ORA E DELLA DATA Per impostare l’ora: 1. Estrarre la corona fino al secondo clic. 2. Ruotare la corona per regolare le lancette dei minuti e delle ore. 3. Al termine, riportare la corona in posizione normale. Per impostare la data (prima cifra): 1.
PRECAUZIONI PER L’USO E NOTIZIE UTILI Indicazione Spruzzi, sudore, Nuoto Quadrante Cassa pioggia leggera, ecc. abluzione, ecc. WATER RESISTANT WATER RESISTANT 30M (3ATM) WATER RESISTANT WATER RESISTANT 50M (5ATM) WATER RESISTANT WATER RESISTANT 100M (10ATM) WATER RESISTANT WATER RESISTANT 200M (20ATM) e oltre L’indicazione “WATER RESISTANT”...
Page 33
in acqua Immersione Immersione in Caratteristiche profondità di impermeabilità Non impermeabile. Va protetto da acqua e umidità Impermeabilità normale. Resiste a spruzzi, sudore, pioggia leggera, abluzioni ecc. durante l’uso quotidiano. Utilizzabile durante il nuoto ma sconsigliato per immersioni. Adatto ad immersioni poco impegnative. Adatto a tutte le immersioni.
Page 34
Temperatura Non lasciare l’orologio sotto i raggi diretti del sole o in luoghi estremamente caldi o estremamente freddi per un lungo periodo di tempo. Ciò potrebbe infatti creare degli inconvenienti al funzionamento dell’orologio ed accorciare la durata della batteria, provocando anche un rallentamento o un’accelerazione dell’orologio e conseguenze sulle altre funzioni.
Page 35
Sostanze chimiche e gas Non indossare l’orologio quando ci si trova in presenza di forti sostanze chimiche e di gas. Se l’orologio viene a contatto di solventi, come benzene, oppure con prodotti contenenti sostanze come benzina, lucidi, detergenti, adesivi, le sue parti possono scolorarsi, dissolversi o spaccarsi.
DATI TECNICI Calibro: 1M52 Tipo: Orologio analogico al quarzo con movimento solo tempo Frequenza: 32.768 Hz Precisione: +/-20 s/mese in normali condizioni d’uso. Funzioni movimento solo tempo Ora: lancetta delle ore, dei minuti e dei secondi Funzioni supplementari Data Batteria:...
Page 37
INDICE COMPONENTES PRINCIPALES ......34 CONFIGURACIÓN DE LA HORA Y DE LA FECHA ...35 PRECAUCIONES PARA EL USO E INFORMACIONES UTILES .36 DATOS TÉCNICOS .
Page 38
COMPONENTES PRINCIPALES Aguja de las horas Corona Aguja de los minutos Aguja de los segundos Calendario Características: Reloj de cuarzo analógico con movimiento sólo tiempo: horas y minutos Calendario...
Page 39
CONFIGURACIÓN DE LA HORA Y DE LA FECHA Como regular la hora 1. Extraiga la corona hasta el segundo clic. 2. Gire la corona para configurar las agujas de las horas y de los minutos. 3. Una vez configurada la hora, coloque nuevamente la corona en su posición normal. Como configurar la fecha (primera cifra) 1.
Page 40
PRECAUCIONES PARA EL USO E INFORMACIONES UTILES Indicación Salpicaduras, Natación Esfera Caja transpiración, etc. llovizna, abluciones, etc. WATER RESISTANT WATER RESISTANT 30M (3ATM) WATER RESISTANT WATER RESISTANT 50M (5ATM) WATER RESISTANT WATER RESISTANT 100M (10ATM) WATER RESISTANT WATER RESISTANT 200M (20ATM) o más Algunas veces la indicación “WATER RESISTANT”...
Page 41
en agua Inmersión Características Inmersión de impermeabilidad profundidad No es impermeable. Debe protegerse del agua y la humedad. Impermeabilidad normal. Durante el uso cotidiano resiste a salpicaduras, transpiración, llovizna, abluciones, etc. Utilizable durante la natación pero no para inmersiones. Idóneo para inmersiones poco importantes. Idóneo para inmersiones importantes de profundidad.
Page 42
Temperatura No exponga nunca el reloj a los rayos directos del sol ni lo deje en lugares extremadamente calurosos o fríos durante un largo período de tiempo. En todos estos casos, se podría afectar el funcionamiento del reloj y acortar la duración de la pila.
Page 43
Si el reloj entra en contacto con solvente como el benceno, o con productos que contienen substancias como bencina, barnices, bruñidores, detergentes o adhesivos, sus partes pueden desteñirse, disolverse o romperse. Ponga mucha atención para evitar las substancias químicas. La caja y la correa del reloj pueden desteñirse si entran en contacto con el mercurio de un termómetro roto o de otra proveniencia.
Page 44
DATOS TÉCNICOS Calibre: 1M52 Tipo: reloj de cuarzo analógico con movimiento sólo tiempo: horas y minutos Frecuencia: 32.768 Hz Precisión: +/-20 s/mes en condiciones normales de uso Funciones movimiento sólo tiempo Hora: aguja de las horas, minutos y segundos Funciones adicionales...
