DVD PLAYER

DV-393-S
DV-393-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
DV-393-S
WYXZT5
DV-393-S
WVXZT5
DV-393-S
WYXZT/UR5
DV-393-K
WYXZT5
DV-393-K
WYXZT/UR5
For details, refer to "
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
Power Requirement
AC220-240V
AC220-240V
AC220-240V
AC220-240V
AC220-240V
Important Check Points for Good Servicing
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
DV-393-S
Region No.
2
2
5
2
5
" .
T-ZZR MAR. 2006 printed in Japan
ORDER NO.
RRV3332
Remarks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV-393-K and is the answer not in the manual?

Questions and answers

Summarization of Contents

Safety Information
Laser Diode Characteristics
Details about laser diode power output and wavelength for DVD and CD.
Label Check
Information regarding caution labels found on the unit.
Important Check Points for Good Servicing
Product Safety
Conformity to safety regulations and maintaining a safe servicing environment.
Adjustments
Procedures to maintain original performance through optimum adjustments.
Lubricants, Glues, and Replacement Parts
Guidelines for using specified lubricants, glues, and parts during repairs.
Cleaning
Proper cleaning procedures for optical pickups, heads, and lenses.
Shipping Mode and Shipping Screws
Instructions for setting shipping mode or installing screws for transit.
Specifications
General Specifications
Overall system, power requirements, dimensions, temperature, and humidity.
Video Output
Specifications for video output level and jack type.
Audio Output (1 Stereo Pair)
Specifications for audio output level, channels, and jacks.
AV Connector Output
Details on the 21-pin AV connector assignment for signals.
Digital Audio Characteristics
Frequency response, S/N ratio, and distortion of digital audio.
Digital Output
Information on coaxial digital output.
Accessories
List of included accessories like cables and remote control.
Component Video Output
Specifications for component video output levels and jacks.
Exploded Views and Parts List
Packing Section
Illustrated breakdown of packing contents and components.
06 DVD Mecha Section
Tray Removal
Procedure for removing and handling the disc tray.
Traverse Assembly Removal
Instructions for removing the traverse assembly.
Loading Motor PCB Assy / Loading Belt
Steps for removing loading motor PCB and belt.
Block Diagram and Schematic Diagram
Block Diagram
Overall block diagram of the DV-393-S MPEG/FIP system.
Operation 1, Operation 2, and Operation 3 PCB Assys
Operation 1 PCB Assy
List of buttons for the Operation 1 PCB.
Operation 2 PCB Assy
List of buttons for the Operation 2 PCB.
Operation 3 PCB Assy
Button list for the Operation 3 PCB (POWER).
Power PCB Assy (1/2)
Power PCB Assy (A21802A240)
Power block diagram for the Power PCB Assy.
Power PCB Assy (2/2)
Power PCB Assy (A21802A240)
21-pin/Digital Audio block diagram for the Power PCB Assy.
PCB Connection Diagram
Loading and SW PCB Assys
PCB connection diagrams for Loading and SW PCBs.
Loading Motor PCB Assy (Inserted Parts)
PCB layout for Loading Motor Assy (inserted parts).
Loading Motor PCB Assy (Chip Mounted Parts)
PCB layout for Loading Motor Assy (chip mounted parts).
SW PCB Assy
PCB layout for SW PCB Assy.
DVD MT PCB Assy
DVD MT PCB Assy (Side A)
Component layout for the DVD MT PCB Assy (Side A).
DVD MT PCB Assy (Side A)
Component layout for the DVD MT PCB Assy (Side A).
DVD MT PCB Assy (Side B)
Component layout for the DVD MT PCB Assy (Side B).
Operation 1, Operation 2, and Operation 3 PCB Assys
Operation 2 PCB Assy (Side A)
Component layout for Operation 2 PCB Assy (Side A).
Operation 1 PCB Assy (Side A)
Component layout for Operation 1 PCB Assy (Side A).
Operation 2 PCB Assy (Side A)
Component layout for Operation 2 PCB Assy (Side A).
Operation 3 PCB Assy (Side A)
Component layout for Operation 3 PCB Assy (Side A).
Operation 2 PCB Assy (Side B)
Component layout for Operation 2 PCB Assy (Side B).
Operation 1 PCB Assy (Side B)
Component layout for Operation 1 PCB Assy (Side B).
Operation 3 PCB Assy (Side B)
Component layout for Operation 3 PCB Assy (Side B).
Power PCB Assy
Power PCB Assy (Side A)
Component layout for the Power PCB Assy (Side A).
Power PCB Assy (Side B)
Component layout for the Power PCB Assy (Side B).
PCB Parts List
List of Assemblies
List of main PCB assemblies and their part numbers.
Semiconductors
List of semiconductor components and their part numbers.
Switches and Relays
List of switches and relays with part numbers.
Others
List of miscellaneous parts like sockets and fuses.
Adjustment
When Replacing DVD Deck
Procedures for removing and installing the DVD deck, including soldering notes.
Test Mode In
Test Mode Entry
Steps to enter the test mode using the remote control.
Release the Test Mode
Procedure to exit the test mode.
LD ON
How to turn on the DVD (650nm) and CD (780nm) laser diodes.
Disc Removal Method
Parental Control - Rating Level 4 Digit Password Cancellation
Steps to cancel the 4-digit parental control password.
Preparation of Servicing
Measures to prevent static electricity damage to the laser diode.
General Information
Diagnosis
Information related to diagnosing unit issues.
Display Specification of the Test Mode
Details on how various parameters are displayed in test mode.
Specification of Model Information Display
Destination Indication
How destination indication is displayed.
Region No.
How region number is displayed.
ROM Number
How ROM number is displayed.
REG CHK
How REG CHK is displayed.
SUM CHK
How SUM CHK is displayed.
CHIP VERSION
How chip version is displayed.
Functional Specification of the Service Mode
ID Address Display
Display of ID Address during service mode.
Error Rate Display
Display of error rate in exponential notation.
EDC/ID Error History
Display of EDC/ID error history.
Method for Diagnosing Degradation of the LDs on the Pickup Assy
No Playback of a DVD
Diagnosing DVD playback issues by measuring voltage.
No Playback of a CD
Diagnosing CD playback issues by measuring voltage.
Trouble Shooting
The Power is Not Turned On
Troubleshooting steps for no power issue.
Opening Screen Not Displayed (Mechanism Inactive)
Troubleshooting display issues when the mechanism is inactive.
Tray Cannot Be Opened
Troubleshooting steps when the tray cannot be opened.
Playback Impossible (No Focusing)
Troubleshooting playback and focusing issues.
Playback Impossible (Spindle Does Not Turn)
Troubleshooting issues when the spindle motor does not turn.
Playback Impossible (Playback Stops)
Troubleshooting playback stop issues and laser diode checks.
Picture Disturbance During Playback
Troubleshooting picture disturbances like noise or freezing.
No Sound (Picture Normal)
Troubleshooting no sound issues when the picture is normal.
Symptoms Related to IC Failures
EEP ROM (IC4003) Failure Symptoms
Symptoms related to EEP ROM failure.
16M Flash ROM (IC4004) Failure Symptoms
Symptoms related to 16M Flash ROM failure.
DVD IC (IC4001) Failure Symptoms
Symptoms related to DVD IC failure.
64M SDRAM (IC4005) Failure Symptoms
Symptoms related to 64M SDRAM failure.
Disassembly
Removal of Top Cabinet, Front Cabinet, and PCBs
Steps to remove top cabinet, front cabinet, and PCBs.
Power PCB Removal
Procedure for removing the Power PCB.
DVD Deck Removal
Steps to remove the DVD deck, including laser safety.
DVD PCB Removal
Procedure for removing the DVD PCB.
DVD Deck Section
Tray Removal
Steps to remove the disc tray.
Traverse Assembly Removal
Procedure for removing the traverse assembly.
Loading Motor PCB Assy / Loading Belt Removal
Steps for removing loading motor PCB and belt.
IC Information
MT1389FE/E-L (IC4001) Pin Arrangement
Pin arrangement and function for the MT1389FE/E-L IC.
MT1389FE/E-L Pin Functions
RF Interface Pins
Pin functions for the RF interface.
ALPC Pins
Pin functions for the ALPC interface.
Reference Voltage Pins
Pin functions for reference voltages.
Analog Monitor Output Pins
Pin functions for analog monitor outputs.
Analog Servo Interface Pins
Pin functions for analog servo interface.
RF Data PLL Interface Pins
Pin functions for RF data PLL interface.
Motor and Actuator Driver Interface Pins
Pin functions for motor and actuator driver interface.
General Power/Ground Pins
Pin functions for general power and ground.
Microcontroller and Flash Interface Pins
Pin functions for microcontroller and flash interface.
Microcontroller Address/Data Pins
Pin functions for microcontroller address/data.
Flash Address Pins
Pin functions for flash addresses.
Microcontroller Port Pins
Pin functions for microcontroller ports.
Audio Interface Pins
Pin functions for audio interface.
Video Interface Pins
Pin functions for video interface.
Miscellaneous Pins
Miscellaneous pin functions.
Disc / Content Format Playback Compatibility
Glossary
Glossary of terms related to audio and video formats.
Analog Audio Definition
Definition of analog audio.
Aspect Ratio Definition
Definition of aspect ratio.
Digital Audio Definition
Definition of digital audio.
DRM Explanation
Explanation of Digital Rights Management copy protection.
DTS Audio Encoding
Information on DTS audio encoding system.
EXIF File Format
Definition of EXIF file format for digital cameras.
PBC (Playback Control)
System for navigating Video CD/Super VCD menus.
PCM Definition
Definition of PCM digital audio encoding.
Progressive Scan Video
Explanation of progressive scan video.
Regions Definition
Association of discs/players with geographical areas.
Sampling Frequency Definition
Rate of sound measurement for digital audio.
WMA Information
Information on Windows Media Audio compression technology.
HDMI Interface (DV-490V Only)
Explanation of High-Definition Multimedia Interface.
ISO 9660 Format
Standard for CD-ROM file structure.
JPEG Format
Standard file format for still images.
MP3 Format
Compressed stereo audio file format.
MPEG Audio Format
Audio format used on Video CD/Super VCDs/DVDs.
Panel Facilities
Front Panel Section
Details and functions of the front panel controls and display.
Front Panel Controls and Indicators
Functions of buttons like STANDBY/ON, OPEN/CLOSE, MENU, ENTER, etc.
RW Compatible Mark
Indicates compatibility with DVD-RW discs.
Remote Control
Remote Control Buttons
Functions of remote control buttons like STANDBY/ON, AUDIO, SUBTITLE, etc.
Number Buttons
Inputting numbers or codes.
Top Menu Button
Displays the top menu of a DVD disc.
Enter and Cursor Buttons
Navigates displays and executes commands.
Home Menu Button
Displays or exits the on-screen display.
Play Button
Starts or resumes playback.
Slow Motion and Scanning Buttons
Used for slow motion playback and scanning.
Chapter/Track Skip Buttons
Jumps to previous/next chapters or tracks.
Pause Button
Pauses playback.
Play Mode Button
Displays the Play Mode menu.
Surround Button
Activates/switches off surround sound.
Open/Close Button
Opens or closes the disc tray.
Angle Button
Changes camera angle for multi-angle scenes.
Clear Button
Clears numeric entry.
Menu Button
Displays DVD disc menu or Disc Navigator.
Return Button
Returns to previous menu screen.
Forward Scan Buttons
Forward slow motion, frame advance, forward scanning.
Next Chapter/Track Button
Jumps to next chapter or track.
Stop Button
Stops disc playback.
Display Button
Displays information about the playing disc.
Zoom Button
Changes the zoom level.
Jigs List
Service Remote Control Unit
Remote control unit used for diagnosis.
DVD Test Disc (NTSC)
Test disc for operation check (NTSC).
DVD Test Disc (PAL)
Test disc for operation check (PAL).
CD Test Disc
Test disc for operation check (CD).
Lubricants and Glues List
List of lubricants and glues used, with part numbers and remarks.
Cleaning Instructions
Cleaning instructions for product shipping.

Table of Contents
